llvm::MCDataAtom Class Reference

An atom consising of a sequence of bytes. More...

#include <MCAtom.h>

Inheritance diagram for llvm::MCDataAtom:

Collaboration diagram for llvm::MCDataAtom:

Public Member Functions
void	addData (const MCData &D)
	Append a data entry, expanding the atom if necessary. More...
ArrayRef< MCData >	getData () const
	Get a reference to the data in this atom. More...
Atom type specific split/truncate logic.
MCDataAtom *	split (uint64_t SplitPt) LLVM_OVERRIDE
	Splits the atom in two at a given address. More...
void	truncate (uint64_t TruncPt) LLVM_OVERRIDE
	Truncates an atom, discarding everything after TruncPt. More...
Public Member Functions inherited from llvm::MCAtom
virtual	~MCAtom ()
AtomKind	getKind () const
uint64_t	getBeginAddr () const
	Get the start address of the atom. More...
uint64_t	getEndAddr () const
	Get the end address, i.e. the last one inside the atom. More...
StringRef	getName () const
void	setName (StringRef NewName)

Static Public Member Functions
static bool	classof (const MCAtom *A)

Friends
class	MCModule

Additional Inherited Members
Public Types inherited from llvm::MCAtom
enum	AtomKind { TextAtom, DataAtom }
Protected Member Functions inherited from llvm::MCAtom
	MCAtom (AtomKind K, MCModule *P, uint64_t B, uint64_t E)
void	remap (uint64_t NewBegin, uint64_t NewEnd)
	Remap the atom, using the given range, updating Begin/End. One or both of the bounds can remain the same, but overlapping with other atoms in the module is still forbidden. More...
void	remapForTruncate (uint64_t TruncPt)
	Remap the atom to prepare for a truncation at TruncPt. Equivalent to: More...
void	remapForSplit (uint64_t SplitPt, uint64_t &LBegin, uint64_t &LEnd, uint64_t &RBegin, uint64_t &REnd)
	Remap the atom to prepare for a split at SplitPt. The bounds for the resulting atoms are returned in {L,R}{Begin,End}. The current atom is truncated to LEnd. More...
Protected Attributes inherited from llvm::MCAtom
const AtomKind	Kind
std::string	Name
MCModule *	Parent
uint64_t	Begin
uint64_t	End

Detailed Description

An atom consising of a sequence of bytes.

Definition at line 170 of file MCAtom.h.

Member Function Documentation

void MCDataAtom::addData

(

const MCData &

D

)

Append a data entry, expanding the atom if necessary.

Definition at line 48 of file MCAtom.cpp.

References llvm::MCAtom::Begin, llvm::MCAtom::End, and llvm::MCAtom::remap().

static bool llvm::MCDataAtom::classof ( const MCAtom *  A )

inlinestatic

Definition at line 187 of file MCAtom.h.

References llvm::MCAtom::DataAtom, and llvm::MCAtom::getKind().

ArrayRef<MCData> llvm::MCDataAtom::getData ( ) const

inline

Get a reference to the data in this atom.

Definition at line 178 of file MCAtom.h.

MCDataAtom * MCDataAtom::split ( uint64_t  SplitPt )

virtual

Splits the atom in two at a given address.

Parameters

SplitPt

Address at which to start a new atom, splitting this one.

Returns

The newly created atom starting at SplitPt.

Implements llvm::MCAtom.

Definition at line 60 of file MCAtom.cpp.

References llvm::MCModule::createDataAtom(), llvm::MCAtom::getName(), I, llvm::MCAtom::Parent, llvm::MCAtom::remapForSplit(), and llvm::MCAtom::setName().

void MCDataAtom::truncate ( uint64_t  TruncPt )

virtual

Truncates an atom, discarding everything after TruncPt.

Parameters

TruncPt

Last byte address to be contained in this atom.

Implements llvm::MCAtom.

Definition at line 54 of file MCAtom.cpp.

References llvm::MCAtom::Begin, and llvm::MCAtom::remapForTruncate().

Friends And Related Function Documentation

friend class MCModule

friend

Definition at line 189 of file MCAtom.h.

---

The documentation for this class was generated from the following files:

• MCAtom.h
• MCAtom.cpp
