llvm::VectorType Class Reference

#include <DerivedTypes.h>

Inheritance diagram for llvm::VectorType:
Inheritance graph
[legend]
Collaboration diagram for llvm::VectorType:
Collaboration graph
[legend]

Public Member Functions

unsigned getNumElements () const
 Return the number of elements in the Vector type. More...

unsigned getBitWidth () const
 Return the number of bits in the Vector type. Returns zero when the vector is a vector of pointers. More...

- Public Member Functions inherited from llvm::SequentialType
TypegetElementType () const

- Public Member Functions inherited from llvm::CompositeType
TypegetTypeAtIndex (const Value *V)

TypegetTypeAtIndex (unsigned Idx)

bool indexValid (const Value *V) const

bool indexValid (unsigned Idx) const

- Public Member Functions inherited from llvm::Type
void print (raw_ostream &O) const

void dump () const

LLVMContextgetContext () const
 getContext - Return the LLVMContext in which this type was uniqued. More...

TypeID getTypeID () const

bool isVoidTy () const
 isVoidTy - Return true if this is 'void'. More...

bool isHalfTy () const
 isHalfTy - Return true if this is 'half', a 16-bit IEEE fp type. More...

bool isFloatTy () const
 isFloatTy - Return true if this is 'float', a 32-bit IEEE fp type. More...

bool isDoubleTy () const
 isDoubleTy - Return true if this is 'double', a 64-bit IEEE fp type. More...

bool isX86_FP80Ty () const
 isX86_FP80Ty - Return true if this is x86 long double. More...

bool isFP128Ty () const
 isFP128Ty - Return true if this is 'fp128'. More...

bool isPPC_FP128Ty () const
 isPPC_FP128Ty - Return true if this is powerpc long double. More...

bool isFloatingPointTy () const

const fltSemanticsgetFltSemantics () const

bool isX86_MMXTy () const
 isX86_MMXTy - Return true if this is X86 MMX. More...

bool isFPOrFPVectorTy () const

bool isLabelTy () const
 isLabelTy - Return true if this is 'label'. More...

bool isMetadataTy () const
 isMetadataTy - Return true if this is 'metadata'. More...

bool isIntegerTy () const

bool isIntegerTy (unsigned Bitwidth) const
 isIntegerTy - Return true if this is an IntegerType of the given width. More...

bool isIntOrIntVectorTy () const

bool isFunctionTy () const

bool isStructTy () const

bool isArrayTy () const

bool isPointerTy () const

bool isPtrOrPtrVectorTy () const

bool isVectorTy () const

bool canLosslesslyBitCastTo (Type *Ty) const
 Determine if this type could be losslessly bitcast to Ty. More...

bool isEmptyTy () const

bool isPrimitiveType () const

bool isDerivedType () const

bool isFirstClassType () const

bool isSingleValueType () const

bool isAggregateType () const

bool isSized () const

unsigned getPrimitiveSizeInBits () const

unsigned getScalarSizeInBits ()

int getFPMantissaWidth () const

const TypegetScalarType () const

TypegetScalarType ()

subtype_iterator subtype_begin () const

subtype_iterator subtype_end () const

subtype_reverse_iterator subtype_rbegin () const

subtype_reverse_iterator subtype_rend () const

TypegetContainedType (unsigned i) const

unsigned getNumContainedTypes () const

unsigned getIntegerBitWidth () const

TypegetFunctionParamType (unsigned i) const

unsigned getFunctionNumParams () const

bool isFunctionVarArg () const

StringRef getStructName () const

unsigned getStructNumElements () const

TypegetStructElementType (unsigned N) const

TypegetSequentialElementType () const

uint64_t getArrayNumElements () const

TypegetArrayElementType () const

unsigned getVectorNumElements () const

TypegetVectorElementType () const

TypegetPointerElementType () const

unsigned getPointerAddressSpace () const
 Get the address space of this pointer or pointer vector type. More...

PointerTypegetPointerTo (unsigned AddrSpace=0)


Static Public Member Functions

static VectorTypeget (Type *ElementType, unsigned NumElements)

static VectorTypegetInteger (VectorType *VTy)

static VectorTypegetExtendedElementVectorType (VectorType *VTy)

static VectorTypegetTruncatedElementVectorType (VectorType *VTy)

static bool isValidElementType (Type *ElemTy)

static bool classof (const Type *T)
 Methods for support type inquiry through isa, cast, and dyn_cast. More...

- Static Public Member Functions inherited from llvm::SequentialType
static bool classof (const Type *T)
 Methods for support type inquiry through isa, cast, and dyn_cast. More...

- Static Public Member Functions inherited from llvm::CompositeType
static bool classof (const Type *T)
 Methods for support type inquiry through isa, cast, and dyn_cast. More...

