llvm::DIFile Class Reference

DIFile - This is a wrapper for a file. More...

#include <DebugInfo.h>

Inheritance diagram for llvm::DIFile:

Collaboration diagram for llvm::DIFile:

Public Member Functions
	DIFile (const MDNode *N=0)
MDNode *	getFileNode () const
	Retrieve the MDNode for the directory/file pair. More...
bool	Verify () const
	Verify that the file descriptor is well formed. More...
Public Member Functions inherited from llvm::DIScope
	DIScope (const MDNode *N=0)
DIScopeRef	getContext () const
StringRef	getName () const
	If the scope node has a name, return that, else return an empty string. More...
StringRef	getFilename () const
StringRef	getDirectory () const
DIScopeRef	getRef () const
Public Member Functions inherited from llvm::DIDescriptor
	DIDescriptor (const MDNode *N=0)
bool	Verify () const
	operator MDNode * () const
MDNode *	operator-> () const
LLVM_EXPLICIT	operator bool () const
bool	operator== (DIDescriptor Other) const
bool	operator!= (DIDescriptor Other) const
uint16_t	getTag () const
bool	isDerivedType () const
	isDerivedType - Return true if the specified tag is legal for DIDerivedType. More...
bool	isCompositeType () const
bool	isBasicType () const
bool	isVariable () const
	isVariable - Return true if the specified tag is legal for DIVariable. More...
bool	isSubprogram () const
bool	isGlobalVariable () const
bool	isScope () const
bool	isFile () const
	isFile - Return true if the specified tag is DW_TAG_file_type. More...
bool	isCompileUnit () const
	isCompileUnit - Return true if the specified tag is DW_TAG_compile_unit. More...
bool	isNameSpace () const
	isNameSpace - Return true if the specified tag is DW_TAG_namespace. More...
bool	isLexicalBlockFile () const
bool	isLexicalBlock () const
	isLexicalBlock - Return true if the specified tag is DW_TAG_lexical_block. More...
bool	isSubrange () const
	isSubrange - Return true if the specified tag is DW_TAG_subrange_type. More...
bool	isEnumerator () const
	isEnumerator - Return true if the specified tag is DW_TAG_enumerator. More...
bool	isType () const
	isType - Return true if the specified tag is legal for DIType. More...
bool	isUnspecifiedParameter () const
bool	isTemplateTypeParameter () const
bool	isTemplateValueParameter () const
bool	isObjCProperty () const
	isObjCProperty - Return true if the specified tag is DW_TAG_APPLE_property. More...
bool	isImportedEntity () const
	Return true if the specified tag is DW_TAG_imported_module or DW_TAG_imported_declaration. More...
void	print (raw_ostream &OS) const
	print - print descriptor. More...
void	dump () const
	dump - print descriptor to dbgs() with a newline. More...

Friends
class	DIDescriptor

Additional Inherited Members
Public Types inherited from llvm::DIDescriptor
enum	{   FlagPrivate = 1 << 0, FlagProtected = 1 << 1, FlagFwdDecl = 1 << 2, FlagAppleBlock = 1 << 3,   FlagBlockByrefStruct = 1 << 4, FlagVirtual = 1 << 5, FlagArtificial = 1 << 6, FlagExplicit = 1 << 7,   FlagPrototyped = 1 << 8, FlagObjcClassComplete = 1 << 9, FlagObjectPointer = 1 << 10, FlagVector = 1 << 11,   FlagStaticMember = 1 << 12, FlagIndirectVariable = 1 << 13 }
Protected Member Functions inherited from llvm::DIScope
void	printInternal (raw_ostream &OS) const
Protected Member Functions inherited from llvm::DIDescriptor
StringRef	getStringField (unsigned Elt) const
unsigned	getUnsignedField (unsigned Elt) const
uint64_t	getUInt64Field (unsigned Elt) const
int64_t	getInt64Field (unsigned Elt) const
DIDescriptor	getDescriptorField (unsigned Elt) const
template<typename DescTy >
DescTy	getFieldAs (unsigned Elt) const
GlobalVariable *	getGlobalVariableField (unsigned Elt) const
Constant *	getConstantField (unsigned Elt) const
Function *	getFunctionField (unsigned Elt) const
void	replaceFunctionField (unsigned Elt, Function *F)
template<>
DIScopeRef	getFieldAs (unsigned Elt) const
	Specialize getFieldAs to handle fields that are references to DIScopes. More...
template<>
DITypeRef	getFieldAs (unsigned Elt) const
	Specialize getFieldAs to handle fields that are references to DITypes. More...
template<>
DIScopeRef	getFieldAs (unsigned Elt) const
	Specialize getFieldAs to handle fields that are references to DIScopes. More...
template<>
DITypeRef	getFieldAs (unsigned Elt) const
	Specialize getFieldAs to handle fields that are references to DITypes. More...
Protected Attributes inherited from llvm::DIDescriptor
const MDNode *	DbgNode

Detailed Description

DIFile - This is a wrapper for a file.

Definition at line 392 of file DebugInfo.h.

Constructor & Destructor Documentation

llvm::DIFile::DIFile ( const MDNode *  N = 0 )

inlineexplicit

Definition at line 396 of file DebugInfo.h.

Member Function Documentation

MDNode * DIFile::getFileNode

(

)

const

Retrieve the MDNode for the directory/file pair.

Definition at line 575 of file DebugInfo.cpp.

References getNodeField().

Referenced by llvm::DIBuilder::createClassType(), llvm::DIBuilder::createEnumerationType(), llvm::DIBuilder::createForwardDecl(), llvm::DIBuilder::createFunction(), llvm::DIBuilder::createLexicalBlock(), llvm::DIBuilder::createLexicalBlockFile(), llvm::DIBuilder::createMemberType(), llvm::DIBuilder::createMethod(), llvm::DIBuilder::createNameSpace(), llvm::DIBuilder::createObjCIVar(), llvm::DIBuilder::createStaticMemberType(), llvm::DIBuilder::createStructType(), llvm::DIBuilder::createTypedef(), and llvm::DIBuilder::createUnionType().

bool DIFile::Verify

(

)

const

Verify that the file descriptor is well formed.

Definition at line 578 of file DebugInfo.cpp.

Referenced by llvm::DIDescriptor::Verify().

Friends And Related Function Documentation

friend class DIDescriptor

friend

Definition at line 393 of file DebugInfo.h.

---

The documentation for this class was generated from the following files:

• DebugInfo.h
• DebugInfo.cpp
