llvm::MCAtom Class Reference

Represents a contiguous range of either instructions (a TextAtom) or data (a DataAtom). Address ranges are expressed as closed intervals. More...

#include <MCAtom.h>

Inheritance diagram for llvm::MCAtom:

Collaboration diagram for llvm::MCAtom:

Public Types
enum	AtomKind { TextAtom, DataAtom }

Public Member Functions
virtual	~MCAtom ()
AtomKind	getKind () const
uint64_t	getBeginAddr () const
	Get the start address of the atom. More...
uint64_t	getEndAddr () const
	Get the end address, i.e. the last one inside the atom. More...
Atom modification methods:
When modifying a TextAtom, keep instruction boundaries in mind. For instance, split must me given the start address of an instruction.
virtual MCAtom *	split (uint64_t SplitPt)=0
	Splits the atom in two at a given address. More...
virtual void	truncate (uint64_t TruncPt)=0
	Truncates an atom, discarding everything after TruncPt. More...
Naming:
This is mostly for display purposes, and may contain anything that hints at what the atom contains: section or symbol name, BB start address, ..
StringRef	getName () const
void	setName (StringRef NewName)

Protected Member Functions
	MCAtom (AtomKind K, MCModule *P, uint64_t B, uint64_t E)
Atom remapping helpers
void	remap (uint64_t NewBegin, uint64_t NewEnd)
	Remap the atom, using the given range, updating Begin/End. One or both of the bounds can remain the same, but overlapping with other atoms in the module is still forbidden. More...
void	remapForTruncate (uint64_t TruncPt)
	Remap the atom to prepare for a truncation at TruncPt. Equivalent to: More...
void	remapForSplit (uint64_t SplitPt, uint64_t &LBegin, uint64_t &LEnd, uint64_t &RBegin, uint64_t &REnd)
	Remap the atom to prepare for a split at SplitPt. The bounds for the resulting atoms are returned in {L,R}{Begin,End}. The current atom is truncated to LEnd. More...

Protected Attributes
const AtomKind	Kind
std::string	Name
MCModule *	Parent
uint64_t	Begin
uint64_t	End

Friends
class	MCModule

Detailed Description

Represents a contiguous range of either instructions (a TextAtom) or data (a DataAtom). Address ranges are expressed as closed intervals.

Definition at line 34 of file MCAtom.h.

Member Enumeration Documentation

enum llvm::MCAtom::AtomKind

Enumerator
TextAtom
DataAtom

Definition at line 39 of file MCAtom.h.

Constructor & Destructor Documentation

virtual llvm::MCAtom::~MCAtom ( )

inlinevirtual

Definition at line 37 of file MCAtom.h.

llvm::MCAtom::MCAtom ( AtomKind  K, MCModule *  P, uint64_t  B, uint64_t  E  )

inlineprotected

Definition at line 78 of file MCAtom.h.

Member Function Documentation

uint64_t llvm::MCAtom::getBeginAddr ( ) const

inline

Get the start address of the atom.

Definition at line 43 of file MCAtom.h.

References Begin.

Referenced by llvm::MCBasicBlock::splitBasicBlock().

uint64_t llvm::MCAtom::getEndAddr ( ) const

inline

Get the end address, i.e. the last one inside the atom.

Definition at line 45 of file MCAtom.h.

References End.

Referenced by AtomComp(), AtomCompInv(), and llvm::MCBasicBlock::splitBasicBlock().

AtomKind llvm::MCAtom::getKind ( ) const

inline

Definition at line 40 of file MCAtom.h.

References Kind.

Referenced by llvm::MCTextAtom::classof(), and llvm::MCDataAtom::classof().

StringRef llvm::MCAtom::getName ( ) const

inline

Definition at line 67 of file MCAtom.h.

References Name.

Referenced by llvm::MCTextAtom::split(), and llvm::MCDataAtom::split().

void MCAtom::remap ( uint64_t  NewBegin, uint64_t  NewEnd  )

protected

Remap the atom, using the given range, updating Begin/End. One or both of the bounds can remain the same, but overlapping with other atoms in the module is still forbidden.

Definition at line 20 of file MCAtom.cpp.

References Parent.

Referenced by llvm::MCDataAtom::addData(), llvm::MCTextAtom::addInst(), remapForSplit(), and remapForTruncate().

void MCAtom::remapForSplit ( uint64_t  SplitPt, uint64_t &  LBegin, uint64_t &  LEnd, uint64_t &  RBegin, uint64_t &  REnd  )

protected

Remap the atom to prepare for a split at SplitPt. The bounds for the resulting atoms are returned in {L,R}{Begin,End}. The current atom is truncated to LEnd.

Definition at line 30 of file MCAtom.cpp.

References Begin, End, and remap().

Referenced by llvm::MCTextAtom::split(), and llvm::MCDataAtom::split().

void MCAtom::remapForTruncate ( uint64_t  TruncPt )

protected

Remap the atom to prepare for a truncation at TruncPt. Equivalent to:

// Bound checks
remap(Begin, TruncPt);

Definition at line 24 of file MCAtom.cpp.

References Begin, End, and remap().

Referenced by llvm::MCTextAtom::truncate(), and llvm::MCDataAtom::truncate().

void llvm::MCAtom::setName ( StringRef  NewName )

inline

Definition at line 68 of file MCAtom.h.

References Name, and llvm::StringRef::str().

Referenced by llvm::MCTextAtom::split(), and llvm::MCDataAtom::split().

virtual MCAtom* llvm::MCAtom::split ( uint64_t  SplitPt )

pure virtual

Splits the atom in two at a given address.

Parameters

SplitPt

Address at which to start a new atom, splitting this one.

Returns

The newly created atom starting at SplitPt.

Implemented in llvm::MCDataAtom, and llvm::MCTextAtom.

virtual void llvm::MCAtom::truncate ( uint64_t  TruncPt )

pure virtual

Truncates an atom, discarding everything after TruncPt.

Parameters

TruncPt

Last byte address to be contained in this atom.

Implemented in llvm::MCDataAtom, and llvm::MCTextAtom.

Friends And Related Function Documentation

friend class MCModule

friend

Definition at line 77 of file MCAtom.h.

Member Data Documentation

uint64_t llvm::MCAtom::Begin

protected

Definition at line 75 of file MCAtom.h.

Referenced by llvm::MCDataAtom::addData(), llvm::MCTextAtom::addInst(), getBeginAddr(), remapForSplit(), remapForTruncate(), and llvm::MCDataAtom::truncate().

uint64_t llvm::MCAtom::End

protected

Definition at line 75 of file MCAtom.h.

Referenced by llvm::MCDataAtom::addData(), llvm::MCTextAtom::addInst(), getEndAddr(), remapForSplit(), and remapForTruncate().

const AtomKind llvm::MCAtom::Kind

protected

Definition at line 72 of file MCAtom.h.

Referenced by getKind().

std::string llvm::MCAtom::Name

protected

Definition at line 73 of file MCAtom.h.

Referenced by getName(), and setName().

MCModule* llvm::MCAtom::Parent

protected

Definition at line 74 of file MCAtom.h.

Referenced by remap(), llvm::MCTextAtom::split(), and llvm::MCDataAtom::split().

---

The documentation for this class was generated from the following files:

• MCAtom.h
• MCAtom.cpp
