#include <LegacyPassManagers.h>

Inheritance diagram for llvm::PMDataManager:

Collaboration diagram for llvm::PMDataManager:

Public Member Functions
	PMDataManager ()

virtual	~PMDataManager ()

virtual Pass *	getAsPass ()=0

void	recordAvailableAnalysis (Pass *P)
	Augment AvailableAnalysis by adding analysis made available by pass P. More...

void	verifyPreservedAnalysis (Pass *P)
	verifyPreservedAnalysis – Verify analysis presreved by pass P. More...

void	removeNotPreservedAnalysis (Pass *P)
	Remove Analysis that is not preserved by the pass. More...

void	removeDeadPasses (Pass *P, StringRef Msg, enum PassDebuggingString)
	Remove dead passes used by P. More...

void	freePass (Pass *P, StringRef Msg, enum PassDebuggingString)
	Remove P. More...

void	add (Pass *P, bool ProcessAnalysis=true)

virtual void	addLowerLevelRequiredPass (Pass P, Pass RequiredPass)

virtual Pass *	getOnTheFlyPass (Pass *P, AnalysisID PI, Function &F)

void	initializeAnalysisInfo ()
	Initialize available analysis information. More...

bool	preserveHigherLevelAnalysis (Pass *P)

void	collectRequiredAnalysis (SmallVectorImpl< Pass * > &RequiredPasses, SmallVectorImpl< AnalysisID > &ReqPassNotAvailable, Pass *P)

void	initializeAnalysisImpl (Pass *P)

Pass *	findAnalysisPass (AnalysisID AID, bool Direction)

PMTopLevelManager *	getTopLevelManager ()

void	setTopLevelManager (PMTopLevelManager *T)

unsigned	getDepth () const

void	setDepth (unsigned newDepth)

void	dumpLastUses (Pass *P, unsigned Offset) const

void	dumpPassArguments () const

void	dumpPassInfo (Pass *P, enum PassDebuggingString S1, enum PassDebuggingString S2, StringRef Msg)

void	dumpRequiredSet (const Pass *P) const

void	dumpPreservedSet (const Pass *P) const

unsigned	getNumContainedPasses () const

virtual PassManagerType	getPassManagerType () const

DenseMap< AnalysisID, Pass * > *	getAvailableAnalysis ()

void	populateInheritedAnalysis (PMStack &PMS)

Protected Member Functions
bool	isPassDebuggingExecutionsOrMore () const

Protected Attributes
PMTopLevelManager *	TPM

SmallVector< Pass *, 16 >	PassVector

DenseMap< AnalysisID, Pass * > *	InheritedAnalysis [PMT_Last]

Detailed Description

PMDataManager provides the common place to manage the analysis data used by pass managers.

Definition at line 263 of file LegacyPassManagers.h.

Constructor & Destructor Documentation

llvm::PMDataManager::PMDataManager ( )

inlineexplicit

Definition at line 266 of file LegacyPassManagers.h.

References initializeAnalysisInfo().

PMDataManager::~PMDataManager ( )

virtual

Definition at line 1266 of file LegacyPassManager.cpp.

References I, and PassVector.

Member Function Documentation

void PMDataManager::add	(	Pass *	P,
		bool	ProcessAnalysis = `true`
	)

Add pass P into the PassVector. Update AvailableAnalysis appropriately if ProcessAnalysis is true.

Definition at line 981 of file LegacyPassManager.cpp.

References addLowerLevelRequiredPass(), llvm::SmallVectorTemplateCommon< T >::begin(), llvm::SmallVectorImpl< T >::clear(), collectRequiredAnalysis(), llvm::PassInfo::createPass(), llvm::SmallVectorBase::empty(), llvm::SmallVectorTemplateCommon< T >::end(), getAsPass(), llvm::Pass::getAsPMDataManager(), getDepth(), llvm::PassRegistry::getPassInfo(), llvm::PassRegistry::getPassRegistry(), llvm::AnalysisResolver::getPMDataManager(), llvm::Pass::getResolver(), I, llvm_unreachable, PassVector, llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back(), recordAvailableAnalysis(), removeNotPreservedAnalysis(), llvm::PMTopLevelManager::setLastUser(), llvm::Pass::setResolver(), and TPM.

Referenced by llvm::LoopPass::assignPassManager(), llvm::RegionPass::assignPassManager(), llvm::ModulePass::assignPassManager(), and llvm::FunctionPass::assignPassManager().

void PMDataManager::addLowerLevelRequiredPass	(	Pass *	P,
		Pass *	RequiredPass
	)

virtual

Add RequiredPass into list of lower level passes required by pass P. RequiredPass is run on the fly by Pass Manager when P requests it through getAnalysis interface.

