llvm::MCAlignFragment Class Reference

#include <MCAssembler.h>

Inheritance diagram for llvm::MCAlignFragment:
Inheritance graph
[legend]
Collaboration diagram for llvm::MCAlignFragment:
Collaboration graph
[legend]

Public Member Functions

 MCAlignFragment (unsigned _Alignment, int64_t _Value, unsigned _ValueSize, unsigned _MaxBytesToEmit, MCSectionData *SD=0)

Accessors
unsigned getAlignment () const

int64_t getValue () const

unsigned getValueSize () const

unsigned getMaxBytesToEmit () const

bool hasEmitNops () const

void setEmitNops (bool Value)

- Public Member Functions inherited from llvm::MCFragment
 MCFragment ()

virtual ~MCFragment ()

FragmentType getKind () const

MCSectionDatagetParent () const

void setParent (MCSectionData *Value)

MCSymbolDatagetAtom () const

void setAtom (MCSymbolData *Value)

unsigned getLayoutOrder () const

void setLayoutOrder (unsigned Value)

virtual bool hasInstructions () const
 Does this fragment have instructions emitted into it? By default this is false, but specific fragment types may set it to true. More...

virtual bool alignToBundleEnd () const
 Should this fragment be placed at the end of an aligned bundle? More...

virtual void setAlignToBundleEnd (bool V)

virtual uint8_t getBundlePadding () const
 Get the padding size that must be inserted before this fragment. Used for bundling. By default, no padding is inserted. Note that padding size is restricted to 8 bits. This is an optimization to reduce the amount of space used for each fragment. In practice, larger padding should never be required. More...

virtual void setBundlePadding (uint8_t N)
 Set the padding size for this fragment. By default it's a no-op, and only some fragments have a meaningful implementation. More...

void dump ()

- Public Member Functions inherited from llvm::ilist_node< MCFragment >
MCFragmentgetPrevNode ()
 Get the previous node, or 0 for the list head. More...

const MCFragmentgetPrevNode () const
 Get the previous node, or 0 for the list head. More...

MCFragmentgetNextNode ()
 Get the next node, or 0 for the list tail. More...

const MCFragmentgetNextNode () const
 Get the next node, or 0 for the list tail. More...


Static Public Member Functions

static bool classof (const MCFragment *F)


Additional Inherited Members

- Public Types inherited from llvm::MCFragment
enum  FragmentType {
  FT_Align, FT_Data, FT_CompactEncodedInst, FT_Fill,
  FT_Relaxable, FT_Org, FT_Dwarf, FT_DwarfFrame,
  FT_LEB
}

- Protected Member Functions inherited from llvm::MCFragment
 MCFragment (FragmentType _Kind, MCSectionData *_Parent=0)

- Protected Member Functions inherited from llvm::ilist_node< MCFragment >
 ilist_node ()


Detailed Description

Definition at line 329 of file MCAssembler.h.

Constructor & Destructor Documentation

llvm::MCAlignFragment::MCAlignFragment ( unsigned  _Alignment,
int64_t  _Value,
unsigned  _ValueSize,
unsigned  _MaxBytesToEmit,
MCSectionData SD = 0
)
inline

Definition at line 351 of file MCAssembler.h.

Member Function Documentation

static bool llvm::MCAlignFragment::classof ( const MCFragment F)
inlinestatic

Definition at line 373 of file MCAssembler.h.

References llvm::MCFragment::FT_Align, and llvm::MCFragment::getKind().

unsigned llvm::MCAlignFragment::getAlignment ( ) const
inline
unsigned llvm::MCAlignFragment::getMaxBytesToEmit ( ) const
inline
int64_t llvm::MCAlignFragment::getValue ( ) const
inline

Definition at line 362 of file MCAssembler.h.

Referenced by llvm::MCFragment::dump(), and writeFragment().

unsigned llvm::MCAlignFragment::getValueSize ( ) const
inline

Definition at line 364 of file MCAssembler.h.

Referenced by llvm::MCFragment::dump(), and writeFragment().

bool llvm::MCAlignFragment::hasEmitNops ( ) const
inline
void llvm::MCAlignFragment::setEmitNops ( bool  Value)
inline

Definition at line 369 of file MCAssembler.h.


The documentation for this class was generated from the following files:
