#include <Instructions.h>

Inheritance diagram for llvm::GetElementPtrInst:

Collaboration diagram for llvm::GetElementPtrInst:

Public Member Functions
	DECLARE_TRANSPARENT_OPERAND_ACCESSORS (Value)
	Transparently provide more efficient getOperand methods. More...

SequentialType *	getType () const

unsigned	getAddressSpace () const
	Returns the address space of this instruction's pointer type. More...

op_iterator	idx_begin ()

const_op_iterator	idx_begin () const

op_iterator	idx_end ()

const_op_iterator	idx_end () const

Value *	getPointerOperand ()

const Value *	getPointerOperand () const

Type *	getPointerOperandType () const

unsigned	getPointerAddressSpace () const
	Returns the address space of the pointer operand. More...

unsigned	getNumIndices () const

bool	hasIndices () const

bool	hasAllZeroIndices () const

bool	hasAllConstantIndices () const

void	setIsInBounds (bool b=true)

bool	isInBounds () const
	isInBounds - Determine whether the GEP has the inbounds flag. More...

bool	accumulateConstantOffset (const DataLayout &DL, APInt &Offset) const
	Accumulate the constant address offset of this GEP if possible. More...

Public Member Functions inherited from llvm::Instruction
	~Instruction ()

Instruction *	use_back ()

const Instruction *	use_back () const

const BasicBlock *	getParent () const

BasicBlock *	getParent ()

void	removeFromParent ()

void	eraseFromParent ()

void	insertBefore (Instruction *InsertPos)

void	insertAfter (Instruction *InsertPos)

void	moveBefore (Instruction *MovePos)

unsigned	getOpcode () const
	getOpcode() returns a member of one of the enums like Instruction::Add. More...

const char *	getOpcodeName () const

bool	isTerminator () const

bool	isBinaryOp () const

bool	isShift ()

bool	isCast () const

bool	isLogicalShift () const

bool	isArithmeticShift () const
	isArithmeticShift - Return true if this is an arithmetic shift right. More...

bool	hasMetadata () const

bool	hasMetadataOtherThanDebugLoc () const

MDNode *	getMetadata (unsigned KindID) const

MDNode *	getMetadata (StringRef Kind) const

void	getAllMetadata (SmallVectorImpl< std::pair< unsigned, MDNode * > > &MDs) const

void	getAllMetadataOtherThanDebugLoc (SmallVectorImpl< std::pair< unsigned, MDNode * > > &MDs) const

void	setMetadata (unsigned KindID, MDNode *Node)

void	setMetadata (StringRef Kind, MDNode *Node)

void	setDebugLoc (const DebugLoc &Loc)
	setDebugLoc - Set the debug location information for this instruction. More...

const DebugLoc &	getDebugLoc () const
	getDebugLoc - Return the debug location for this node as a DebugLoc. More...

void	setHasUnsafeAlgebra (bool B)

void	setHasNoNaNs (bool B)

void	setHasNoInfs (bool B)

void	setHasNoSignedZeros (bool B)

void	setHasAllowReciprocal (bool B)

void	setFastMathFlags (FastMathFlags FMF)

bool	hasUnsafeAlgebra () const
	Determine whether the unsafe-algebra flag is set. More...

bool	hasNoNaNs () const
	Determine whether the no-NaNs flag is set. More...

bool	hasNoInfs () const
	Determine whether the no-infs flag is set. More...

bool	hasNoSignedZeros () const
	Determine whether the no-signed-zeros flag is set. More...

bool	hasAllowReciprocal () const
	Determine whether the allow-reciprocal flag is set. More...

FastMathFlags	getFastMathFlags () const

void	copyFastMathFlags (const Instruction *I)
	Copy I's fast-math flags. More...

bool	isAssociative () const

bool	isCommutative () const

bool	isIdempotent () const

bool	isNilpotent () const

bool	mayWriteToMemory () const

bool	mayReadFromMemory () const

bool	mayReadOrWriteMemory () const

bool	mayThrow () const

bool	mayReturn () const

bool	mayHaveSideEffects () const

Instruction *	clone () const

bool	isIdenticalTo (const Instruction *I) const

bool	isIdenticalToWhenDefined (const Instruction *I) const

bool	isSameOperationAs (const Instruction *I, unsigned flags=0) const
	Determine if one instruction is the same operation as another. More...

bool	isUsedOutsideOfBlock (const BasicBlock *BB) const

Public Member Functions inherited from llvm::User
	~User ()

void	operator delete (void *Usr)
	operator delete - free memory allocated for User and Use objects More...

void	operator delete (void *, unsigned)
	placement delete - required by std, but never called. More...

void	operator delete (void *, unsigned, bool)
	placement delete - required by std, but never called. More...