Add RequiredPass into list of lower level passes required by pass P. RequiredPass is run on the fly by Pass Manager when P requests it through getAnalysis interface. This should be handled by specific pass manager.

Definition at line 1239 of file LegacyPassManager.cpp.

References llvm::dbgs(), llvm::PMTopLevelManager::dumpArguments(), llvm::PMTopLevelManager::dumpPasses(), llvm::Pass::getPassName(), llvm_unreachable, and TPM.

Referenced by add().

void PMDataManager::collectRequiredAnalysis	(	SmallVectorImpl< Pass * > &	RP,
		SmallVectorImpl< AnalysisID > &	RP_NotAvail,
		Pass *	P
	)

Populate RequiredPasses with analysis pass that are required by pass P and are available. Populate ReqPassNotAvailable with analysis pass that are required by pass P but are not available.

Populate RP with analysis pass that are required by pass P and are available. Populate RP_NotAvail with analysis pass that are required by pass P but are not available.

Definition at line 1061 of file LegacyPassManager.cpp.

References llvm::SmallVectorTemplateCommon< T, typename >::begin(), llvm::SmallVectorTemplateCommon< T, typename >::end(), findAnalysisPass(), llvm::PMTopLevelManager::findAnalysisUsage(), llvm::AnalysisUsage::getRequiredSet(), llvm::AnalysisUsage::getRequiredTransitiveSet(), I, llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back(), llvm::SmallVectorTemplateBase< T, isPodLike >::push_back(), and TPM.

Referenced by add().

void PMDataManager::dumpLastUses	(	Pass *	P,
		unsigned	Offset
	)		const

Definition at line 1124 of file LegacyPassManager.cpp.

References llvm::SmallVectorTemplateCommon< T >::begin(), llvm::PMTopLevelManager::collectLastUses(), llvm::dbgs(), llvm::SmallVectorTemplateCommon< T >::end(), I, and TPM.

Referenced by llvm::LPPassManager::dumpPassStructure(), and llvm::RGPassManager::dumpPassStructure().

void PMDataManager::dumpPassArguments ( ) const

Definition at line 1141 of file LegacyPassManager.cpp.

References llvm::dbgs(), llvm::PassRegistry::getPassRegistry(), I, and PassVector.

void PMDataManager::dumpPassInfo	(	Pass *	P,
		enum PassDebuggingString	S1,
		enum PassDebuggingString	S2,
		StringRef	Msg
	)

Definition at line 1154 of file LegacyPassManager.cpp.

References llvm::dbgs(), llvm::EXECUTION_MSG, llvm::FREEING_MSG, getDepth(), llvm::Pass::getPassName(), llvm::MODIFICATION_MSG, llvm::ON_BASICBLOCK_MSG, llvm::ON_CG_MSG, llvm::ON_FUNCTION_MSG, llvm::ON_LOOP_MSG, llvm::ON_MODULE_MSG, llvm::ON_REGION_MSG, and PassDebugging.

Referenced by freePass(), llvm::LPPassManager::runOnFunction(), and llvm::RGPassManager::runOnFunction().

void PMDataManager::dumpPreservedSet ( const Pass * P ) const

Definition at line 1206 of file LegacyPassManager.cpp.

References llvm::Pass::getAnalysisUsage(), llvm::AnalysisUsage::getPreservedSet(), and PassDebugging.

Referenced by llvm::LPPassManager::runOnFunction(), and llvm::RGPassManager::runOnFunction().

void PMDataManager::dumpRequiredSet ( const Pass * P ) const

Definition at line 1197 of file LegacyPassManager.cpp.

References llvm::Pass::getAnalysisUsage(), llvm::AnalysisUsage::getRequiredSet(), and PassDebugging.

Referenced by llvm::LPPassManager::runOnFunction(), and llvm::RGPassManager::runOnFunction().

Pass * PMDataManager::findAnalysisPass	(	AnalysisID	AID,
		bool	SearchParent
	)

Find the pass that implements Analysis AID. If desired pass is not found then return NULL.

Definition at line 1108 of file LegacyPassManager.cpp.

References llvm::PMTopLevelManager::findAnalysisPass(), I, if(), and TPM.

Referenced by collectRequiredAnalysis(), llvm::AnalysisResolver::getAnalysisIfAvailable(), initializeAnalysisImpl(), and verifyPreservedAnalysis().

void PMDataManager::freePass	(	Pass *	P,
		StringRef	Msg,
		enum PassDebuggingString	DBG_STR
	)

Remove P.

