#include <SparseBitVector.h>

Inheritance diagram for llvm::SparseBitVectorElement< ElementSize >:

Collaboration diagram for llvm::SparseBitVectorElement< ElementSize >:

Public Types
enum	{ BITWORD_SIZE = sizeof(BitWord) * CHAR_BIT, BITWORDS_PER_ELEMENT = (ElementSize + BITWORD_SIZE - 1) / BITWORD_SIZE, BITS_PER_ELEMENT = ElementSize }

typedef unsigned long	BitWord

Public Member Functions
	SparseBitVectorElement (unsigned Idx)

bool	operator== (const SparseBitVectorElement &RHS) const

bool	operator!= (const SparseBitVectorElement &RHS) const

BitWord	word (unsigned Idx) const

unsigned	index () const

bool	empty () const

void	set (unsigned Idx)

bool	test_and_set (unsigned Idx)

void	reset (unsigned Idx)

bool	test (unsigned Idx) const

unsigned	count () const

int	find_first () const
	find_first - Returns the index of the first set bit. More...

int	find_next (unsigned Curr) const

bool	unionWith (const SparseBitVectorElement &RHS)

bool	intersects (const SparseBitVectorElement &RHS) const

bool	intersectWith (const SparseBitVectorElement &RHS, bool &BecameZero)

bool	intersectWithComplement (const SparseBitVectorElement &RHS, bool &BecameZero)

void	intersectWithComplement (const SparseBitVectorElement &RHS1, const SparseBitVectorElement &RHS2, bool &BecameZero)

Public Member Functions inherited from llvm::ilist_node< SparseBitVectorElement< ElementSize > >
SparseBitVectorElement < ElementSize > *	getPrevNode ()
	Get the previous node, or 0 for the list head. More...

const SparseBitVectorElement < ElementSize > *	getPrevNode () const
	Get the previous node, or 0 for the list head. More...

SparseBitVectorElement < ElementSize > *	getNextNode ()
	Get the next node, or 0 for the list tail. More...

const SparseBitVectorElement < ElementSize > *	getNextNode () const
	Get the next node, or 0 for the list tail. More...

Friends
struct	ilist_sentinel_traits< SparseBitVectorElement >

Additional Inherited Members
Protected Member Functions inherited from llvm::ilist_node< SparseBitVectorElement< ElementSize > >
	ilist_node ()

Detailed Description

template<unsigned ElementSize = 128>
struct llvm::SparseBitVectorElement< ElementSize >

SparseBitVector is an implementation of a bitvector that is sparse by only storing the elements that have non-zero bits set. In order to make this fast for the most common cases, SparseBitVector is implemented as a linked list of SparseBitVectorElements. We maintain a pointer to the last SparseBitVectorElement accessed (in the form of a list iterator), in order to make multiple in-order test/set constant time after the first one is executed. Note that using vectors to store SparseBitVectorElement's does not work out very well because it causes insertion in the middle to take enormous amounts of time with a large amount of bits. Other structures that have better worst cases for insertion in the middle (various balanced trees, etc) do not perform as well in practice as a linked list with this iterator kept up to date. They are also significantly more memory intensive.

Definition at line 44 of file SparseBitVector.h.

Member Typedef Documentation

template<unsigned ElementSize = 128>

typedef unsigned long llvm::SparseBitVectorElement< ElementSize >::BitWord

Definition at line 47 of file SparseBitVector.h.

Member Enumeration Documentation

template<unsigned ElementSize = 128>

anonymous enum

Enumerator
BITWORD_SIZE
BITWORDS_PER_ELEMENT
BITS_PER_ELEMENT

Definition at line 48 of file SparseBitVector.h.

Constructor & Destructor Documentation

template<unsigned ElementSize = 128>

llvm::SparseBitVectorElement< ElementSize >::SparseBitVectorElement ( unsigned Idx )

inlineexplicit

Definition at line 66 of file SparseBitVector.h.

References llvm::tgtok::Bits, llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT, and llvm::Intrinsic::memset.

Member Function Documentation

template<unsigned ElementSize = 128>

unsigned llvm::SparseBitVectorElement< ElementSize >::count ( ) const

inline

Definition at line 123 of file SparseBitVector.h.

References llvm::tgtok::Bits, llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT, llvm::CountPopulation_32(), llvm::CountPopulation_64(), and llvm_unreachable.

template<unsigned ElementSize = 128>

bool llvm::SparseBitVectorElement< ElementSize >::empty ( ) const

inline

Definition at line 95 of file SparseBitVector.h.

References llvm::tgtok::Bits, and llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT.

template<unsigned ElementSize = 128>

int llvm::SparseBitVectorElement< ElementSize >::find_first ( ) const

inline

find_first - Returns the index of the first set bit.

Definition at line 136 of file SparseBitVector.h.

References llvm::tgtok::Bits, llvm::SparseBitVectorElement< ElementSize >::BITWORD_SIZE, llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT, llvm::countTrailingZeros(), and llvm_unreachable.

Referenced by llvm::SparseBitVector< ElementSize >::find_first().

template<unsigned ElementSize = 128>

int llvm::SparseBitVectorElement< ElementSize >::find_next ( unsigned Curr ) const

inline

find_next - Returns the index of the next set bit starting from the "Curr" bit. Returns -1 if the next set bit is not found.

Definition at line 150 of file SparseBitVector.h.

References llvm::tgtok::Bits, llvm::SparseBitVectorElement< ElementSize >::BITS_PER_ELEMENT, llvm::SparseBitVectorElement< ElementSize >::BITWORD_SIZE, llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT, llvm::countTrailingZeros(), and llvm_unreachable.

template<unsigned ElementSize = 128>

unsigned llvm::SparseBitVectorElement< ElementSize >::index ( ) const

inline

Definition at line 91 of file SparseBitVector.h.

Referenced by llvm::SparseBitVector< ElementSize >::find_first().

template<unsigned ElementSize = 128>

bool llvm::SparseBitVectorElement< ElementSize >::intersects ( const SparseBitVectorElement< ElementSize > & RHS ) const

inline

Definition at line 197 of file SparseBitVector.h.

References llvm::tgtok::Bits, and llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT.

template<unsigned ElementSize = 128>

bool llvm::SparseBitVectorElement< ElementSize >::intersectWith	(	const SparseBitVectorElement< ElementSize > &	RHS,
		bool &	BecameZero
	)

inline

Definition at line 207 of file SparseBitVector.h.

References llvm::tgtok::Bits, and llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT.

template<unsigned ElementSize = 128>

bool llvm::SparseBitVectorElement< ElementSize >::intersectWithComplement	(	const SparseBitVectorElement< ElementSize > &	RHS,
		bool &	BecameZero
	)

inline

Definition at line 229 of file SparseBitVector.h.

References llvm::tgtok::Bits, and llvm::SparseBitVectorElement< ElementSize >::BITWORDS_PER_ELEMENT.

Referenced by llvm::SparseBitVector< ElementSize >::intersectWithComplement().

template<unsigned ElementSize = 128>

void llvm::SparseBitVectorElement< ElementSize >::intersectWithComplement	(	const SparseBitVectorElement< ElementSize > &	RHS1,
		const SparseBitVectorElement< ElementSize > &	RHS2,
		bool &	BecameZero
	)