Value *	getOperand (unsigned i) const

void	setOperand (unsigned i, Value *Val)

const Use &	getOperandUse (unsigned i) const

Use &	getOperandUse (unsigned i)

unsigned	getNumOperands () const

op_iterator	op_begin ()

const_op_iterator	op_begin () const

op_iterator	op_end ()

const_op_iterator	op_end () const

value_op_iterator	value_op_begin ()

value_op_iterator	value_op_end ()

void	dropAllReferences ()

void	replaceUsesOfWith (Value From, Value To)

Public Member Functions inherited from llvm::Value
virtual	~Value ()

void	dump () const
	dump - Support for debugging, callable in GDB: V->dump() More...

void	print (raw_ostream &O, AssemblyAnnotationWriter *AAW=0) const

Type *	getType () const

LLVMContext &	getContext () const
	All values hold a context through their type. More...

bool	hasName () const

ValueName *	getValueName () const

void	setValueName (ValueName *VN)

StringRef	getName () const

void	setName (const Twine &Name)

void	takeName (Value *V)

void	replaceAllUsesWith (Value *V)

bool	use_empty () const

use_iterator	use_begin ()

const_use_iterator	use_begin () const

use_iterator	use_end ()

const_use_iterator	use_end () const

User *	use_back ()

const User *	use_back () const

bool	hasOneUse () const

bool	hasNUses (unsigned N) const

bool	hasNUsesOrMore (unsigned N) const

bool	isUsedInBasicBlock (const BasicBlock *BB) const

unsigned	getNumUses () const

void	addUse (Use &U)

unsigned	getValueID () const

unsigned	getRawSubclassOptionalData () const

void	clearSubclassOptionalData ()

bool	hasSameSubclassOptionalData (const Value *V) const

void	intersectOptionalDataWith (const Value *V)

bool	hasValueHandle () const

Value *	stripPointerCasts ()
	Strips off any unneeded pointer casts, all-zero GEPs and aliases from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCasts () const

Value *	stripPointerCastsNoFollowAliases ()
	Strips off any unneeded pointer casts and all-zero GEPs from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCastsNoFollowAliases () const

Value *	stripInBoundsConstantOffsets ()
	Strips off unneeded pointer casts and all-constant GEPs from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsConstantOffsets () const

Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset)
	Strips like `stripInBoundsConstantOffsets` but also accumulates the constant offset stripped. More...

const Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset) const

Value *	stripInBoundsOffsets ()
	Strips off unneeded pointer casts and any in-bounds offsets from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsOffsets () const

bool	isDereferenceablePointer () const

Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB)

const Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB) const

void	mutateType (Type *Ty)

Public Member Functions inherited from llvm::ilist_node< Instruction >
Instruction *	getPrevNode ()
	Get the previous node, or 0 for the list head. More...

const Instruction *	getPrevNode () const
	Get the previous node, or 0 for the list head. More...

Instruction *	getNextNode ()
	Get the next node, or 0 for the list tail. More...

const Instruction *	getNextNode () const
	Get the next node, or 0 for the list tail. More...

Static Public Member Functions
static GetElementPtrInst *	Create (Value Ptr, ArrayRef< Value > IdxList, const Twine &NameStr="", Instruction *InsertBefore=0)

static GetElementPtrInst *	Create (Value Ptr, ArrayRef< Value > IdxList, const Twine &NameStr, BasicBlock *InsertAtEnd)

static GetElementPtrInst *	CreateInBounds (Value Ptr, ArrayRef< Value > IdxList, const Twine &NameStr="", Instruction *InsertBefore=0)

static GetElementPtrInst *	CreateInBounds (Value Ptr, ArrayRef< Value > IdxList, const Twine &NameStr, BasicBlock *InsertAtEnd)

static Type *	getIndexedType (Type Ptr, ArrayRef< Value > IdxList)

static Type *	getIndexedType (Type Ptr, ArrayRef< Constant > IdxList)

static Type *	getIndexedType (Type *Ptr, ArrayRef< uint64_t > IdxList)

static unsigned	getPointerOperandIndex ()

static Type *	getGEPReturnType (Value Ptr, ArrayRef< Value > IdxList)

static bool	classof (const Instruction *I)

static bool	classof (const Value *V)

