llvm::MCMachOObjectDisassembler Class Reference

#include <MCObjectDisassembler.h>

Inheritance diagram for llvm::MCMachOObjectDisassembler:

Collaboration diagram for llvm::MCMachOObjectDisassembler:

Public Member Functions
	MCMachOObjectDisassembler (const object::MachOObjectFile &MOOF, const MCDisassembler &Dis, const MCInstrAnalysis &MIA, uint64_t VMAddrSlide, uint64_t HeaderLoadAddress)
	Construct a Mach-O specific object disassembler. More...
Public Member Functions inherited from llvm::MCObjectDisassembler
	MCObjectDisassembler (const object::ObjectFile &Obj, const MCDisassembler &Dis, const MCInstrAnalysis &MIA)
virtual	~MCObjectDisassembler ()
MCModule *	buildModule (bool withCFG=false)
	Build an MCModule, creating atoms and optionally functions. More...
MCModule *	buildEmptyModule ()
MCFunction *	createFunction (MCModule *Module, uint64_t BeginAddr, AddressSetTy &CallTargets, AddressSetTy &TailCallTargets)
void	setFallbackRegion (OwningPtr< MemoryObject > &Region)
	Set the region on which to fallback if disassembly was requested somewhere not accessible in the object file. This is used for dynamic disassembly (see RawMemoryObject). More...
void	setSymbolizer (MCObjectSymbolizer *ObjectSymbolizer)
	Set the symbolizer to use to get information on external functions. Note that this isn't used to do instruction-level symbolization (that is, plugged into MCDisassembler), but to symbolize function call targets. More...

Protected Member Functions
uint64_t	getEffectiveLoadAddr (uint64_t Addr) LLVM_OVERRIDE
uint64_t	getOriginalLoadAddr (uint64_t EffectiveAddr) LLVM_OVERRIDE
	Compute the original load address, as specified in the objectfile. This is the inverse of getEffectiveLoadAddr. More...
uint64_t	getEntrypoint () LLVM_OVERRIDE
	Get the effective address of the entrypoint, or 0 if there is none. More...
ArrayRef< uint64_t >	getStaticInitFunctions () LLVM_OVERRIDE
ArrayRef< uint64_t >	getStaticExitFunctions () LLVM_OVERRIDE
Protected Member Functions inherited from llvm::MCObjectDisassembler
MemoryObject *	getRegionFor (uint64_t Addr)
	Return a memory region suitable for reading starting at Addr. In most cases, this returns a StringRefMemoryObject backed by the containing section. When no section was found, this returns the FallbackRegion, if it is suitable. If it is not, or if there is no fallback region, this returns 0. More...

Additional Inherited Members
Public Types inherited from llvm::MCObjectDisassembler
typedef std::vector< uint64_t >	AddressSetTy
Protected Attributes inherited from llvm::MCObjectDisassembler
const object::ObjectFile &	Obj
const MCDisassembler &	Dis
const MCInstrAnalysis &	MIA
MCObjectSymbolizer *	MOS
OwningPtr< MemoryObject >	FallbackRegion
	The fallback memory region, outside the object file. More...

Detailed Description

Definition at line 143 of file MCObjectDisassembler.h.

Constructor & Destructor Documentation

MCMachOObjectDisassembler::MCMachOObjectDisassembler	(	const object::MachOObjectFile &	MOOF,
		const MCDisassembler &	Dis,
		const MCInstrAnalysis &	MIA,
		uint64_t	VMAddrSlide,
		uint64_t	HeaderLoadAddress
	)

Construct a Mach-O specific object disassembler.

Parameters

VMAddrSlide	The virtual address slide applied by dyld.
HeaderLoadAddress	The load address of the mach_header for this object.

Definition at line 502 of file MCObjectDisassembler.cpp.

References llvm::object::MachOObjectFile::begin_sections(), llvm::dbgs(), DEBUG, llvm::object::MachOObjectFile::end_sections(), and llvm::object::content_iterator< content_type >::increment().

Member Function Documentation

uint64_t MCMachOObjectDisassembler::getEffectiveLoadAddr ( uint64_t  Addr )

protectedvirtual

Reimplemented from llvm::MCObjectDisassembler.

Definition at line 528 of file MCObjectDisassembler.cpp.

uint64_t MCMachOObjectDisassembler::getEntrypoint ( )

protectedvirtual

Get the effective address of the entrypoint, or 0 if there is none.

Reimplemented from llvm::MCObjectDisassembler.

Definition at line 537 of file MCObjectDisassembler.cpp.

References llvm::object::MachOObjectFile::LoadCommandInfo::C, llvm::MachO::load_command::cmd, llvm::MCObjectDisassembler::getEntrypoint(), llvm::object::MachOObjectFile::getFirstLoadCommandInfo(), llvm::object::MachOObjectFile::getHeader(), llvm::object::MachOObjectFile::getNextLoadCommandInfo(), I, llvm::SPII::Load, llvm::MachO::mach_header::ncmds, and llvm::object::MachOObjectFile::LoadCommandInfo::Ptr.

uint64_t MCMachOObjectDisassembler::getOriginalLoadAddr ( uint64_t  EffectiveAddr )

protectedvirtual

Compute the original load address, as specified in the objectfile. This is the inverse of getEffectiveLoadAddr.

Reimplemented from llvm::MCObjectDisassembler.

Definition at line 533 of file MCObjectDisassembler.cpp.

ArrayRef< uint64_t > MCMachOObjectDisassembler::getStaticExitFunctions ( )

protectedvirtual

Reimplemented from llvm::MCObjectDisassembler.

Definition at line 576 of file MCObjectDisassembler.cpp.

References llvm::StringRef::data(), llvm::object::MachOObjectFile::is64Bit(), and llvm::StringRef::size().

ArrayRef< uint64_t > MCMachOObjectDisassembler::getStaticInitFunctions ( )

protectedvirtual

Reimplemented from llvm::MCObjectDisassembler.

Definition at line 566 of file MCObjectDisassembler.cpp.

References llvm::StringRef::data(), llvm::object::MachOObjectFile::is64Bit(), and llvm::StringRef::size().

---

The documentation for this class was generated from the following files:

• MCObjectDisassembler.h
• MCObjectDisassembler.cpp
