Navigating media-rich information spaces using concept graphs -- the abramovic dossier
Anton Eliëns, Chris van Riel, Yiwen Wang
abstract
Navigating media-rich information spaces usually involves switching
back and forth between categories and lists indexing the material
and the actual media presentations.
In this paper,
we describe a multidisciplinary case study of creating a digital dossier
to present a collection of artworks and related information
in a more immersive manner, using a concept graph for navigation.
The case study is done for the artworks of the
Serbian-Dutch performance artist Marina Abramovic,
in cooperation with the Dutch Institute for Cultural heritage.
In the paper, we describe the design requirements, as well as the
technical realization of the abramovic dossier.
Based on an initial user evaluation, we also indicate directions for
future research, and discuss the style criteria for the user interface
of our digital dossier(s).
keywords:
digital dossiers, concept graphs, relation visualization, contemporary art, VRML.
Introduction
media-rich information spaces
Navigating media-rich information spaces usually involves switching
back and forth between categories and lists indexing the material
and the actual media presentations.
To address this problem, we developed a concept graph navigation
system in 3D that allows the presentation of media material
and navigation in a more immersive manner, [Bolter and Grusin (2000)], using a presentation gadget
that is closely connected with the navigation facilities
offered by the concept graph.
In this paper,
we describe a multidisciplinary case study of creating a digital dossier
to present a collection of artworks
of the Serbian-Dutch performance artist Marina Abramovic,
together with the art related information for the preservation
and re-installation of these artworks.
For the presentation of information we choose a 3D environment
which facilitates the presentation of text,
pictures and video as well as 3D models of artwork installations.
For navigation we developed a concept graph that allows
for choosing inter-related concepts,
artwork-related information and media recordings of artworks
in a unified intuitive fashion.
When navigating, a preview of the related material is shown in a semi-transparant way,
to assist the user in selecting the appropriate node.
The Abramovic dossier
resulted from a long-standing cooperation with
ICN (the Dutch Institute
for Cultural Heritage) and Montevideo
(the Institute for time-based arts), in the context of
the INCCA project
(International Network for the Conservation of Contemporary Art,
and the Culture 2000 project.
In a follow-up project, we worked at a digital dossier for
Jeffrey Shaw,
in which we further explored the incorporation of 3D models of artworks,
in this case for the installation Revolution.
The structure of this paper is as follows. In section 2, we describe the design requirements of the digital dossier.
followed by an overview of the
technical realization of the Abramovic dossier in section 4.
Based on an initial user evaluation,
we indicate, in section 5, directions for
future research and discuss the style criteria for the user interface
of our digital dossier(s). Finally, in section 6, we will draw our conclusions.
Design requirements
As material for the abramovic dossier there was an interview with
Marina Abramovic from ICN, made in cooperation with the Dutch Foundation
for the Visual Arts, and a great collection of videos from the Institute for Time-based Arts (Montevideo).
In addition, a transcription of the contents of the interview
made by Michela Negrini, a student of media art at the University of Amsterdam,
who also provided an interpretation as well as a categorization of the works of art.
The digital dossier for the artist Marina Abramovic had to satisfy the following requirements:
requirement(s)
- It must serve as an information source for conservators and curators of contemporary art,
- It must present rich media recordings of all artworks, and,
- In addition, it must provide background information for the general public (non-expert users).
The abramovic dossier was developed in 2004 as a collective student
project (including students from Computer Science, Information Science and
Artificial Intelligence) at the Vrije Universiteit, Amsterdam.
The directive with which the students where set to work was, quoting Ted Nelson:
everything must be highly intertwinkled.
Since virtual museums are by now a common phenomenon,
and the virtual atelier for Marinus Boezem (that was realized in a previous casus, [_Agents]) may be considered to be just a variant of this,
the 2004 autumn group decided to explore alternative ways of presentation and navigation, in particular the use of
a concept graph.
|
|
|
| Fig. 2: main node | Fig. 2: presentation gadget |
Realization of the digital dossier
The digital dossier was created with VRML (Virtual Reality Modeling Language),
which allows for creating virtual worlds and present them on the web.
concept graph
As a user interface for navigating the digital dossier, we created a concept graph
that represents relational information structures.
The concept graph allows the user to detect relations and search for information.
Unlike a 3D cone tree, [Robertson and MacKinlay (1991)], where the complete hierarchical structure is presented,
only a subset of the relational structure is shown - three levels deep.
The presentation of the concept graph is dynamic and actually determined by the user's choice.
To compensate for the lack of an instant overview, where all information is shown at once,
the user can, as already indicated in the previous section, also use keyword search instead of navigation.
icon(s)
Information objects shown in the concept graph are represented by 3D icons.
These 3D icons visualize a certain type of information, both
conceptual information, that represent categories, and
content information types, that represent actual (media) content,
including text, pictures and video.
The digital dossier contains different presentation facilities for 2D and 3D content.
For 2D media content a visualization facility is needed that is able to present video, images or textual information.
This facility is implemented as a content gadget with three windows.
In each of the three windows the user can view 2D media content.
These windows are positioned in such a way that
the user can inspect the information simultaneously.
In our experience, three images can be presented at the same time
without much visual distortion.
zoom
Below the three windows a list of all content related
to the selected information object is displayed.
