Base class of casting instructions. More...

#include <InstrTypes.h>

Inheritance diagram for llvm::CastInst:

Collaboration diagram for llvm::CastInst:

Public Member Functions
bool	isIntegerCast () const
	Determine if this is an integer-only cast. More...

bool	isLosslessCast () const
	Determine if this is a lossless cast. More...

bool	isNoopCast (Type *IntPtrTy) const
	Determine if this cast is a no-op cast. More...

Instruction::CastOps	getOpcode () const
	Return the opcode of this CastInst. More...

Type *	getSrcTy () const
	Return the source type, as a convenience. More...

Type *	getDestTy () const
	Return the destination type, as a convenience. More...

Public Member Functions inherited from llvm::UnaryInstruction
void *	operator new (size_t s)

	~UnaryInstruction ()

	DECLARE_TRANSPARENT_OPERAND_ACCESSORS (Value)
	Transparently provide more efficient getOperand methods. More...

Public Member Functions inherited from llvm::Instruction
	~Instruction ()

Instruction *	use_back ()

const Instruction *	use_back () const

const BasicBlock *	getParent () const

BasicBlock *	getParent ()

void	removeFromParent ()

void	eraseFromParent ()

void	insertBefore (Instruction *InsertPos)

void	insertAfter (Instruction *InsertPos)

void	moveBefore (Instruction *MovePos)

unsigned	getOpcode () const
	getOpcode() returns a member of one of the enums like Instruction::Add. More...

const char *	getOpcodeName () const

bool	isTerminator () const

bool	isBinaryOp () const

bool	isShift ()

bool	isCast () const

bool	isLogicalShift () const

bool	isArithmeticShift () const
	isArithmeticShift - Return true if this is an arithmetic shift right. More...

bool	hasMetadata () const

bool	hasMetadataOtherThanDebugLoc () const

MDNode *	getMetadata (unsigned KindID) const

MDNode *	getMetadata (StringRef Kind) const

void	getAllMetadata (SmallVectorImpl< std::pair< unsigned, MDNode * > > &MDs) const

void	getAllMetadataOtherThanDebugLoc (SmallVectorImpl< std::pair< unsigned, MDNode * > > &MDs) const

void	setMetadata (unsigned KindID, MDNode *Node)

void	setMetadata (StringRef Kind, MDNode *Node)

void	setDebugLoc (const DebugLoc &Loc)
	setDebugLoc - Set the debug location information for this instruction. More...

const DebugLoc &	getDebugLoc () const
	getDebugLoc - Return the debug location for this node as a DebugLoc. More...

void	setHasUnsafeAlgebra (bool B)

void	setHasNoNaNs (bool B)

void	setHasNoInfs (bool B)

void	setHasNoSignedZeros (bool B)

void	setHasAllowReciprocal (bool B)

void	setFastMathFlags (FastMathFlags FMF)

bool	hasUnsafeAlgebra () const
	Determine whether the unsafe-algebra flag is set. More...

bool	hasNoNaNs () const
	Determine whether the no-NaNs flag is set. More...

bool	hasNoInfs () const
	Determine whether the no-infs flag is set. More...

bool	hasNoSignedZeros () const
	Determine whether the no-signed-zeros flag is set. More...

bool	hasAllowReciprocal () const
	Determine whether the allow-reciprocal flag is set. More...

FastMathFlags	getFastMathFlags () const

void	copyFastMathFlags (const Instruction *I)
	Copy I's fast-math flags. More...

bool	isAssociative () const

bool	isCommutative () const

bool	isIdempotent () const

bool	isNilpotent () const

bool	mayWriteToMemory () const

bool	mayReadFromMemory () const

bool	mayReadOrWriteMemory () const

bool	mayThrow () const

bool	mayReturn () const

bool	mayHaveSideEffects () const

Instruction *	clone () const

bool	isIdenticalTo (const Instruction *I) const

bool	isIdenticalToWhenDefined (const Instruction *I) const

bool	isSameOperationAs (const Instruction *I, unsigned flags=0) const
	Determine if one instruction is the same operation as another. More...

bool	isUsedOutsideOfBlock (const BasicBlock *BB) const

Public Member Functions inherited from llvm::User
	~User ()

void	operator delete (void *Usr)
	operator delete - free memory allocated for User and Use objects More...

void	operator delete (void *, unsigned)
	placement delete - required by std, but never called. More...

void	operator delete (void *, unsigned, bool)
	placement delete - required by std, but never called. More...

