#include <X86ATTInstPrinter.h>

Inheritance diagram for llvm::X86ATTInstPrinter:

Collaboration diagram for llvm::X86ATTInstPrinter:

Public Member Functions
	X86ATTInstPrinter (const MCAsmInfo &MAI, const MCInstrInfo &MII, const MCRegisterInfo &MRI)

virtual void	printRegName (raw_ostream &OS, unsigned RegNo) const
	printRegName - Print the assembler register name. More...

virtual void	printInst (const MCInst *MI, raw_ostream &OS, StringRef Annot)

bool	printAliasInstr (const MCInst *MI, raw_ostream &OS)

void	printInstruction (const MCInst *MI, raw_ostream &OS)

void	printOperand (const MCInst *MI, unsigned OpNo, raw_ostream &OS)

void	printMemReference (const MCInst *MI, unsigned Op, raw_ostream &OS)

void	printSSECC (const MCInst *MI, unsigned Op, raw_ostream &OS)

void	printAVXCC (const MCInst *MI, unsigned Op, raw_ostream &OS)

void	printPCRelImm (const MCInst *MI, unsigned OpNo, raw_ostream &OS)

void	printMemOffset (const MCInst *MI, unsigned OpNo, raw_ostream &OS)

void	printopaquemem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi8mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi16mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi32mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi64mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi128mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi256mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printi512mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf32mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf64mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf80mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf128mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf256mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printf512mem (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printMemOffs8 (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printMemOffs16 (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printMemOffs32 (const MCInst *MI, unsigned OpNo, raw_ostream &O)

void	printMemOffs64 (const MCInst *MI, unsigned OpNo, raw_ostream &O)

Public Member Functions inherited from llvm::MCInstPrinter
	MCInstPrinter (const MCAsmInfo &mai, const MCInstrInfo &mii, const MCRegisterInfo &mri)

virtual	~MCInstPrinter ()

void	setCommentStream (raw_ostream &OS)
	setCommentStream - Specify a stream to emit comments to. More...

StringRef	getOpcodeName (unsigned Opcode) const

uint64_t	getAvailableFeatures () const

void	setAvailableFeatures (uint64_t Value)

bool	getUseMarkup () const

void	setUseMarkup (bool Value)

StringRef	markup (StringRef s) const
	Utility functions to make adding mark ups simpler. More...

StringRef	markup (StringRef a, StringRef b) const

bool	getPrintImmHex () const

void	setPrintImmHex (bool Value)

HexStyle::Style	getPrintHexStyleHex () const

void	setPrintImmHex (HexStyle::Style Value)

format_object1< int64_t >	formatImm (const int64_t Value) const
	Utility function to print immediates in decimal or hex. More...

format_object1< int64_t >	formatDec (const int64_t Value) const
	Utility functions to print decimal/hexadecimal values. More...

format_object1< int64_t >	formatHex (const int64_t Value) const

format_object1< uint64_t >	formatHex (const uint64_t Value) const

Static Public Member Functions
static const char *	getRegisterName (unsigned RegNo)

Additional Inherited Members
Protected Member Functions inherited from llvm::MCInstPrinter
void	printAnnotation (raw_ostream &OS, StringRef Annot)
	Utility function for printing annotations. More...

Protected Attributes inherited from llvm::MCInstPrinter
raw_ostream *	CommentStream

const MCAsmInfo &	MAI

const MCInstrInfo &	MII

const MCRegisterInfo &	MRI

uint64_t	AvailableFeatures
	The current set of available features. More...

bool	UseMarkup
	True if we are printing marked up assembly. More...

bool	PrintImmHex
	True if we are printing immediates as hex. More...

HexStyle::Style	PrintHexStyle
	Which style to use for printing hexadecimal values. More...

Detailed Description

Definition at line 23 of file X86ATTInstPrinter.h.

Constructor & Destructor Documentation

llvm::X86ATTInstPrinter::X86ATTInstPrinter	(	const MCAsmInfo &	MAI,
		const MCInstrInfo &	MII,
		const MCRegisterInfo &	MRI
	)

inline

Definition at line 25 of file X86ATTInstPrinter.h.

Member Function Documentation

static const char* llvm::X86ATTInstPrinter::getRegisterName ( unsigned RegNo )

static

Referenced by llvm::X86AsmPrinter::EmitInstruction(), llvm::X86AsmPrinter::printAsmMRegister(), printInst(), llvm::X86AsmPrinter::printOperand(), and printRegName().

bool llvm::X86ATTInstPrinter::printAliasInstr	(	const MCInst *	MI,
		raw_ostream &	OS
	)

Referenced by printInst().

void X86ATTInstPrinter::printAVXCC	(	const MCInst *	MI,
		unsigned	Op,
		raw_ostream &	OS
	)

Definition at line 86 of file X86ATTInstPrinter.cpp.

