llvm::MCTargetStreamer Class Reference

#include <MCStreamer.h>

Inheritance diagram for llvm::MCTargetStreamer:

Collaboration diagram for llvm::MCTargetStreamer:

Public Member Functions
virtual	~MCTargetStreamer ()
void	setStreamer (MCStreamer *S)

Protected Attributes
MCStreamer *	Streamer

Detailed Description

Target specific streamer interface. This is used so that targets can implement support for target specific assembly directives.

If target foo wants to use this, it should implement 3 classes:

• FooTargetStreamer : public MCTargetStreamer
• FooTargetAsmSreamer : public FooTargetStreamer
• FooTargetELFStreamer : public FooTargetStreamer

FooTargetStreamer should have a pure virtual method for each directive. For example, for a ".bar symbol_name" directive, it should have virtual emitBar(const MCSymbol &Symbol) = 0;

The FooTargetAsmSreamer and FooTargetELFStreamer classes implement the method. The assembly streamer just prints ".bar symbol_name". The object streamer does whatever is needed to implement .bar in the object file.

In the assembly printer and parser the target streamer can be used by calling getTargetStreamer and casting it to FooTargetStreamer:

MCTargetStreamer &TS = OutStreamer.getTargetStreamer(); FooTargetStreamer &ATS = static_cast<FooTargetStreamer &>(TS);

The base classes FooTargetAsmSreamer and FooTargetELFStreamer should never be treated differently. Callers should always talk to a FooTargetStreamer.

Definition at line 67 of file MCStreamer.h.

Constructor & Destructor Documentation

MCTargetStreamer::~MCTargetStreamer ( )

virtual

Definition at line 26 of file MCStreamer.cpp.

Member Function Documentation

void llvm::MCTargetStreamer::setStreamer ( MCStreamer *  S )

inline

Definition at line 73 of file MCStreamer.h.

References Streamer.

Referenced by llvm::MCStreamer::MCStreamer().

Member Data Documentation

MCStreamer* llvm::MCTargetStreamer::Streamer

protected

Definition at line 69 of file MCStreamer.h.

Referenced by setStreamer().

---

The documentation for this class was generated from the following files:

• MCStreamer.h
• MCStreamer.cpp
