LoopIdiomRecognize.cpp File Reference

#include "llvm/Transforms/Scalar.h"
#include "llvm/ADT/Statistic.h"
#include "llvm/Analysis/AliasAnalysis.h"
#include "llvm/Analysis/LoopPass.h"
#include "llvm/Analysis/ScalarEvolutionExpander.h"
#include "llvm/Analysis/ScalarEvolutionExpressions.h"
#include "llvm/Analysis/TargetTransformInfo.h"
#include "llvm/Analysis/ValueTracking.h"
#include "llvm/IR/DataLayout.h"
#include "llvm/IR/IRBuilder.h"
#include "llvm/IR/IntrinsicInst.h"
#include "llvm/IR/Module.h"
#include "llvm/Support/Debug.h"
#include "llvm/Support/raw_ostream.h"
#include "llvm/Target/TargetLibraryInfo.h"
#include "llvm/Transforms/Utils/Local.h"

Include dependency graph for LoopIdiomRecognize.cpp:

Go to the source code of this file.

Macros
#define	DEBUG_TYPE   "loop-idiom"

Functions
	STATISTIC (NumMemSet,"Number of memset's formed from loop stores")
	STATISTIC (NumMemCpy,"Number of memcpy's formed from loop load+stores")
	INITIALIZE_PASS_BEGIN (LoopIdiomRecognize,"loop-idiom","Recognize loop idioms", false, false) INITIALIZE_PASS_END(LoopIdiomRecognize
static void	deleteDeadInstruction (Instruction *I, ScalarEvolution &SE, const TargetLibraryInfo *TLI)
static void	deleteIfDeadInstruction (Value *V, ScalarEvolution &SE, const TargetLibraryInfo *TLI)
static bool	mayLoopAccessLocation (Value *Ptr, AliasAnalysis::ModRefResult Access, Loop *L, const SCEV *BECount, unsigned StoreSize, AliasAnalysis &AA, Instruction *IgnoredStore)
static Constant *	getMemSetPatternValue (Value *V, const DataLayout &TD)

Variables
loop	idiom
loop Recognize loop	idioms
loop Recognize loop	false

Macro Definition Documentation

#define DEBUG_TYPE   "loop-idiom"

Definition at line 44 of file LoopIdiomRecognize.cpp.

Function Documentation

static void deleteDeadInstruction ( Instruction *  I, ScalarEvolution &  SE, const TargetLibraryInfo *  TLI  )

static

deleteDeadInstruction - Delete this instruction. Before we do, go through and zero out all the operands of this instruction. If any of them become dead, delete them and the computation tree that feeds them.

Definition at line 231 of file LoopIdiomRecognize.cpp.

References llvm::SmallVectorBase::empty(), llvm::Instruction::eraseFromParent(), llvm::ScalarEvolution::forgetValue(), llvm::User::getNumOperands(), llvm::User::getOperand(), llvm::isInstructionTriviallyDead(), llvm::SmallVectorImpl< T >::pop_back_val(), llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back(), llvm::User::setOperand(), and llvm::Value::use_empty().

Referenced by deleteIfDeadInstruction().

static void deleteIfDeadInstruction ( Value *  V, ScalarEvolution &  SE, const TargetLibraryInfo *  TLI  )

static

deleteIfDeadInstruction - If the specified value is a dead instruction, delete it and any recursively used instructions.

Definition at line 264 of file LoopIdiomRecognize.cpp.

References deleteDeadInstruction(), I, and llvm::isInstructionTriviallyDead().

static Constant* getMemSetPatternValue ( Value *  V, const DataLayout &  TD  )

static

getMemSetPatternValue - If a strided store of the specified value is safe to turn into a memset_pattern16, return a ConstantArray of 16 bytes that should be passed in. Otherwise, return null.

Note that we don't ever attempt to use memset_pattern8 or 4, because these just replicate their input array and then pass on to memset_pattern16.

Definition at line 908 of file LoopIdiomRecognize.cpp.

References llvm::CallingConv::C, llvm::dyn_cast(), llvm::Value::getType(), llvm::DataLayout::getTypeSizeInBits(), and llvm::DataLayout::isBigEndian().

INITIALIZE_PASS_BEGIN	(	LoopIdiomRecognize	,
		"loop-idiom"	,
		"Recognize loop idioms"	,
		false	,
		false
	)

static bool mayLoopAccessLocation ( Value *  Ptr, AliasAnalysis::ModRefResult  Access, Loop *  L, const SCEV *  BECount, unsigned  StoreSize, AliasAnalysis &  AA, Instruction *  IgnoredStore  )

static

mayLoopAccessLocation - Return true if the specified loop might access the specified pointer location, which is a loop-strided access. The 'Access' argument specifies what the verboten forms of access are (read or write).

Definition at line 872 of file LoopIdiomRecognize.cpp.

References llvm::LoopBase< N, M >::block_begin(), llvm::LoopBase< N, M >::block_end(), llvm::AliasAnalysis::getModRefInfo(), and I.

STATISTIC	(	NumMemSet	,
		"Number of memset's formed from loop stores"
	)

STATISTIC	(	NumMemCpy	,
		"Number of memcpy's formed from loop load+stores"
	)

Variable Documentation

loop Recognize loop false

Definition at line 222 of file LoopIdiomRecognize.cpp.

loop idiom

Definition at line 222 of file LoopIdiomRecognize.cpp.

loop Recognize loop idioms

Definition at line 222 of file LoopIdiomRecognize.cpp.