References llvm::MCOperand::getImm(), llvm::MCInst::getOperand(), and llvm_unreachable.

void llvm::X86ATTInstPrinter::printf128mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 81 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printf256mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 84 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printf32mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 72 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printf512mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 87 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printf64mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 75 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printf80mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 78 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi128mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 63 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi16mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 54 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi256mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 66 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi32mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 57 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi512mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 69 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi64mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 60 of file X86ATTInstPrinter.h.

References printMemReference().

void llvm::X86ATTInstPrinter::printi8mem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 51 of file X86ATTInstPrinter.h.

References printMemReference().

void X86ATTInstPrinter::printInst	(	const MCInst *	MI,
		raw_ostream &	OS,
		StringRef	Annot
	)

virtual

printInst - Print the specified MCInst to the specified raw_ostream.

Implements llvm::MCInstPrinter.

Definition at line 42 of file X86ATTInstPrinter.cpp.

References llvm::MCInstPrinter::CommentStream, llvm::EmitAnyX86InstComments(), llvm::MCInstrInfo::get(), llvm::MCInst::getOpcode(), getRegisterName(), llvm::X86II::LOCK, llvm::MCInstPrinter::MII, printAliasInstr(), llvm::MCInstPrinter::printAnnotation(), printInstruction(), and llvm::MCInstrDesc::TSFlags.

void llvm::X86ATTInstPrinter::printInstruction	(	const MCInst *	MI,
		raw_ostream &	OS
	)

Referenced by printInst().

void llvm::X86ATTInstPrinter::printMemOffs16	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 94 of file X86ATTInstPrinter.h.

References printMemOffset().

void llvm::X86ATTInstPrinter::printMemOffs32	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 97 of file X86ATTInstPrinter.h.

References printMemOffset().

void llvm::X86ATTInstPrinter::printMemOffs64	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 100 of file X86ATTInstPrinter.h.

References printMemOffset().

void llvm::X86ATTInstPrinter::printMemOffs8	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 91 of file X86ATTInstPrinter.h.

References printMemOffset().

void X86ATTInstPrinter::printMemOffset	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	OS
	)

Definition at line 219 of file X86ATTInstPrinter.cpp.

References llvm::MCInstPrinter::formatImm(), llvm::MCOperand::getExpr(), llvm::MCOperand::getImm(), llvm::MCInst::getOperand(), llvm::MCOperand::isExpr(), llvm::MCOperand::isImm(), and llvm::MCInstPrinter::markup().

Referenced by printMemOffs16(), printMemOffs32(), printMemOffs64(), and printMemOffs8().

void X86ATTInstPrinter::printMemReference	(	const MCInst *	MI,
		unsigned	Op,
		raw_ostream &	OS
	)

Definition at line 173 of file X86ATTInstPrinter.cpp.

References llvm::MCInstPrinter::formatImm(), llvm::MCOperand::getExpr(), llvm::MCOperand::getImm(), llvm::MCInst::getOperand(), llvm::MCOperand::getReg(), llvm::MCOperand::isExpr(), llvm::MCOperand::isImm(), llvm::MCInstPrinter::markup(), and printOperand().

Referenced by printf128mem(), printf256mem(), printf32mem(), printf512mem(), printf64mem(), printf80mem(), printi128mem(), printi16mem(), printi256mem(), printi32mem(), printi512mem(), printi64mem(), printi8mem(), and printopaquemem().

void llvm::X86ATTInstPrinter::printopaquemem	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

inline

Definition at line 47 of file X86ATTInstPrinter.h.

References printMemReference().

void X86ATTInstPrinter::printOperand	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	OS
	)

Definition at line 151 of file X86ATTInstPrinter.cpp.

References llvm::MCInstPrinter::CommentStream, llvm::format(), llvm::MCInstPrinter::formatImm(), llvm::MCOperand::getExpr(), llvm::MCOperand::getImm(), llvm::MCInst::getOperand(), llvm::MCOperand::getReg(), llvm::MCOperand::isExpr(), llvm::MCOperand::isImm(), llvm::MCOperand::isReg(), llvm::MCInstPrinter::markup(), and printRegName().

Referenced by printMemReference().

void X86ATTInstPrinter::printPCRelImm	(	const MCInst *	MI,
		unsigned	OpNo,
		raw_ostream &	O
	)

printPCRelImm - This is used to print an immediate value that ends up being encoded as a pc-relative value (e.g. for jumps and calls). These print slightly differently than normal immediates. For example, a $ is not emitted.

Definition at line 130 of file X86ATTInstPrinter.cpp.

References llvm::dyn_cast(), llvm::MCInstPrinter::formatHex(), llvm::MCInstPrinter::formatImm(), llvm::MCOperand::getExpr(), llvm::MCOperand::getImm(), llvm::MCInst::getOperand(), llvm::MCOperand::isExpr(), and llvm::MCOperand::isImm().
