Symbolize using user-provided, C API, callbacks. More...

#include <MCExternalSymbolizer.h>

Inheritance diagram for llvm::MCExternalSymbolizer:

Collaboration diagram for llvm::MCExternalSymbolizer:

Public Member Functions
	MCExternalSymbolizer (MCContext &Ctx, OwningPtr< MCRelocationInfo > &RelInfo, LLVMOpInfoCallback getOpInfo, LLVMSymbolLookupCallback symbolLookUp, void *disInfo)

bool	tryAddingSymbolicOperand (MCInst &MI, raw_ostream &CommentStream, int64_t Value, uint64_t Address, bool IsBranch, uint64_t Offset, uint64_t InstSize)
	Try to add a symbolic operand instead of `Value` to the MCInst. More...

void	tryAddingPcLoadReferenceComment (raw_ostream &CommentStream, int64_t Value, uint64_t Address)
	Try to add a comment on the PC-relative load. For instance, in Mach-O, this is used to add annotations to instructions that use C string literals, as found in __cstring. More...

Public Member Functions inherited from llvm::MCSymbolizer
	MCSymbolizer (MCContext &Ctx, OwningPtr< MCRelocationInfo > &RelInfo)
	Construct an MCSymbolizer, taking ownership of `RelInfo`. More...

virtual	~MCSymbolizer ()

Additional Inherited Members
Protected Attributes inherited from llvm::MCSymbolizer
MCContext &	Ctx

OwningPtr< MCRelocationInfo >	RelInfo

Detailed Description

Symbolize using user-provided, C API, callbacks.

See llvm-c/Disassembler.h.

Definition at line 27 of file MCExternalSymbolizer.h.

Constructor & Destructor Documentation

llvm::MCExternalSymbolizer::MCExternalSymbolizer	(	MCContext &	Ctx,
		OwningPtr< MCRelocationInfo > &	RelInfo,
		LLVMOpInfoCallback	getOpInfo,
		LLVMSymbolLookupCallback	symbolLookUp,
		void *	disInfo
	)

inline

Definition at line 40 of file MCExternalSymbolizer.h.

Member Function Documentation

void MCExternalSymbolizer::tryAddingPcLoadReferenceComment	(	raw_ostream &	cStream,
		int64_t	Value,
		uint64_t	Address
	)

virtual

Try to add a comment on the PC-relative load. For instance, in Mach-O, this is used to add annotations to instructions that use C string literals, as found in __cstring.

Implements llvm::MCSymbolizer.

Definition at line 139 of file MCExternalSymbolizer.cpp.

References LLVMDisassembler_ReferenceType_In_PCrel_Load, LLVMDisassembler_ReferenceType_Out_LitPool_CstrAddr, LLVMDisassembler_ReferenceType_Out_LitPool_SymAddr, LLVMDisassembler_ReferenceType_Out_Objc_CFString_Ref, LLVMDisassembler_ReferenceType_Out_Objc_Class_Ref, LLVMDisassembler_ReferenceType_Out_Objc_Message, LLVMDisassembler_ReferenceType_Out_Objc_Message_Ref, and LLVMDisassembler_ReferenceType_Out_Objc_Selector_Ref.

bool MCExternalSymbolizer::tryAddingSymbolicOperand	(	MCInst &	Inst,
		raw_ostream &	cStream,
		int64_t	Value,
		uint64_t	Address,
		bool	IsBranch,
		uint64_t	Offset,
		uint64_t	InstSize
	)

virtual

Try to add a symbolic operand instead of Value to the MCInst.

Instead of having a difficult to read immediate, a symbolic operand would represent this immediate in a more understandable way, for instance as a symbol or an offset from a symbol. Relocations can also be used to enrich the symbolic expression.

Parameters

Inst	- The MCInst where to insert the symbolic operand.
cStream	- Stream to print comments and annotations on.
Value	- Operand value, pc-adjusted by the caller if necessary.
Address	- Load address of the instruction.
IsBranch	- Is the instruction a branch?
Offset	- Byte offset of the operand inside the inst.
InstSize	- Size of the instruction in bytes.

Returns: Whether a symbolic operand was added.

Implements llvm::MCSymbolizer.

Definition at line 31 of file MCExternalSymbolizer.cpp.

References llvm::MCInst::addOperand(), LLVMOpInfo1::AddSymbol, llvm::MCConstantExpr::Create(), llvm::MCSymbolRefExpr::Create(), llvm::MCBinaryExpr::CreateAdd(), llvm::MCOperand::CreateExpr(), llvm::MCUnaryExpr::CreateMinus(), llvm::MCBinaryExpr::CreateSub(), llvm::MCSymbolizer::Ctx, llvm::MCContext::GetOrCreateSymbol(), LLVMDisassembler_ReferenceType_In_Branch, LLVMDisassembler_ReferenceType_InOut_None, LLVMDisassembler_ReferenceType_Out_Objc_Message, LLVMDisassembler_ReferenceType_Out_SymbolStub, llvm::Intrinsic::memset, LLVMOpInfoSymbol1::Name, LLVMOpInfoSymbol1::Present, llvm::MCSymbolizer::RelInfo, LLVMOpInfo1::SubtractSymbol, LLVMOpInfoSymbol1::Value, LLVMOpInfo1::Value, and LLVMOpInfo1::VariantKind.

The documentation for this class was generated from the following files:
