llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT > Class Template Reference

#include <SparseMultiSet.h>

Inheritance diagram for llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >:

Collaboration diagram for llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >:

Classes
class	iterator_base

Public Types
typedef ValueT	value_type
typedef ValueT &	reference
typedef const ValueT &	const_reference
typedef ValueT *	pointer
typedef const ValueT *	const_pointer
typedef iterator_base < SparseMultiSet * >	iterator
typedef iterator_base< const SparseMultiSet * >	const_iterator
typedef std::pair< iterator, iterator >	RangePair

Public Member Functions
	SparseMultiSet ()
	~SparseMultiSet ()
void	setUniverse (unsigned U)
iterator	end ()
const_iterator	end () const
bool	empty () const
unsigned	size () const
void	clear ()
iterator	findIndex (unsigned Idx)
iterator	find (const KeyT &Key)
const_iterator	find (const KeyT &Key) const
unsigned	count (const KeyT &Key) const
bool	contains (const KeyT &Key) const
	Returns true if this set contains an element identified by Key. More...
iterator	getHead (const KeyT &Key)
	Return the head and tail of the subset's list, otherwise returns end(). More...
iterator	getTail (const KeyT &Key)
RangePair	equal_range (const KeyT &K)
iterator	insert (const ValueT &Val)
*	if (test(I))*break
**iterator	erase (iterator I)
void	eraseAll (const KeyT &K)

Public Attributes
*	I = erase(I)

Detailed Description

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>
class llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >

Fast multiset implementation for objects that can be identified by small unsigned keys.

SparseMultiSet allocates memory proportional to the size of the key universe, so it is not recommended for building composite data structures. It is useful for algorithms that require a single set with fast operations.

Compared to DenseSet and DenseMap, SparseMultiSet provides constant-time fast clear() as fast as a vector. The find(), insert(), and erase() operations are all constant time, and typically faster than a hash table. The iteration order doesn't depend on numerical key values, it only depends on the order of insert() and erase() operations. Iteration order is the insertion order. Iteration is only provided over elements of equivalent keys, but iterators are bidirectional.

Compared to BitVector, SparseMultiSet<unsigned> uses 8x-40x more memory, but offers constant-time clear() and size() operations as well as fast iteration independent on the size of the universe.

SparseMultiSet contains a dense vector holding all the objects and a sparse array holding indexes into the dense vector. Most of the memory is used by the sparse array which is the size of the key universe. The SparseT template parameter provides a space/speed tradeoff for sets holding many elements.

When SparseT is uint32_t, find() only touches up to 3 cache lines, but the sparse array uses 4 x Universe bytes.

When SparseT is uint8_t (the default), find() touches up to 3+[N/256] cache lines, but the sparse array is 4x smaller. N is the number of elements in the set.

For sets that may grow to thousands of elements, SparseT should be set to uint16_t or uint32_t.

Multiset behavior is provided by providing doubly linked lists for values that are inlined in the dense vector. SparseMultiSet is a good choice when one desires a growable number of entries per key, as it will retain the SparseSet algorithmic properties despite being growable. Thus, it is often a better choice than a SparseSet of growable containers or a vector of vectors. SparseMultiSet also keeps iterators valid after erasure (provided the iterators don't point to the element erased), allowing for more intuitive and fast removal.

Template Parameters

ValueT	The type of objects in the set.
KeyFunctorT	A functor that computes an unsigned index from KeyT.
SparseT	An unsigned integer type. See above.

Definition at line 78 of file SparseMultiSet.h.

Member Typedef Documentation

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef iterator_base<const SparseMultiSet *> llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::const_iterator

Definition at line 313 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef const ValueT* llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::const_pointer

Definition at line 183 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef const ValueT& llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::const_reference

Definition at line 181 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef iterator_base<SparseMultiSet *> llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::iterator

Definition at line 312 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef ValueT* llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::pointer

Definition at line 182 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef std::pair<iterator, iterator> llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::RangePair

Definition at line 316 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef ValueT& llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::reference

Definition at line 180 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

typedef ValueT llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::value_type

Definition at line 179 of file SparseMultiSet.h.

Constructor & Destructor Documentation

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::SparseMultiSet ( )

inline

Definition at line 185 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::~SparseMultiSet ( )

inline

Definition at line 188 of file SparseMultiSet.h.

Member Function Documentation

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

void llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::clear ( )

inline

Clears the set. This is a very fast constant time operation.

Definition at line 343 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::buildSchedGraph().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

bool llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::contains ( const KeyT &  Key ) const

inline

Returns true if this set contains an element identified by Key.

Definition at line 399 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDataDeps(), llvm::ScheduleDAGInstrs::addPhysRegDeps(), and llvm::ScheduleDAGInstrs::addSchedBarrierDeps().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

unsigned llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::count ( const KeyT &  Key ) const

inline

Returns the number of elements identified by Key. This will be linear in the number of elements of that key.

Definition at line 390 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

bool llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::empty ( ) const

inline

Returns true if the set is empty.

This is not the same as BitVector::empty().

Definition at line 329 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addSchedBarrierDeps(), llvm::ScheduleDAGInstrs::buildSchedGraph(), and llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::setUniverse().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::end ( )

inline

Returns an iterator past this container. Note that such an iterator cannot be decremented, but will compare equal to other end iterators.

Definition at line 320 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDataDeps(), llvm::ScheduleDAGInstrs::addPhysRegDeps(), llvm::ScheduleDAGInstrs::addVRegUseDeps(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::contains(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::count(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::eraseAll(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::findIndex(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::getTail(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::insert(), and llvm::ScheduleDAGMI::updatePressureDiffs().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

const_iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::end ( ) const

inline

Definition at line 321 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

RangePair llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::equal_range ( const KeyT &  K )

inline

The bounds of the range of items sharing Key K. First member is the head of the list, and the second member is a decrementable end iterator for that key.

Definition at line 415 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDeps().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

* * iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::erase ( iterator  I )

inline

Definition at line 470 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDeps(), and llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::eraseAll().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

void llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::eraseAll ( const KeyT &  K )

inline

Erase all elements with the given key. This invalidates all iterators of that key.

Definition at line 486 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDeps().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::find ( const KeyT &  Key )

inline

Find an element by its key.

Parameters

Key	A valid key to find.

Returns

An iterator to the element identified by key, or end().

Definition at line 379 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDataDeps(), llvm::ScheduleDAGInstrs::addPhysRegDeps(), llvm::ScheduleDAGInstrs::addVRegUseDeps(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::contains(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::count(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::equal_range(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::eraseAll(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::getHead(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::getTail(), and llvm::ScheduleDAGMI::updatePressureDiffs().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

const_iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::find ( const KeyT &  Key ) const

inline

Definition at line 383 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::findIndex ( unsigned  Idx )

inline

Find an element by its index.

Parameters

Idx	A valid index to find.

Returns

An iterator to the element identified by key, or end().

Definition at line 355 of file SparseMultiSet.h.

Referenced by llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::find(), and llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::insert().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::getHead ( const KeyT &  Key )

inline

Return the head and tail of the subset's list, otherwise returns end().

Definition at line 404 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::getTail ( const KeyT &  Key )

inline

Definition at line 405 of file SparseMultiSet.h.

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

* llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::if

(

test(I)

)

Erases an existing element identified by a valid iterator.

This invalidates iterators pointing at the same entry, but erase() returns an iterator pointing to the next element in the subset's list. This makes it possible to erase selected elements while iterating over the subset:

tie(I, E) = Set.equal_range(Key); while (I != E) if (test(*I)) I = Set.erase(I); else ++I;

Note that if the last element in the subset list is erased, this will return an end iterator which can be decremented to get the new tail (if it exists):

tie(B, I) = Set.equal_range(Key); for (bool isBegin = B == I; !isBegin; /* empty

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

iterator llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::insert ( const ValueT &  Val )

inline

Insert a new element at the tail of the subset list. Returns an iterator to the newly added entry.

Definition at line 423 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDeps(), llvm::ScheduleDAGInstrs::addSchedBarrierDeps(), and llvm::ScheduleDAGInstrs::addVRegUseDeps().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

void llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::setUniverse ( unsigned  U )

inline

Set the universe size which determines the largest key the set can hold. The universe must be sized before any elements can be added.

Parameters

U	Universe size. All object keys must be less than U.

Definition at line 195 of file SparseMultiSet.h.

Referenced by llvm::ScheduleDAGInstrs::buildSchedGraph().

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

unsigned llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::size ( ) const

inline

Returns the number of elements in the set.

This is not the same as BitVector::size() which returns the size of the universe.

Definition at line 336 of file SparseMultiSet.h.

Referenced by llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::empty().

Member Data Documentation

template<typename ValueT, typename KeyFunctorT = llvm::identity<unsigned>, typename SparseT = uint8_t>

* llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::I = erase(I)

Definition at line 468 of file SparseMultiSet.h.

Referenced by llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::eraseAll(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::find(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::getTail(), llvm::SparseMultiSet< VReg2SUnit, VirtReg2IndexFunctor >::insert(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::iterator_base< SMSPtrTy >::operator++(), and llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::iterator_base< SMSPtrTy >::operator--().

---

The documentation for this class was generated from the following file:

• SparseMultiSet.h
