llvm::X86AddressMode Struct Reference

#include <X86InstrBuilder.h>

Collaboration diagram for llvm::X86AddressMode:

Public Types
enum	{ RegBase, FrameIndexBase }

Public Member Functions
	X86AddressMode ()
void	getFullAddress (SmallVectorImpl< MachineOperand > &MO)

Public Attributes
enum llvm::X86AddressMode:: { ... }	BaseType
union {
unsigned   Reg
int   FrameIndex
}	Base
unsigned	Scale
unsigned	IndexReg
int	Disp
const GlobalValue *	GV
unsigned	GVOpFlags

Detailed Description

X86AddressMode - This struct holds a generalized full x86 address mode. The base register can be a frame index, which will eventually be replaced with BP or SP and Disp being offsetted accordingly. The displacement may also include the offset of a global value.

Definition at line 37 of file X86InstrBuilder.h.

Member Enumeration Documentation

anonymous enum

Enumerator
RegBase
FrameIndexBase

Definition at line 38 of file X86InstrBuilder.h.

Constructor & Destructor Documentation

llvm::X86AddressMode::X86AddressMode ( )

inline

Definition at line 54 of file X86InstrBuilder.h.

References Base.

Member Function Documentation

void llvm::X86AddressMode::getFullAddress ( SmallVectorImpl< MachineOperand > &  MO )

inline

Definition at line 60 of file X86InstrBuilder.h.

References Base, BaseType, llvm::MachineOperand::CreateFI(), llvm::MachineOperand::CreateGA(), llvm::MachineOperand::CreateImm(), llvm::MachineOperand::CreateReg(), Disp, FrameIndexBase, GV, GVOpFlags, IndexReg, llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back(), RegBase, and Scale.

Member Data Documentation

union { ... } llvm::X86AddressMode::Base

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), getFullAddress(), and X86AddressMode().

enum { ... } llvm::X86AddressMode::BaseType

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), and getFullAddress().

int llvm::X86AddressMode::Disp

Definition at line 50 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), and getFullAddress().

int llvm::X86AddressMode::FrameIndex

Definition at line 45 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), and llvm::X86TargetLowering::EmitInstrWithCustomInserter().

const GlobalValue* llvm::X86AddressMode::GV

Definition at line 51 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), and getFullAddress().

unsigned llvm::X86AddressMode::GVOpFlags

Definition at line 52 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), and getFullAddress().

unsigned llvm::X86AddressMode::IndexReg

Definition at line 49 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), and getFullAddress().

unsigned llvm::X86AddressMode::Reg

Definition at line 44 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), and llvm::X86TargetLowering::EmitInstrWithCustomInserter().

unsigned llvm::X86AddressMode::Scale

Definition at line 48 of file X86InstrBuilder.h.

Referenced by llvm::addFullAddress(), llvm::X86TargetLowering::EmitInstrWithCustomInserter(), and getFullAddress().

---

The documentation for this struct was generated from the following file:

• X86InstrBuilder.h
