#include <MCInstPrinter.h>

Inheritance diagram for llvm::MCInstPrinter:

Collaboration diagram for llvm::MCInstPrinter:

Public Member Functions
	MCInstPrinter (const MCAsmInfo &mai, const MCInstrInfo &mii, const MCRegisterInfo &mri)

virtual	~MCInstPrinter ()

void	setCommentStream (raw_ostream &OS)
	setCommentStream - Specify a stream to emit comments to. More...

virtual void	printInst (const MCInst *MI, raw_ostream &OS, StringRef Annot)=0

StringRef	getOpcodeName (unsigned Opcode) const

virtual void	printRegName (raw_ostream &OS, unsigned RegNo) const
	printRegName - Print the assembler register name. More...

uint64_t	getAvailableFeatures () const

void	setAvailableFeatures (uint64_t Value)

bool	getUseMarkup () const

void	setUseMarkup (bool Value)

StringRef	markup (StringRef s) const
	Utility functions to make adding mark ups simpler. More...

StringRef	markup (StringRef a, StringRef b) const

bool	getPrintImmHex () const

void	setPrintImmHex (bool Value)

HexStyle::Style	getPrintHexStyleHex () const

void	setPrintImmHex (HexStyle::Style Value)

format_object1< int64_t >	formatImm (const int64_t Value) const
	Utility function to print immediates in decimal or hex. More...

format_object1< int64_t >	formatDec (const int64_t Value) const
	Utility functions to print decimal/hexadecimal values. More...

format_object1< int64_t >	formatHex (const int64_t Value) const

format_object1< uint64_t >	formatHex (const uint64_t Value) const

Protected Member Functions
void	printAnnotation (raw_ostream &OS, StringRef Annot)
	Utility function for printing annotations. More...

Protected Attributes
raw_ostream *	CommentStream

const MCAsmInfo &	MAI

const MCInstrInfo &	MII

const MCRegisterInfo &	MRI

uint64_t	AvailableFeatures
	The current set of available features. More...

bool	UseMarkup
	True if we are printing marked up assembly. More...

bool	PrintImmHex
	True if we are printing immediates as hex. More...

HexStyle::Style	PrintHexStyle
	Which style to use for printing hexadecimal values. More...

Detailed Description

MCInstPrinter - This is an instance of a target assembly language printer that converts an MCInst to valid target assembly syntax.

Definition at line 33 of file MCInstPrinter.h.

Constructor & Destructor Documentation

llvm::MCInstPrinter::MCInstPrinter	(	const MCAsmInfo &	mai,
		const MCInstrInfo &	mii,
		const MCRegisterInfo &	mri
	)

inline

Definition at line 58 of file MCInstPrinter.h.

MCInstPrinter::~MCInstPrinter ( )

virtual

Definition at line 19 of file MCInstPrinter.cpp.

Member Function Documentation

format_object1< int64_t > MCInstPrinter::formatDec ( const int64_t Value ) const

Utility functions to print decimal/hexadecimal values.

Definition at line 72 of file MCInstPrinter.cpp.

References llvm::format().

Referenced by formatImm().

format_object1< int64_t > MCInstPrinter::formatHex ( const int64_t Value ) const

Definition at line 76 of file MCInstPrinter.cpp.

References llvm::HexStyle::Asm, llvm::HexStyle::C, llvm::format(), llvm_unreachable, needsLeadingZero(), and PrintHexStyle.

Referenced by formatImm(), llvm::X86IntelInstPrinter::printPCRelImm(), and llvm::X86ATTInstPrinter::printPCRelImm().

format_object1< uint64_t > MCInstPrinter::formatHex ( const uint64_t Value ) const

Definition at line 99 of file MCInstPrinter.cpp.

References llvm::HexStyle::Asm, llvm::HexStyle::C, llvm::format(), llvm_unreachable, needsLeadingZero(), and PrintHexStyle.

format_object1<int64_t> llvm::MCInstPrinter::formatImm ( const int64_t Value ) const

inline

Utility function to print immediates in decimal or hex.

Definition at line 97 of file MCInstPrinter.h.

References formatDec(), formatHex(), and PrintImmHex.

Referenced by llvm::ARMInstPrinter::printImmPlusOneOperand(), llvm::X86IntelInstPrinter::printMemOffset(), llvm::X86ATTInstPrinter::printMemOffset(), llvm::X86IntelInstPrinter::printMemReference(), llvm::X86ATTInstPrinter::printMemReference(), llvm::ARMInstPrinter::printOperand(), llvm::X86IntelInstPrinter::printOperand(), llvm::NVPTXInstPrinter::printOperand(), llvm::X86ATTInstPrinter::printOperand(), llvm::X86IntelInstPrinter::printPCRelImm(), llvm::X86ATTInstPrinter::printPCRelImm(), llvm::ARMInstPrinter::printT2AddrModeImm0_1020s4Operand(), llvm::ARMInstPrinter::printThumbAddrModeImm5SOperand(), llvm::ARMInstPrinter::printThumbLdrLabelOperand(), llvm::ARMInstPrinter::printThumbS4ImmOperand(), and llvm::ARMInstPrinter::printThumbSRImm().

uint64_t llvm::MCInstPrinter::getAvailableFeatures ( ) const

inline

Definition at line 80 of file MCInstPrinter.h.

References AvailableFeatures.

Referenced by llvm::ARMInstPrinter::printInst(), llvm::ARMInstPrinter::printMemBOption(), and llvm::ARMInstPrinter::printMSRMaskOperand().

