SIDefines.h File Reference

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
	SIInstrFlags

Macros
#define	R_00B028_SPI_SHADER_PGM_RSRC1_PS   0x00B028
#define	R_00B02C_SPI_SHADER_PGM_RSRC2_PS   0x00B02C
#define	S_00B02C_EXTRA_LDS_SIZE(x)   (((x) & 0xFF) << 8)
#define	R_00B128_SPI_SHADER_PGM_RSRC1_VS   0x00B128
#define	R_00B228_SPI_SHADER_PGM_RSRC1_GS   0x00B228
#define	R_00B848_COMPUTE_PGM_RSRC1   0x00B848
#define	S_00B028_VGPRS(x)   (((x) & 0x3F) << 0)
#define	S_00B028_SGPRS(x)   (((x) & 0x0F) << 6)
#define	R_00B84C_COMPUTE_PGM_RSRC2   0x00B84C
#define	S_00B84C_LDS_SIZE(x)   (((x) & 0x1FF) << 15)
#define	R_0286CC_SPI_PS_INPUT_ENA   0x0286CC

Enumerations
enum	{   SIInstrFlags::MIMG = 1 << 3, SIInstrFlags::SMRD = 1 << 4, SIInstrFlags::VOP1 = 1 << 5, SIInstrFlags::VOP2 = 1 << 6,   SIInstrFlags::VOP3 = 1 << 7, SIInstrFlags::VOPC = 1 << 8, SIInstrFlags::SALU = 1 << 9 }

Macro Definition Documentation

#define R_00B028_SPI_SHADER_PGM_RSRC1_PS   0x00B028

Definition at line 26 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_00B02C_SPI_SHADER_PGM_RSRC2_PS   0x00B02C

Definition at line 27 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_00B128_SPI_SHADER_PGM_RSRC1_VS   0x00B128

Definition at line 29 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_00B228_SPI_SHADER_PGM_RSRC1_GS   0x00B228

Definition at line 30 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_00B848_COMPUTE_PGM_RSRC1   0x00B848

Definition at line 31 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_00B84C_COMPUTE_PGM_RSRC2   0x00B84C

Definition at line 34 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define R_0286CC_SPI_PS_INPUT_ENA   0x0286CC

Definition at line 36 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define S_00B028_SGPRS

(

x

)

(((x) & 0x0F) << 6)

Definition at line 33 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define S_00B028_VGPRS

(

x

)

(((x) & 0x3F) << 0)

Definition at line 32 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define S_00B02C_EXTRA_LDS_SIZE

(

x

)

(((x) & 0xFF) << 8)

Definition at line 28 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().

#define S_00B84C_LDS_SIZE

(

x

)

(((x) & 0x1FF) << 15)

Definition at line 35 of file SIDefines.h.

Referenced by llvm::AMDGPUAsmPrinter::EmitProgramInfoSI().
