llvm::RelocationEntry Class Reference

#include <RuntimeDyldImpl.h>

Collaboration diagram for llvm::RelocationEntry:

Public Member Functions
	RelocationEntry (unsigned id, uint64_t offset, uint32_t type, int64_t addend)
	RelocationEntry (unsigned id, uint64_t offset, uint32_t type, int64_t addend, uint64_t symoffset)
	RelocationEntry (unsigned id, uint64_t offset, uint32_t type, int64_t addend, bool IsPCRel, unsigned Size)

Public Attributes
unsigned	SectionID
	SectionID - the section this relocation points to. More...
uint64_t	Offset
	Offset - offset into the section. More...
uint32_t	RelType
	RelType - relocation type. More...
int64_t	Addend
uint64_t	SymOffset
bool	IsPCRel
	True if this is a PCRel relocation (MachO specific). More...
unsigned	Size
	The size of this relocation (MachO specific). More...

Detailed Description

RelocationEntry - used to represent relocations internally in the dynamic linker.

Definition at line 78 of file RuntimeDyldImpl.h.

Constructor & Destructor Documentation

llvm::RelocationEntry::RelocationEntry ( unsigned  id, uint64_t  offset, uint32_t  type, int64_t  addend  )

inline

Definition at line 103 of file RuntimeDyldImpl.h.

llvm::RelocationEntry::RelocationEntry ( unsigned  id, uint64_t  offset, uint32_t  type, int64_t  addend, uint64_t  symoffset  )

inline

Definition at line 107 of file RuntimeDyldImpl.h.

llvm::RelocationEntry::RelocationEntry ( unsigned  id, uint64_t  offset, uint32_t  type, int64_t  addend, bool  IsPCRel, unsigned  Size  )

inline

Definition at line 112 of file RuntimeDyldImpl.h.

Member Data Documentation

int64_t llvm::RelocationEntry::Addend

Addend - the relocation addend encoded in the instruction itself. Also used to make a relocation section relative instead of symbol relative.

Definition at line 91 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldImpl::addRelocationForSymbol(), llvm::RuntimeDyldMachO::resolveRelocation(), and llvm::RuntimeDyldELF::resolveRelocation().

bool llvm::RelocationEntry::IsPCRel

True if this is a PCRel relocation (MachO specific).

Definition at line 98 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldMachO::resolveRelocation().

uint64_t llvm::RelocationEntry::Offset

Offset - offset into the section.

Definition at line 84 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldMachO::resolveRelocation(), and llvm::RuntimeDyldELF::resolveRelocation().

uint32_t llvm::RelocationEntry::RelType

RelType - relocation type.

Definition at line 87 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldMachO::resolveRelocation(), and llvm::RuntimeDyldELF::resolveRelocation().

unsigned llvm::RelocationEntry::SectionID

SectionID - the section this relocation points to.

Definition at line 81 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldMachO::resolveRelocation(), llvm::RuntimeDyldELF::resolveRelocation(), and llvm::RuntimeDyldImpl::resolveRelocationList().

unsigned llvm::RelocationEntry::Size

The size of this relocation (MachO specific).

Definition at line 101 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldMachO::resolveRelocation().

uint64_t llvm::RelocationEntry::SymOffset

SymOffset - Section offset of the relocation entry's symbol (used for GOT lookup).

Definition at line 95 of file RuntimeDyldImpl.h.

Referenced by llvm::RuntimeDyldELF::resolveRelocation().

---

The documentation for this class was generated from the following file:

• RuntimeDyldImpl.h