By using drag-and-drop the user can view content on a window of choice.
If necessary, the user can focus on a particular window with a zoom option,
to avoid distraction from the other windows.
Since we adopted 3D technology, we could easily accommodate
a 3D model for one of the installation art works by Marina Abramovic.
We implemented a plain exhibition room, providing a
3D perspective of the installation Terra Degli Dea Madre
that allows the user to manipulate the position of the objects
by a click-and-drag function.
The 3D environment demonstrates the interactive exploration
of the installation of an artwork.
By manipulating position and/or angle of objects,
museum curators can get insight into how the artwork could be exhibited.
At this point, we can only speculate how useful such a reconstruction can be
as a tool for the conservator responsible for the re-installation,
to play around with the presentation parameters, the positioning in space,
the overall size, light and ambient effects.
Issues for future research and development
An initial usability evaluation (with staff members from ICN and Montevideo) indicated
that the concept graph supports both intuitive navigation and relationship detection.
However improvement of the visual appearance of the digital dossier is definitely possible and desired.
In summary, when demonstrating the application to
the interested parties, that is ICN and Montevideo,
a number of issues came along, that we will here summarize as a list of questions:
style issues
- what icons should be used to identify the elements of the concept graph?
- what categories and relationships are most appropriate?
- how should the information be displayed, simultaneously or more focussed?
- how do we allow the user to choose between multiple information items?
- how do we avoid visually disturbing elements?
Obviously, although the abramovic dossier was very positively
received, these issues must be dealt with to make it a success.
Having a first prototype, we needed to rethink our application,
not only with regard to its style of presentation
but, as we will discuss in the next section,
also in terms of its underlying data representation.
For constructing the actual abramovic dossier, we developed
a content management tool, that allows the user to browse
and edit existing nodes, and to insert new nodes into the graph.
However, to preserve the information stored in the digital dossier for future use, we must reconsider the data representation
i.e. how the information is stored and structured.
To use the information presented by the digital dossier, taking into account future developments in 3D technology
or other application contexts, it has to be independent of formatting information.
This means that the same information instance can be used for other presentations in a relatively easy way.
In particular, in case of the digital dossier the presented information has to be VRML independent.
In re-thinking the abramovic dossier,
we needed to re-establish what were our goals in developing this application
and what our primary data sources.
The primary goal, after all, is to support conservators in their task of preserving
contemporary art, and to assist them with the re-installation of such artworks.
For the next generation of digital dossiers, we stated the following requirements:
next generation dossier(s)
- adaptation of representation to Dublin Core
- XML-based content management, with php forms
- develop multiple ways to present the information
- provide stylesheets to accomodate user preferences wrt style
Another important question is
how we allow the user to interact with the material presented.
Conclusions
conclusion(s)
We have argued that a dynamically presented concept graph,
as used in the digital dossier,
may provide intuitive navigation when dealing with highly inter-related information structures in 3D space.
Instead of presenting a complete view of the hierarchy,
the concept graph shows only a subset of the information.
Presentation of content is separated from navigation but the digital dossier indicates a strong relation between them.
So far, the results of the initial evaluation look very promising for using the concept graph as a navigation paradigm.
Evaluation indicates that it is relatively easy to use and that it supports exploratory tasks rather well.
As such, the digital dossier can be a solution for dealing with presenting highly interrelated information structures in 3D space.
However, to get a more accurate view of the usability of the digital dossier, and in particular concept graphs as a navigation
paradign, we wish the explore more real world applications in the domain of cultural heritage,
that may reveal new issues for further development.
Acknowledgements
We gratefully acknowledge the contribution of the following people to the development of the digital dossier:
acknowledgement(s)
- Vrije Universiteit Amsterdam : Tim Verweij, Olav van Zon, Eric de Boer, Pascal Snijders Blok, Olaf van Zon
- Universiteit van Amsterdam : Abeer Mahdi, Jina Menke, Michela Negrini
- Technische Universiteit Delft: Jurgen Koster
- The Netherlands Institute for Cultural Heritage : Tatja Scholte, Ijsbrand Hummelen
- Montevideo : Bart Rutten, Gaby Wijers
References
- [Remediation] Bolter J.D and Grusin R. (2000),
- Remediation -- Understanding New Media,
MIT Press
- [ Hoorn J., Eliens A., Huang Z., van Vugt H.C.,
- Konijn E.A., Visser C.T. (2004), Agents with character: Evaluation of empathic agents in digital dossiers,
Emphatic Agents, AAMAS 2004 New York 19 July - 23 July, 2004
- [Cones] Robertson G.G. and MacKinlay J.D. (1991) ,
- Cone trees: animated 3D visualizations of hierarchical information,
Proc. of the SIGCHI Conference on Human factors in computing systems: Reaching through technology, 189 194, New Orleans, Louisiana, United States, March 1991.
- [Gadgets] Schonhage, B., van Ballegooij, A., Eliens, A. (2000),
- 3D gadgets for business process visualizations,
Proc. of the fifth symposium on Virtual reality modeling language (Web3D-VRML), 131 - 138, Monterey, California, United States, February 2000.
(C) Æliens
27/08/2009
You may not copy or print any of this material without explicit permission of the author or the publisher.
In case of other copyright issues, contact the author.