StringRef MCInstPrinter::getOpcodeName ( unsigned Opcode ) const

getOpcodeName - Return the name of the specified opcode enum (e.g. "MOV32ri") or empty if we can't resolve it.

Definition at line 24 of file MCInstPrinter.cpp.

References llvm::MCInstrInfo::getName(), and MII.

Referenced by llvm::MCInst::dump_pretty().

HexStyle::Style llvm::MCInstPrinter::getPrintHexStyleHex ( ) const

inline

Definition at line 93 of file MCInstPrinter.h.

References PrintHexStyle.

bool llvm::MCInstPrinter::getPrintImmHex ( ) const

inline

Definition at line 90 of file MCInstPrinter.h.

References PrintImmHex.

bool llvm::MCInstPrinter::getUseMarkup ( ) const

inline

Definition at line 83 of file MCInstPrinter.h.

References UseMarkup.

Referenced by markup().

StringRef MCInstPrinter::markup ( StringRef s ) const

Utility functions to make adding mark ups simpler.

Definition at line 46 of file MCInstPrinter.cpp.

References getUseMarkup().

StringRef MCInstPrinter::markup	(	StringRef	a,
		StringRef	b
	)		const

Definition at line 52 of file MCInstPrinter.cpp.

References getUseMarkup().

void MCInstPrinter::printAnnotation	(	raw_ostream &	OS,
		StringRef	Annot
	)

protected

Utility function for printing annotations.

Definition at line 32 of file MCInstPrinter.cpp.

References CommentStream, llvm::StringRef::empty(), llvm::MCAsmInfo::getCommentString(), and MAI.

Referenced by llvm::MSP430InstPrinter::printInst(), llvm::ARMInstPrinter::printInst(), llvm::X86ATTInstPrinter::printInst(), llvm::X86IntelInstPrinter::printInst(), llvm::HexagonInstPrinter::printInst(), llvm::NVPTXInstPrinter::printInst(), llvm::AMDGPUInstPrinter::printInst(), llvm::PPCInstPrinter::printInst(), llvm::XCoreInstPrinter::printInst(), llvm::SystemZInstPrinter::printInst(), llvm::MipsInstPrinter::printInst(), and llvm::AArch64InstPrinter::printInst().

virtual void llvm::MCInstPrinter::printInst	(	const MCInst *	MI,
		raw_ostream &	OS,
		StringRef	Annot
	)

pure virtual

printInst - Print the specified MCInst to the specified raw_ostream.

Implemented in llvm::AArch64InstPrinter, llvm::MipsInstPrinter, llvm::SystemZInstPrinter, llvm::PPCInstPrinter, llvm::XCoreInstPrinter, llvm::AMDGPUInstPrinter, llvm::NVPTXInstPrinter, llvm::X86IntelInstPrinter, llvm::HexagonInstPrinter, llvm::X86ATTInstPrinter, llvm::ARMInstPrinter, and llvm::MSP430InstPrinter.

Referenced by LLVMDisasmInstruction().

void MCInstPrinter::printRegName	(	raw_ostream &	OS,
		unsigned	RegNo
	)		const

virtual

printRegName - Print the assembler register name.

Reimplemented in llvm::MipsInstPrinter, llvm::SystemZInstPrinter, llvm::AArch64InstPrinter, llvm::PPCInstPrinter, llvm::XCoreInstPrinter, llvm::ARMInstPrinter, llvm::NVPTXInstPrinter, llvm::X86IntelInstPrinter, and llvm::X86ATTInstPrinter.

Definition at line 28 of file MCInstPrinter.cpp.

References llvm_unreachable.

void llvm::MCInstPrinter::setAvailableFeatures ( uint64_t Value )

inline

Definition at line 81 of file MCInstPrinter.h.

References AvailableFeatures.

Referenced by llvm::AArch64InstPrinter::AArch64InstPrinter(), llvm::ARMInstPrinter::ARMInstPrinter(), and llvm::NVPTXInstPrinter::NVPTXInstPrinter().

void llvm::MCInstPrinter::setCommentStream ( raw_ostream & OS )

inline

setCommentStream - Specify a stream to emit comments to.

Definition at line 66 of file MCInstPrinter.h.

References CommentStream.

Referenced by LLVMSetDisasmOptions().

void llvm::MCInstPrinter::setPrintImmHex ( bool Value )

inline

Definition at line 91 of file MCInstPrinter.h.

References PrintImmHex.

Referenced by LLVMSetDisasmOptions().

void llvm::MCInstPrinter::setPrintImmHex ( HexStyle::Style Value )

inline

Definition at line 94 of file MCInstPrinter.h.

References PrintHexStyle.

void llvm::MCInstPrinter::setUseMarkup ( bool Value )

inline

Definition at line 84 of file MCInstPrinter.h.

References UseMarkup.

Referenced by LLVMSetDisasmOptions().

Member Data Documentation

uint64_t llvm::MCInstPrinter::AvailableFeatures

protected

The current set of available features.

Definition at line 44 of file MCInstPrinter.h.

Referenced by getAvailableFeatures(), and setAvailableFeatures().

raw_ostream* llvm::MCInstPrinter::CommentStream

protected

CommentStream - a stream that comments can be emitted to if desired. Each comment must end with a newline. This will be null if verbose assembly emission is disable.

Definition at line 38 of file MCInstPrinter.h.

Referenced by printAnnotation(), llvm::X86ATTInstPrinter::printInst(), llvm::X86IntelInstPrinter::printInst(), llvm::X86ATTInstPrinter::printOperand(), and setCommentStream().