Definition at line 950 of file LegacyPassManager.cpp.

References dumpPassInfo(), llvm::FREEING_MSG, llvm::Pass::getPassID(), llvm::PassRegistry::getPassRegistry(), llvm::getPassTimer(), P, llvm::Pass::releaseMemory(), and llvm::X.

Referenced by removeDeadPasses(), llvm::LPPassManager::runOnFunction(), and llvm::RGPassManager::runOnFunction().

virtual Pass* llvm::PMDataManager::getAsPass ( )

pure virtual

Implemented in llvm::FPPassManager, llvm::legacy::PassManagerImpl, llvm::legacy::FunctionPassManagerImpl, llvm::RGPassManager, and llvm::LPPassManager.

Referenced by add(), and llvm::PMTopLevelManager::setLastUser().

DenseMap<AnalysisID, Pass*>* llvm::PMDataManager::getAvailableAnalysis ( )

inline

Definition at line 355 of file LegacyPassManagers.h.

unsigned llvm::PMDataManager::getDepth ( ) const

inline

Definition at line 335 of file LegacyPassManagers.h.

Referenced by add(), dumpPassInfo(), llvm::PMStack::push(), and llvm::PMTopLevelManager::setLastUser().

unsigned llvm::PMDataManager::getNumContainedPasses ( ) const

inline

Definition at line 346 of file LegacyPassManagers.h.

References PassVector.

Referenced by llvm::LPPassManager::cloneBasicBlockSimpleAnalysis(), llvm::LPPassManager::deleteSimpleAnalysisValue(), llvm::LPPassManager::dumpPassStructure(), llvm::RGPassManager::dumpPassStructure(), llvm::legacy::FunctionPassManagerImpl::releaseMemoryOnTheFly(), llvm::LPPassManager::runOnFunction(), and llvm::RGPassManager::runOnFunction().

Pass * PMDataManager::getOnTheFlyPass	(	Pass *	P,
		AnalysisID	PI,
		Function &	F
	)

virtual

Definition at line 1261 of file LegacyPassManager.cpp.

References llvm_unreachable.

Referenced by llvm::AnalysisResolver::findImplPass().

virtual PassManagerType llvm::PMDataManager::getPassManagerType ( ) const

inlinevirtual

Reimplemented in llvm::FPPassManager, llvm::RGPassManager, and llvm::LPPassManager.

Definition at line 350 of file LegacyPassManagers.h.

References llvm::PMT_Unknown.

Referenced by llvm::LoopPass::assignPassManager(), llvm::CallGraphSCCPass::assignPassManager(), llvm::RegionPass::assignPassManager(), llvm::ModulePass::assignPassManager(), llvm::FunctionPass::assignPassManager(), llvm::BasicBlockPass::assignPassManager(), llvm::LoopPass::preparePassManager(), llvm::RegionPass::preparePassManager(), and llvm::PMStack::push().

PMTopLevelManager* llvm::PMDataManager::getTopLevelManager ( )

inline

Definition at line 332 of file LegacyPassManagers.h.

References TPM.

void PMDataManager::initializeAnalysisImpl ( Pass * P )

All Required analyses should be available to the pass as it runs! Here we fill in the AnalysisImpls member of the pass so that it can successfully use the getAnalysis() method to retrieve the implementations it needs.

Definition at line 1089 of file LegacyPassManager.cpp.

References llvm::AnalysisResolver::addAnalysisImplsPair(), llvm::SmallVectorTemplateCommon< T, typename >::begin(), llvm::SmallVectorTemplateCommon< T, typename >::end(), findAnalysisPass(), llvm::PMTopLevelManager::findAnalysisUsage(), llvm::AnalysisUsage::getRequiredSet(), llvm::Pass::getResolver(), I, and TPM.

Referenced by llvm::LPPassManager::runOnFunction(), llvm::RGPassManager::runOnFunction(), and llvm::PMTopLevelManager::schedulePass().

void llvm::PMDataManager::initializeAnalysisInfo ( )

inline

Initialize available analysis information.

Definition at line 303 of file LegacyPassManagers.h.

References InheritedAnalysis, and llvm::PMT_Last.

Referenced by PMDataManager(), and llvm::PMStack::pop().

bool PMDataManager::isPassDebuggingExecutionsOrMore ( ) const

protected

isPassDebuggingExecutionsOrMore - Return true if -debug-pass=Executions or higher is specified.