Static Public Member Functions inherited from llvm::Instruction
static const char *	getOpcodeName (unsigned OpCode)

static bool	isTerminator (unsigned OpCode)

static bool	isBinaryOp (unsigned Opcode)

static bool	isShift (unsigned Opcode)
	Determine if the Opcode is one of the shift instructions. More...

static bool	isCast (unsigned OpCode)
	Determine if the OpCode is one of the CastInst instructions. More...

static bool	isAssociative (unsigned op)

static bool	isCommutative (unsigned op)

static bool	isIdempotent (unsigned op)

static bool	isNilpotent (unsigned op)

static bool	classof (const Value *V)
	Methods for support type inquiry through isa, cast, and dyn_cast: More...

Static Public Member Functions inherited from llvm::User
static bool	classof (const Value *V)

Protected Member Functions
virtual GetElementPtrInst *	clone_impl () const

Protected Member Functions inherited from llvm::Instruction
void	setInstructionSubclassData (unsigned short D)

unsigned	getSubclassDataFromInstruction () const

	Instruction (Type Ty, unsigned iType, Use Ops, unsigned NumOps, Instruction *InsertBefore=0)

	Instruction (Type Ty, unsigned iType, Use Ops, unsigned NumOps, BasicBlock *InsertAtEnd)

Protected Member Functions inherited from llvm::User
void *	operator new (size_t s, unsigned Us)

	User (Type ty, unsigned vty, Use OpList, unsigned NumOps)

Use *	allocHungoffUses (unsigned) const

void	dropHungoffUses ()

template<int Idx>
Use &	Op ()

template<int Idx>
const Use &	Op () const

Protected Member Functions inherited from llvm::Value
virtual void	printCustom (raw_ostream &O) const

	Value (Type *Ty, unsigned scid)

unsigned short	getSubclassDataFromValue () const

void	setValueSubclassData (unsigned short D)

Protected Member Functions inherited from llvm::ilist_node< Instruction >
	ilist_node ()

Additional Inherited Members
Public Types inherited from llvm::Instruction
enum	OperationEquivalenceFlags { CompareIgnoringAlignment = 1<<0, CompareUsingScalarTypes = 1<<1 }

enum	TermOps

enum	BinaryOps

enum	MemoryOps

enum	CastOps

enum	OtherOps

Public Types inherited from llvm::User
typedef Use *	op_iterator

typedef const Use *	const_op_iterator

Public Types inherited from llvm::Value
enum	ValueTy { ArgumentVal, BasicBlockVal, FunctionVal, GlobalAliasVal, GlobalVariableVal, UndefValueVal, BlockAddressVal, ConstantExprVal, ConstantAggregateZeroVal, ConstantDataArrayVal, ConstantDataVectorVal, ConstantIntVal, ConstantFPVal, ConstantArrayVal, ConstantStructVal, ConstantVectorVal, ConstantPointerNullVal, MDNodeVal, MDStringVal, InlineAsmVal, PseudoSourceValueVal, FixedStackPseudoSourceValueVal, InstructionVal, ConstantFirstVal = FunctionVal, ConstantLastVal = ConstantPointerNullVal }

typedef value_use_iterator< User >	use_iterator

typedef value_use_iterator < const User >	const_use_iterator

Static Public Attributes inherited from llvm::Value
static const unsigned	MaximumAlignment = 1u << 29

Static Protected Member Functions inherited from llvm::User
template<int Idx, typename U >
static Use &	OpFrom (const U *that)

Protected Attributes inherited from llvm::User
Use *	OperandList

unsigned	NumOperands

Protected Attributes inherited from llvm::Value
unsigned char	SubclassOptionalData: 7

Detailed Description

GetElementPtrInst - an instruction for type-safe pointer arithmetic to access elements of arrays and structs

Definition at line 709 of file Instructions.h.

Member Function Documentation

bool GetElementPtrInst::accumulateConstantOffset	(	const DataLayout &	DL,
		APInt &	Offset
	)		const

Accumulate the constant address offset of this GEP if possible.

This routine accepts an APInt into which it will accumulate the constant offset of this GEP if the GEP is in fact constant. If the GEP is not all-constant, it returns false and the value of the offset APInt is undefined (it is not preserved!). The APInt passed into this routine must be at least as wide as the IntPtr type for the address space of the base GEP pointer.

