llvm::MCObjectSymbolizer Class Reference

An ObjectFile-backed symbolizer. More...

#include <MCObjectSymbolizer.h>

Inheritance diagram for llvm::MCObjectSymbolizer:

Collaboration diagram for llvm::MCObjectSymbolizer:

Public Member Functions
virtual StringRef	findExternalFunctionAt (uint64_t Addr)
	Look for an external function symbol at Addr. (References through the ELF PLT, Mach-O stubs, and similar). More...
Overridden MCSymbolizer methods:
bool	tryAddingSymbolicOperand (MCInst &MI, raw_ostream &cStream, int64_t Value, uint64_t Address, bool IsBranch, uint64_t Offset, uint64_t InstSize)
	Try to add a symbolic operand instead of Value to the MCInst. More...
void	tryAddingPcLoadReferenceComment (raw_ostream &cStream, int64_t Value, uint64_t Address)
	Try to add a comment on the PC-relative load. For instance, in Mach-O, this is used to add annotations to instructions that use C string literals, as found in __cstring. More...
Public Member Functions inherited from llvm::MCSymbolizer
	MCSymbolizer (MCContext &Ctx, OwningPtr< MCRelocationInfo > &RelInfo)
	Construct an MCSymbolizer, taking ownership of RelInfo. More...
virtual	~MCSymbolizer ()

Static Public Member Functions
static MCObjectSymbolizer *	createObjectSymbolizer (MCContext &Ctx, OwningPtr< MCRelocationInfo > &RelInfo, const object::ObjectFile *Obj)
	Create an object symbolizer for Obj. More...

Protected Member Functions
const object::RelocationRef *	findRelocationAt (uint64_t Addr)
const object::SectionRef *	findSectionContaining (uint64_t Addr)
	MCObjectSymbolizer (MCContext &Ctx, OwningPtr< MCRelocationInfo > &RelInfo, const object::ObjectFile *Obj)

Protected Attributes
const object::ObjectFile *	Obj
Protected Attributes inherited from llvm::MCSymbolizer
MCContext &	Ctx
OwningPtr< MCRelocationInfo >	RelInfo

Detailed Description

An ObjectFile-backed symbolizer.

Definition at line 31 of file MCObjectSymbolizer.h.

Constructor & Destructor Documentation

MCObjectSymbolizer::MCObjectSymbolizer ( MCContext &  Ctx, OwningPtr< MCRelocationInfo > &  RelInfo, const object::ObjectFile *  Obj  )

protected

Definition at line 128 of file MCObjectSymbolizer.cpp.

Referenced by createObjectSymbolizer().

Member Function Documentation

MCObjectSymbolizer * MCObjectSymbolizer::createObjectSymbolizer ( MCContext &  Ctx, OwningPtr< MCRelocationInfo > &  RelInfo, const object::ObjectFile *  Obj  )

static

Create an object symbolizer for Obj.

Definition at line 199 of file MCObjectSymbolizer.cpp.

References MCObjectSymbolizer().

StringRef MCObjectSymbolizer::findExternalFunctionAt ( uint64_t  Addr )

virtual

Look for an external function symbol at Addr. (References through the ELF PLT, Mach-O stubs, and similar).

Returns

An MCExpr representing the external symbol, or 0 if not found.

Definition at line 194 of file MCObjectSymbolizer.cpp.

Referenced by llvm::MCObjectDisassembler::createFunction(), and tryAddingSymbolicOperand().

const RelocationRef * MCObjectSymbolizer::findRelocationAt ( uint64_t  Addr )

protected

Definition at line 231 of file MCObjectSymbolizer.cpp.

References llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::empty(), llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::end(), and llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::find().

Referenced by tryAddingSymbolicOperand().

const SectionRef * MCObjectSymbolizer::findSectionContaining ( uint64_t  Addr )

protected

Definition at line 214 of file MCObjectSymbolizer.cpp.

References SectionStartsBefore().

void MCObjectSymbolizer::tryAddingPcLoadReferenceComment ( raw_ostream &  cStream, int64_t  Value, uint64_t  Address  )

virtual

Try to add a comment on the PC-relative load. For instance, in Mach-O, this is used to add annotations to instructions that use C string literals, as found in __cstring.

Implements llvm::MCSymbolizer.

Definition at line 190 of file MCObjectSymbolizer.cpp.

bool MCObjectSymbolizer::tryAddingSymbolicOperand ( MCInst &  Inst, raw_ostream &  cStream, int64_t  Value, uint64_t  Address, bool  IsBranch, uint64_t  Offset, uint64_t  InstSize  )

virtual

Try to add a symbolic operand instead of Value to the MCInst.

Instead of having a difficult to read immediate, a symbolic operand would represent this immediate in a more understandable way, for instance as a symbol or an offset from a symbol. Relocations can also be used to enrich the symbolic expression.

Parameters

Inst	- The MCInst where to insert the symbolic operand.
cStream	- Stream to print comments and annotations on.
Value	- Operand value, pc-adjusted by the caller if necessary.
Address	- Load address of the instruction.
IsBranch	- Is the instruction a branch?
Offset	- Byte offset of the operand inside the inst.
InstSize	- Size of the instruction in bytes.

Returns

Whether a symbolic operand was added.

Implements llvm::MCSymbolizer.

Definition at line 135 of file MCObjectSymbolizer.cpp.

References llvm::MCInst::addOperand(), llvm::object::ObjectFile::begin_symbols(), llvm::MCConstantExpr::Create(), llvm::MCSymbolRefExpr::Create(), llvm::MCBinaryExpr::CreateAdd(), llvm::MCOperand::CreateExpr(), llvm::MCRelocationInfo::createExprForRelocation(), llvm::StringRef::empty(), llvm::object::ObjectFile::end_symbols(), findExternalFunctionAt(), findRelocationAt(), llvm::MCContext::GetOrCreateSymbol(), llvm::object::content_iterator< content_type >::increment(), Obj, llvm::object::SymbolRef::ST_Function, and llvm::object::UnknownAddressOrSize.

Member Data Documentation

const object::ObjectFile* llvm::MCObjectSymbolizer::Obj

protected

Definition at line 33 of file MCObjectSymbolizer.h.

Referenced by tryAddingSymbolicOperand().

---

The documentation for this class was generated from the following files:

• MCObjectSymbolizer.h
• MCObjectSymbolizer.cpp
