#include <MCAssembler.h>

Inheritance diagram for llvm::MCEncodedFragment:

Collaboration diagram for llvm::MCEncodedFragment:

Public Member Functions
	MCEncodedFragment (MCFragment::FragmentType FType, MCSectionData *SD=0)

virtual	~MCEncodedFragment ()

virtual SmallVectorImpl< char > &	getContents ()=0

virtual const SmallVectorImpl < char > &	getContents () const =0

virtual uint8_t	getBundlePadding () const
	Get the padding size that must be inserted before this fragment. Used for bundling. By default, no padding is inserted. Note that padding size is restricted to 8 bits. This is an optimization to reduce the amount of space used for each fragment. In practice, larger padding should never be required. More...

virtual void	setBundlePadding (uint8_t N)
	Set the padding size for this fragment. By default it's a no-op, and only some fragments have a meaningful implementation. More...

Public Member Functions inherited from llvm::MCFragment
	MCFragment ()

virtual	~MCFragment ()

FragmentType	getKind () const

MCSectionData *	getParent () const

void	setParent (MCSectionData *Value)

MCSymbolData *	getAtom () const

void	setAtom (MCSymbolData *Value)

unsigned	getLayoutOrder () const

void	setLayoutOrder (unsigned Value)

virtual bool	hasInstructions () const
	Does this fragment have instructions emitted into it? By default this is false, but specific fragment types may set it to true. More...

virtual bool	alignToBundleEnd () const
	Should this fragment be placed at the end of an aligned bundle? More...

virtual void	setAlignToBundleEnd (bool V)

void	dump ()

Public Member Functions inherited from llvm::ilist_node< MCFragment >
MCFragment *	getPrevNode ()
	Get the previous node, or 0 for the list head. More...

const MCFragment *	getPrevNode () const
	Get the previous node, or 0 for the list head. More...

MCFragment *	getNextNode ()
	Get the next node, or 0 for the list tail. More...

const MCFragment *	getNextNode () const
	Get the next node, or 0 for the list tail. More...

Static Public Member Functions
static bool	classof (const MCFragment *F)

Additional Inherited Members
Public Types inherited from llvm::MCFragment
enum	FragmentType { FT_Align, FT_Data, FT_CompactEncodedInst, FT_Fill, FT_Relaxable, FT_Org, FT_Dwarf, FT_DwarfFrame, FT_LEB }

Protected Member Functions inherited from llvm::MCFragment
	MCFragment (FragmentType _Kind, MCSectionData *_Parent=0)

Protected Member Functions inherited from llvm::ilist_node< MCFragment >
	ilist_node ()

Detailed Description

Interface implemented by fragments that contain encoded instructions and/or data.

Definition at line 132 of file MCAssembler.h.

Constructor & Destructor Documentation

llvm::MCEncodedFragment::MCEncodedFragment	(	MCFragment::FragmentType	FType,
		MCSectionData *	SD = `0`
	)

inline

Definition at line 137 of file MCAssembler.h.

MCEncodedFragment::~MCEncodedFragment ( )

virtual

Definition at line 223 of file MCAssembler.cpp.

Member Function Documentation

static bool llvm::MCEncodedFragment::classof ( const MCFragment * F )

inlinestatic

Definition at line 154 of file MCAssembler.h.

References llvm::MCFragment::FT_CompactEncodedInst, llvm::MCFragment::FT_Data, llvm::MCFragment::FT_Relaxable, and llvm::MCFragment::getKind().

virtual uint8_t llvm::MCEncodedFragment::getBundlePadding ( ) const

inlinevirtual

Get the padding size that must be inserted before this fragment. Used for bundling. By default, no padding is inserted. Note that padding size is restricted to 8 bits. This is an optimization to reduce the amount of space used for each fragment. In practice, larger padding should never be required.

Reimplemented from llvm::MCFragment.

Definition at line 146 of file MCAssembler.h.

virtual SmallVectorImpl<char>& llvm::MCEncodedFragment::getContents ( )

pure virtual

Implemented in llvm::MCRelaxableFragment, llvm::MCCompactEncodedInstFragment, and llvm::MCDataFragment.

Referenced by llvm::MCAssembler::Finish(), and writeFragmentContents().

virtual const SmallVectorImpl<char>& llvm::MCEncodedFragment::getContents ( ) const

pure virtual

Implemented in llvm::MCRelaxableFragment, llvm::MCCompactEncodedInstFragment, and llvm::MCDataFragment.

virtual void llvm::MCEncodedFragment::setBundlePadding ( uint8_t N )

inlinevirtual

Set the padding size for this fragment. By default it's a no-op, and only some fragments have a meaningful implementation.