Definition at line 1430 of file Instructions.cpp.

Referenced by llvm::detail::PtrUseVisitorBase::adjustOffsetForGEP(), and llvm::InstCombiner::visitGetElementPtrInst().

static bool llvm::GetElementPtrInst::classof ( const Instruction * I )

inlinestatic

Definition at line 863 of file Instructions.h.

References llvm::Instruction::getOpcode().

Referenced by classof().

static bool llvm::GetElementPtrInst::classof ( const Value * V )

inlinestatic

Definition at line 866 of file Instructions.h.

References classof().

GetElementPtrInst * GetElementPtrInst::clone_impl ( ) const

protectedvirtual

Implements llvm::Instruction.

Definition at line 3511 of file Instructions.cpp.

References llvm::User::getNumOperands().

static GetElementPtrInst* llvm::GetElementPtrInst::Create	(	Value *	Ptr,
		ArrayRef< Value * >	IdxList,
		const Twine &	NameStr = `""`,
		Instruction *	InsertBefore = `0`
	)

inlinestatic

Definition at line 726 of file Instructions.h.

References llvm::ArrayRef< T >::size().

Referenced by BuildNew(), llvm::IRBuilder< true, TargetFolder >::CreateConstGEP1_32(), llvm::IRBuilder< true, TargetFolder >::CreateConstGEP1_64(), llvm::IRBuilder< true, TargetFolder >::CreateConstGEP2_32(), llvm::IRBuilder< true, TargetFolder >::CreateConstGEP2_64(), llvm::IRBuilder< true, TargetFolder >::CreateGEP(), llvm::NoFolder::CreateGetElementPtr(), CreateInBounds(), llvm::ConstantExpr::getAsInstruction(), RewriteHeapSROALoadUser(), SRAGlobal(), and llvm::InstCombiner::visitGetElementPtrInst().

static GetElementPtrInst* llvm::GetElementPtrInst::Create	(	Value *	Ptr,
		ArrayRef< Value * >	IdxList,
		const Twine &	NameStr,
		BasicBlock *	InsertAtEnd
	)

inlinestatic

Definition at line 733 of file Instructions.h.

References llvm::ArrayRef< T >::size().

static GetElementPtrInst* llvm::GetElementPtrInst::CreateInBounds	(	Value *	Ptr,
		ArrayRef< Value * >	IdxList,
		const Twine &	NameStr = `""`,
		Instruction *	InsertBefore = `0`
	)

inlinestatic

Create an "inbounds" getelementptr. See the documentation for the "inbounds" flag in LangRef.html for details.

Definition at line 743 of file Instructions.h.

References Create(), and setIsInBounds().

Referenced by llvm::IRBuilder< true, TargetFolder >::CreateConstInBoundsGEP1_32(), llvm::IRBuilder< true, TargetFolder >::CreateConstInBoundsGEP1_64(), llvm::IRBuilder< true, TargetFolder >::CreateConstInBoundsGEP2_32(), llvm::IRBuilder< true, TargetFolder >::CreateConstInBoundsGEP2_64(), llvm::IRBuilder< true, TargetFolder >::CreateInBoundsGEP(), llvm::NoFolder::CreateInBoundsGetElementPtr(), llvm::ConstantExpr::getAsInstruction(), llvm::InstCombiner::visitAllocaInst(), llvm::InstCombiner::visitBitCast(), and llvm::InstCombiner::visitGetElementPtrInst().

static GetElementPtrInst* llvm::GetElementPtrInst::CreateInBounds	(	Value *	Ptr,
		ArrayRef< Value * >	IdxList,
		const Twine &	NameStr,
		BasicBlock *	InsertAtEnd
	)

inlinestatic

Definition at line 751 of file Instructions.h.

References Create(), and setIsInBounds().

llvm::GetElementPtrInst::DECLARE_TRANSPARENT_OPERAND_ACCESSORS ( Value )

Transparently provide more efficient getOperand methods.

unsigned llvm::GetElementPtrInst::getAddressSpace ( ) const

inline

Returns the address space of this instruction's pointer type.

Definition at line 769 of file Instructions.h.

References getPointerAddressSpace().

static Type* llvm::GetElementPtrInst::getGEPReturnType	(	Value *	Ptr,
		ArrayRef< Value * >	IdxList
	)

inlinestatic

GetGEPReturnType - Returns the pointer type returned by the GEP instruction, which may be a vector of pointers.

