Current technology does not allow us to extract information automatically from arbitrary media objects. In these cases, at least for the time being, we need to assist search by annotating content with what is commonly referred to as meta-information.

In this chapter, we will look at two more media types, in particular audio and video. Studying audio, we will learn how we may combine feature extraction and meta-information to define a data model that allows for search. Studying video, on the other hand, will indicate the complexity of devising a knowledge representation scheme that captures the content of video fragments.

Concluding this chapter, we will discuss an architecture for feature extraction for arbitrary media objects.

...

audio databases

• audio signals -- compression, discrete representation
• musical patterns -- similarity-based retrieval

audio data model

• meta-data -- describing content
• features -- using feature extraction

example

   singers -- (Opera,Role,Person)
   score -- ...
   transcript -- ...


signal-based content

• audio data -- $\%F(x)$ over time x
• wave -- period T, frequency $f\; =\; 1/T$
• velocity -- $v\; =\; w/T\; =\; w\; *\; f$, with $w$ wavelength
• amplitude -- a

windowing

• break signal up in small windows of time

feature extraction

• intensity -- watts/$m^2$
• loudness -- in decibels
• pitch -- from frequency and amplitude
• brightness -- amount of distortion

...

...

...

video annotation

• what are the interesting aspects?
• how do we represent this information?

video content

  video v, frame f
  f has associated objects and activities
  objects and activities have properties


property

  property: name = value


object schema

   (fd,fi) -- frame-dependent and frame-independent properties


object instance: (oid,os,ip)

• object-id -- oid
• object-schema -- os = (fd,fi)
• set of statements -- ip: name = v and name = v IN f

example

frame-independent properties

activity

• activity name -- id
• statements -- role = v

example

   { giver : Person, receiver : Person, item : Object }
   giver = Jane, receiver = Dennis, object = briefcase


...

video libraries

  which videos are in the library
  what constitutes the content of each video
  what is the location of a particular video


query language for video libraries

• segment retrievals -- exchange of briefcase
• object retrievals -- all people in v:[s,e]
• activity retrieval -- all activities in v:[s,e]
• property-based -- find all videos with object oid

VideoSQL

  SELECT -- v:[s,e]
  FROM -- video:<source><V>
  WHERE -- term IN funcall


example

  SELECT  vid:[s,e]
  FROM video:VidLib
  WHERE (vid,s,e) IN VideoWithObject(Dennis) AND
  	object IN ObjectsInVideo(vid,s,e) AND
  	object != Dennis AND
  	typeof(object) = Person


...

...

questions

• what -- content-related
• when -- position on time-continuum
• where -- geographic location

atlas of cyberspace

...

...

feature grammar


  detector song; ## to get the filename
  detector lyrics; ## extracts lyrics
  detector melody; ## extracts melody
  detector check;  ## to walk the tree

  atom str name;
  atom str text;
  atom str note;

  midi: song;

  song: file lyrics melody check;

  file: name;

  lyrics: text*;
  melody: note*;



  event('twinkle',2,time=384, note_on:[chan=2,pitch=72,vol=111]).
  event('twinkle',2,time=768, note_off:[chan=2,pitch=72,vol=100]).


melody detector

  int melodyDetector(tree *pt, list *tks ){
  char buf[1024]; char* _result;
  void* q = _query;
  int idq = 0;

    idq = query_eval(q,"X:melody(X)");
    while ((_result = query_result(q,idq)) ) {
           putAtom(tks,"note",_result);
           }
    return SUCCESS;
  }


...

...

prediction techniques

• social-based -- dependent on (group) rating of item(s)
• information-based -- dependent on features of item(s)
• hybrid methods -- combining predictors

definition(s)

• rating -- a value representing a user's interest
• recommendation -- item(s) that might be of interest to the user
• regret -- a function to measure the accuracy of recommendations

guided tour(s)

• automated (viewpoint) navigation in virtual space,
• an animation explaining, for example, the construction of an artwork, or
• the (narrative) presentation of a sequence of concept nodes.

...

6. content annotation

• (*) How can video information be made accessible? Discuss the requirements for supporting video queries.

concepts

• What are the ingredients of an audio data model
• What information must be stored to enable search for video content?
• What is feature extraction? Indicate how feature extraction can be deployed for arbitrary media formats.

technology

• What are the parameters for signal-based (audio) content?
• Give an example of the representation of frame-dependent en frame-independent properties of a video fragment.
• What are the elements of a query language for searching in video libraries?
• Give an example (with explanation) of the use of VideoSQL.

As a project, think of implementing musical similarity matching, or developing an application retrieving video fragments using a simple annotation logic.

You may further explore the construction of media repositories, and finding a balance between automatic indexing, content search and meta information.

For further reading I advice you to google recent research on video analysis, and the online material on search engines.
