llvm::detail::PtrUseVisitorBase Class Reference

Implementation of non-dependent functionality for PtrUseVisitor. More...

#include <PtrUseVisitor.h>

Inheritance diagram for llvm::detail::PtrUseVisitorBase:

Collaboration diagram for llvm::detail::PtrUseVisitorBase:

Classes
class	PtrInfo
	This class provides information about the result of a visit. More...
struct	UseToVisit
	A struct of the data needed to visit a particular use. More...

Protected Member Functions
	PtrUseVisitorBase (const DataLayout &DL)
void	enqueueUsers (Instruction &I)
	Enqueue the users of this instruction in the visit worklist. More...
bool	adjustOffsetForGEP (GetElementPtrInst &GEPI)
	Walk the operands of a GEP and adjust the offset as appropriate. More...

Protected Attributes
const DataLayout &	DL
Visitation infrastructure
PtrInfo	PI
	The info collected about the pointer being visited thus far. More...
SmallVector< UseToVisit, 8 >	Worklist
	The worklist of to-visit uses. More...
SmallPtrSet< Use *, 8 >	VisitedUses
	A set of visited uses to break cycles in unreachable code. More...
Per-visit state
This state is reset for each instruction visited.
Use *	U
	The use currently being visited. More...
bool	IsOffsetKnown
	True if we have a known constant offset for the use currently being visited. More...
APInt	Offset
	The constant offset of the use if that is known. More...

Detailed Description

Implementation of non-dependent functionality for PtrUseVisitor.

See PtrUseVisitor for the public interface and detailed comments about usage. This class is just a helper base class which is not templated and contains all common code to be shared between different instantiations of PtrUseVisitor.

Definition at line 42 of file PtrUseVisitor.h.

Constructor & Destructor Documentation

llvm::detail::PtrUseVisitorBase::PtrUseVisitorBase ( const DataLayout &  DL )

inlineprotected

Note that the constructor is protected because this class must be a base class, we can't create instances directly of this class.

Definition at line 151 of file PtrUseVisitor.h.

Member Function Documentation

bool detail::PtrUseVisitorBase::adjustOffsetForGEP ( GetElementPtrInst &  GEPI )

protected

Walk the operands of a GEP and adjust the offset as appropriate.

This routine does the heavy lifting of the pointer walk by computing offsets and looking through GEPs.

Definition at line 31 of file PtrUseVisitor.cpp.

References llvm::GetElementPtrInst::accumulateConstantOffset(), DL, IsOffsetKnown, and Offset.

Referenced by llvm::PtrUseVisitor< SliceBuilder >::visitGetElementPtrInst().

void detail::PtrUseVisitorBase::enqueueUsers ( Instruction &  I )

protected

Enqueue the users of this instruction in the visit worklist.

This will visit the users with the same offset of the current visit (including an unknown offset if that is the current state).

Definition at line 18 of file PtrUseVisitor.cpp.

References IsOffsetKnown, llvm_move, Offset, llvm::Value::use_begin(), llvm::Value::use_end(), VisitedUses, and Worklist.

Referenced by llvm::PtrUseVisitor< SliceBuilder >::visitBitCastInst(), llvm::PtrUseVisitor< SliceBuilder >::visitGetElementPtrInst(), and llvm::PtrUseVisitor< SliceBuilder >::visitPtr().

Member Data Documentation

const DataLayout& llvm::detail::PtrUseVisitorBase::DL

protected

Definition at line 105 of file PtrUseVisitor.h.

Referenced by adjustOffsetForGEP(), and llvm::PtrUseVisitor< SliceBuilder >::visitPtr().

bool llvm::detail::PtrUseVisitorBase::IsOffsetKnown

protected

True if we have a known constant offset for the use currently being visited.

Definition at line 141 of file PtrUseVisitor.h.

Referenced by adjustOffsetForGEP(), enqueueUsers(), llvm::PtrUseVisitor< SliceBuilder >::visitGetElementPtrInst(), and llvm::PtrUseVisitor< SliceBuilder >::visitPtr().

APInt llvm::detail::PtrUseVisitorBase::Offset

protected

The constant offset of the use if that is known.

Definition at line 144 of file PtrUseVisitor.h.

Referenced by adjustOffsetForGEP(), enqueueUsers(), llvm::PtrUseVisitor< SliceBuilder >::visitGetElementPtrInst(), and llvm::PtrUseVisitor< SliceBuilder >::visitPtr().

PtrInfo llvm::detail::PtrUseVisitorBase::PI

protected

The info collected about the pointer being visited thus far.

Definition at line 111 of file PtrUseVisitor.h.

Referenced by llvm::PtrUseVisitor< SliceBuilder >::visitCallSite(), llvm::PtrUseVisitor< SliceBuilder >::visitPtr(), llvm::PtrUseVisitor< SliceBuilder >::visitPtrToIntInst(), and llvm::PtrUseVisitor< SliceBuilder >::visitStoreInst().

Use* llvm::detail::PtrUseVisitorBase::U

protected

The use currently being visited.

Definition at line 137 of file PtrUseVisitor.h.

Referenced by llvm::PtrUseVisitor< SliceBuilder >::visitPtr(), and llvm::PtrUseVisitor< SliceBuilder >::visitStoreInst().

SmallPtrSet<Use *, 8> llvm::detail::PtrUseVisitorBase::VisitedUses

protected

A set of visited uses to break cycles in unreachable code.

Definition at line 127 of file PtrUseVisitor.h.

Referenced by enqueueUsers().

SmallVector<UseToVisit, 8> llvm::detail::PtrUseVisitorBase::Worklist

protected

The worklist of to-visit uses.

Definition at line 124 of file PtrUseVisitor.h.

Referenced by enqueueUsers(), and llvm::PtrUseVisitor< SliceBuilder >::visitPtr().

---

The documentation for this class was generated from the following files:

• PtrUseVisitor.h
• PtrUseVisitor.cpp