Definition at line 813 of file Instructions.h.

References llvm::checkGEPType(), llvm::VectorType::get(), llvm::PointerType::get(), getIndexedType(), llvm::Type::getPointerAddressSpace(), llvm::Value::getType(), and llvm::Type::isVectorTy().

Type * GetElementPtrInst::getIndexedType	(	Type *	Ptr,
		ArrayRef< Value * >	IdxList
	)

static

getIndexedType - Returns the type of the element that would be loaded with a load instruction with the specified parameters.

Null is returned if the indices are invalid for the specified pointer type.

Definition at line 1384 of file Instructions.cpp.

References getIndexedTypeInternal().

Referenced by CastGEPIndices(), ConstantFoldGetElementPtrImpl(), getGEPReturnType(), llvm::ConstantExpr::getGetElementPtr(), and SimplifyGEPInst().

Type * GetElementPtrInst::getIndexedType	(	Type *	Ptr,
		ArrayRef< Constant * >	IdxList
	)

static

Definition at line 1388 of file Instructions.cpp.

References getIndexedTypeInternal().

Type * GetElementPtrInst::getIndexedType	(	Type *	Ptr,
		ArrayRef< uint64_t >	IdxList
	)

static

Definition at line 1393 of file Instructions.cpp.

References getIndexedTypeInternal().

unsigned llvm::GetElementPtrInst::getNumIndices ( ) const

inline

Definition at line 827 of file Instructions.h.

References llvm::User::getNumOperands().

Referenced by llvm::InstCombiner::visitGetElementPtrInst().

unsigned llvm::GetElementPtrInst::getPointerAddressSpace ( ) const

inline

Returns the address space of the pointer operand.

Definition at line 807 of file Instructions.h.

References llvm::Type::getPointerAddressSpace(), and getPointerOperandType().

Referenced by getAddressSpace(), and llvm::InstCombiner::visitGetElementPtrInst().

Value* llvm::GetElementPtrInst::getPointerOperand ( )

inline

Definition at line 790 of file Instructions.h.

References llvm::User::getOperand().

Referenced by getPointerOperandType(), and llvm::Interpreter::visitGetElementPtrInst().

const Value* llvm::GetElementPtrInst::getPointerOperand ( ) const

inline

Definition at line 793 of file Instructions.h.

References llvm::User::getOperand().

static unsigned llvm::GetElementPtrInst::getPointerOperandIndex ( )

inlinestatic

Definition at line 796 of file Instructions.h.

Type* llvm::GetElementPtrInst::getPointerOperandType ( ) const

inline

getPointerOperandType - Method to return the pointer operand as a PointerType.

Definition at line 802 of file Instructions.h.

References getPointerOperand(), and llvm::Value::getType().

Referenced by getPointerAddressSpace(), and llvm::InstCombiner::visitGetElementPtrInst().

SequentialType* llvm::GetElementPtrInst::getType ( ) const

inline

Definition at line 764 of file Instructions.h.

References llvm::Value::getType().

Referenced by llvm::InstCombiner::FoldCmpLoadFromIndexedGlobal(), getGEPInductionOperand(), and llvm::InstCombiner::visitGetElementPtrInst().

bool GetElementPtrInst::hasAllConstantIndices ( ) const

hasAllConstantIndices - Return true if all of the indices of this GEP are constant integers. If so, the result pointer and the first operand have a constant offset between them.

Definition at line 1414 of file Instructions.cpp.

References llvm::User::getNumOperands(), and llvm::User::getOperand().

Referenced by isSafeAndProfitableToSinkLoad().

bool GetElementPtrInst::hasAllZeroIndices ( ) const

hasAllZeroIndices - Return true if all of the indices of this GEP are zeros. If so, the result pointer and the first operand have the same value, just potentially different types.

Definition at line 1400 of file Instructions.cpp.

References llvm::User::getNumOperands(), and llvm::User::getOperand().

bool llvm::GetElementPtrInst::hasIndices ( ) const

inline

Definition at line 831 of file Instructions.h.

References llvm::User::getNumOperands().

op_iterator llvm::GetElementPtrInst::idx_begin ( )

inline

Definition at line 785 of file Instructions.h.

References llvm::User::op_begin().

Referenced by llvm::InstCombiner::visitGetElementPtrInst().

const_op_iterator llvm::GetElementPtrInst::idx_begin ( ) const