- Static Public Member Functions inherited from llvm::Type
static TypegetPrimitiveType (LLVMContext &C, TypeID IDNumber)
 getPrimitiveType - Return a type based on an identifier. More...

static TypegetVoidTy (LLVMContext &C)

static TypegetLabelTy (LLVMContext &C)

static TypegetHalfTy (LLVMContext &C)

static TypegetFloatTy (LLVMContext &C)

static TypegetDoubleTy (LLVMContext &C)

static TypegetMetadataTy (LLVMContext &C)

static TypegetX86_FP80Ty (LLVMContext &C)

static TypegetFP128Ty (LLVMContext &C)

static TypegetPPC_FP128Ty (LLVMContext &C)

static TypegetX86_MMXTy (LLVMContext &C)

static IntegerTypegetIntNTy (LLVMContext &C, unsigned N)

static IntegerTypegetInt1Ty (LLVMContext &C)

static IntegerTypegetInt8Ty (LLVMContext &C)

static IntegerTypegetInt16Ty (LLVMContext &C)

static IntegerTypegetInt32Ty (LLVMContext &C)

static IntegerTypegetInt64Ty (LLVMContext &C)

static PointerTypegetHalfPtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetFloatPtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetDoublePtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetX86_FP80PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetFP128PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetPPC_FP128PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetX86_MMXPtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetIntNPtrTy (LLVMContext &C, unsigned N, unsigned AS=0)

static PointerTypegetInt1PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetInt8PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetInt16PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetInt32PtrTy (LLVMContext &C, unsigned AS=0)

static PointerTypegetInt64PtrTy (LLVMContext &C, unsigned AS=0)


Additional Inherited Members

- Public Types inherited from llvm::Type
enum  TypeID {
  VoidTyID = 0, HalfTyID, FloatTyID, DoubleTyID,
  X86_FP80TyID, FP128TyID, PPC_FP128TyID, LabelTyID,
  MetadataTyID, X86_MMXTyID, IntegerTyID, FunctionTyID,
  StructTyID, ArrayTyID, PointerTyID, VectorTyID,
  NumTypeIDs, LastPrimitiveTyID = X86_MMXTyID, FirstDerivedTyID = IntegerTyID
}

typedef Type *const * subtype_iterator

typedef std::reverse_iterator
< subtype_iterator
subtype_reverse_iterator

- Protected Member Functions inherited from llvm::SequentialType
 SequentialType (TypeID TID, Type *ElType)

- Protected Member Functions inherited from llvm::CompositeType
 CompositeType (LLVMContext &C, TypeID tid)

- Protected Member Functions inherited from llvm::Type
 Type (LLVMContext &C, TypeID tid)

 ~Type ()

void setTypeID (TypeID ID)

unsigned getSubclassData () const

void setSubclassData (unsigned val)

- Protected Attributes inherited from llvm::Type
unsigned NumContainedTys

Type *const * ContainedTys


Detailed Description

VectorType - Class to represent vector types.

Definition at line 358 of file DerivedTypes.h.

Member Function Documentation

static bool llvm::VectorType::classof ( const Type T)
inlinestatic

Methods for support type inquiry through isa, cast, and dyn_cast.

Definition at line 417 of file DerivedTypes.h.

References llvm::Type::getTypeID(), and llvm::Type::VectorTyID.

VectorType * VectorType::get ( Type ElementType,
unsigned  NumElements
)
static
unsigned llvm::VectorType::getBitWidth ( ) const
inline

Return the number of bits in the Vector type. Returns zero when the vector is a vector of pointers.

Definition at line 412 of file DerivedTypes.h.

static VectorType* llvm::VectorType::getExtendedElementVectorType ( VectorType VTy)
inlinestatic

VectorType::getExtendedElementVectorType - This static method is like getInteger except that the element types are twice as wide as the elements in the input type.

Definition at line 385 of file DerivedTypes.h.

References llvm::IntegerType::get(), get(), llvm::Type::getContext(), llvm::SequentialType::getElementType(), getNumElements(), and llvm::Type::getPrimitiveSizeInBits().

Referenced by DecodeFixedType().

static VectorType* llvm::VectorType::getInteger ( VectorType VTy)
inlinestatic

VectorType::getInteger - This static method gets a VectorType with the same number of elements as the input type, and the element type is an integer type of the same width as the input element type.

Definition at line 374 of file DerivedTypes.h.

References llvm::IntegerType::get(), get(), llvm::Type::getContext(), llvm::SequentialType::getElementType(), getNumElements(), and llvm::Type::getPrimitiveSizeInBits().

unsigned llvm::VectorType::getNumElements ( ) const
inline
static VectorType* llvm::VectorType::getTruncatedElementVectorType ( VectorType VTy)
inlinestatic

VectorType::getTruncatedElementVectorType - This static method is like getInteger except that the element types are half as wide as the elements in the input type.

Definition at line 395 of file DerivedTypes.h.

References llvm::IntegerType::get(), get(), llvm::Type::getContext(), llvm::SequentialType::getElementType(), getNumElements(), and llvm::Type::getPrimitiveSizeInBits().

Referenced by DecodeFixedType().

bool VectorType::isValidElementType ( Type ElemTy)
static

isValidElementType - Return true if the specified type is valid as a element type.

Definition at line 721 of file Type.cpp.

References llvm::Type::isFloatingPointTy(), llvm::Type::isIntegerTy(), and llvm::Type::isPointerTy().

Referenced by get().


The documentation for this class was generated from the following files:
