StackProtector.cpp File Reference

#include "llvm/CodeGen/StackProtector.h"
#include "llvm/CodeGen/Analysis.h"
#include "llvm/CodeGen/Passes.h"
#include "llvm/ADT/SmallPtrSet.h"
#include "llvm/ADT/Statistic.h"
#include "llvm/Analysis/Dominators.h"
#include "llvm/Analysis/ValueTracking.h"
#include "llvm/IR/Attributes.h"
#include "llvm/IR/Constants.h"
#include "llvm/IR/DataLayout.h"
#include "llvm/IR/DerivedTypes.h"
#include "llvm/IR/Function.h"
#include "llvm/IR/GlobalValue.h"
#include "llvm/IR/GlobalVariable.h"
#include "llvm/IR/IRBuilder.h"
#include "llvm/IR/Instructions.h"
#include "llvm/IR/IntrinsicInst.h"
#include "llvm/IR/Intrinsics.h"
#include "llvm/IR/Module.h"
#include "llvm/Support/CommandLine.h"
#include <cstdlib>

Include dependency graph for StackProtector.cpp:

Go to the source code of this file.

Macros
#define	DEBUG_TYPE   "stack-protector"

Functions
	STATISTIC (NumFunProtected,"Number of functions protected")
	STATISTIC (NumAddrTaken,"Number of local variables that have their address"" taken.")
	INITIALIZE_PASS (StackProtector,"stack-protector","Insert stack protectors", false, true) FunctionPass *llvm
static bool	InstructionWillNotHaveChain (const Instruction *I)
static CallInst *	FindPotentialTailCall (BasicBlock *BB, ReturnInst *RI, const TargetLoweringBase *TLI)
static bool	CreatePrologue (Function *F, Module *M, ReturnInst *RI, const TargetLoweringBase *TLI, const Triple &Trip, AllocaInst *&AI, Value *&StackGuardVar)

Variables
static cl::opt< bool >	EnableSelectionDAGSP ("enable-selectiondag-sp", cl::init(true), cl::Hidden)

Macro Definition Documentation

#define DEBUG_TYPE   "stack-protector"

Definition at line 17 of file StackProtector.cpp.

Function Documentation

static bool CreatePrologue ( Function *  F, Module *  M, ReturnInst *  RI, const TargetLoweringBase *  TLI, const Triple &  Trip, AllocaInst *&  AI, Value *&  StackGuardVar  )

static

Insert code into the entry block that stores the __stack_chk_guard variable onto the stack:

entry: StackGuardSlot = alloca i8* StackGuard = load __stack_chk_guard call void .stackprotect.create(StackGuard, StackGuardSlot)

Returns true if the platform/triple supports the stackprotectorcreate pseudo node.

Definition at line 315 of file StackProtector.cpp.

References llvm::BasicBlock::front(), llvm::ConstantInt::get(), llvm::PointerType::get(), llvm::Value::getContext(), llvm::Intrinsic::getDeclaration(), llvm::Function::getEntryBlock(), llvm::Type::getInt32Ty(), llvm::Type::getInt8PtrTy(), llvm::ConstantExpr::getIntToPtr(), llvm::Module::getOrInsertGlobal(), llvm::Triple::getOS(), llvm::TargetLoweringBase::getStackCookieLocation(), llvm::GlobalValue::HiddenVisibility, LI, llvm::Triple::OpenBSD, and llvm::Intrinsic::stackprotector.

static CallInst* FindPotentialTailCall ( BasicBlock *  BB, ReturnInst *  RI, const TargetLoweringBase *  TLI  )

static

Identify if RI has a previous instruction in the "Tail Position" and return it. Otherwise return 0.

This is based off of the code in llvm::isInTailCallPosition. The difference is that it inverts the first part of llvm::isInTailCallPosition since isInTailCallPosition is checking if a call is in a tail call position, and we are searching for an unknown tail call that might be in the tail call position. Once we find the call though, the code uses the same refactored code, returnTypeIsEligibleForTailCall.

Definition at line 256 of file StackProtector.cpp.

References llvm::BasicBlock::getParent(), I, InstructionWillNotHaveChain(), llvm::next(), llvm::BasicBlock::rbegin(), llvm::BasicBlock::rend(), and llvm::returnTypeIsEligibleForTailCall().

INITIALIZE_PASS	(	StackProtector	,
		"stack-protector"	,
		"Insert stack protectors"	,
		false	,
		true
	)

Definition at line 49 of file StackProtector.cpp.

static bool InstructionWillNotHaveChain ( const Instruction *  I )

static

Definition at line 242 of file StackProtector.cpp.

References llvm::isSafeToSpeculativelyExecute(), llvm::Instruction::mayHaveSideEffects(), and llvm::Instruction::mayReadFromMemory().

Referenced by FindPotentialTailCall().

STATISTIC	(	NumFunProtected	,
		"Number of functions protected"
	)

STATISTIC	(	NumAddrTaken	,
		"Number of local variables that have their address"" taken."
	)

Variable Documentation

cl::opt<bool> EnableSelectionDAGSP("enable-selectiondag-sp", cl::init(true), cl::Hidden)

static