Value *	getOperand (unsigned i) const

void	setOperand (unsigned i, Value *Val)

const Use &	getOperandUse (unsigned i) const

Use &	getOperandUse (unsigned i)

unsigned	getNumOperands () const

op_iterator	op_begin ()

const_op_iterator	op_begin () const

op_iterator	op_end ()

const_op_iterator	op_end () const

value_op_iterator	value_op_begin ()

value_op_iterator	value_op_end ()

void	dropAllReferences ()

void	replaceUsesOfWith (Value From, Value To)

Public Member Functions inherited from llvm::Value
virtual	~Value ()

void	dump () const
	dump - Support for debugging, callable in GDB: V->dump() More...

void	print (raw_ostream &O, AssemblyAnnotationWriter *AAW=0) const

Type *	getType () const

LLVMContext &	getContext () const
	All values hold a context through their type. More...

bool	hasName () const

ValueName *	getValueName () const

void	setValueName (ValueName *VN)

StringRef	getName () const

void	setName (const Twine &Name)

void	takeName (Value *V)

void	replaceAllUsesWith (Value *V)

bool	use_empty () const

use_iterator	use_begin ()

const_use_iterator	use_begin () const

use_iterator	use_end ()

const_use_iterator	use_end () const

User *	use_back ()

const User *	use_back () const

bool	hasOneUse () const

bool	hasNUses (unsigned N) const

bool	hasNUsesOrMore (unsigned N) const

bool	isUsedInBasicBlock (const BasicBlock *BB) const

unsigned	getNumUses () const

void	addUse (Use &U)

unsigned	getValueID () const

unsigned	getRawSubclassOptionalData () const

void	clearSubclassOptionalData ()

bool	hasSameSubclassOptionalData (const Value *V) const

void	intersectOptionalDataWith (const Value *V)

bool	hasValueHandle () const

Value *	stripPointerCasts ()
	Strips off any unneeded pointer casts, all-zero GEPs and aliases from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCasts () const

Value *	stripPointerCastsNoFollowAliases ()
	Strips off any unneeded pointer casts and all-zero GEPs from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCastsNoFollowAliases () const

Value *	stripInBoundsConstantOffsets ()
	Strips off unneeded pointer casts and all-constant GEPs from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsConstantOffsets () const

Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset)
	Strips like `stripInBoundsConstantOffsets` but also accumulates the constant offset stripped. More...

const Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset) const

Value *	stripInBoundsOffsets ()
	Strips off unneeded pointer casts and any in-bounds offsets from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsOffsets () const

bool	isDereferenceablePointer () const

Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB)

const Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB) const

void	mutateType (Type *Ty)

Public Member Functions inherited from llvm::ilist_node< Instruction >
Instruction *	getPrevNode ()
	Get the previous node, or 0 for the list head. More...

const Instruction *	getPrevNode () const
	Get the previous node, or 0 for the list head. More...

Instruction *	getNextNode ()
	Get the next node, or 0 for the list tail. More...

const Instruction *	getNextNode () const
	Get the next node, or 0 for the list tail. More...

Static Public Member Functions
static CastInst *	Create (Instruction::CastOps, Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Construct any of the CastInst subclasses. More...

static CastInst *	Create (Instruction::CastOps, Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Construct any of the CastInst subclasses. More...

static CastInst *	CreateZExtOrBitCast (Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Create a ZExt or BitCast cast instruction. More...

static CastInst *	CreateZExtOrBitCast (Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Create a ZExt or BitCast cast instruction. More...

static CastInst *	CreateSExtOrBitCast (Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Create a SExt or BitCast cast instruction. More...

static CastInst *	CreateSExtOrBitCast (Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Create a SExt or BitCast cast instruction. More...

static CastInst *	CreatePointerCast (Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Create a BitCast or a PtrToInt cast instruction. More...

static CastInst *	CreatePointerCast (Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Create a BitCast or a PtrToInt cast instruction. More...

static CastInst *	CreateIntegerCast (Value S, Type Ty, bool isSigned, const Twine &Name="", Instruction *InsertBefore=0)
	Create a ZExt, BitCast, or Trunc for int -> int casts. More...

static CastInst *	CreateIntegerCast (Value S, Type Ty, bool isSigned, const Twine &Name, BasicBlock *InsertAtEnd)
	Create a ZExt, BitCast, or Trunc for int -> int casts. More...

static CastInst *	CreateFPCast (Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Create an FPExt, BitCast, or FPTrunc for fp -> fp casts. More...

static CastInst *	CreateFPCast (Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Create an FPExt, BitCast, or FPTrunc for fp -> fp casts. More...

static CastInst *	CreateTruncOrBitCast (Value S, Type Ty, const Twine &Name="", Instruction *InsertBefore=0)
	Create a Trunc or BitCast cast instruction. More...

static CastInst *	CreateTruncOrBitCast (Value S, Type Ty, const Twine &Name, BasicBlock *InsertAtEnd)
	Create a Trunc or BitCast cast instruction. More...

static bool	isCastable (Type SrcTy, Type DestTy)
	Check whether it is valid to call getCastOpcode for these types. More...

static bool	isBitCastable (Type SrcTy, Type DestTy)
	Check whether a bitcast between these types is valid. More...

static Instruction::CastOps	getCastOpcode (const Value Val, bool SrcIsSigned, Type Ty, bool DstIsSigned)
	Infer the opcode for cast operand and type. More...

static bool	isNoopCast (Instruction::CastOps Opcode, Type SrcTy, Type DstTy, Type *IntPtrTy)
	Determine if the described cast is a no-op cast. More...

static unsigned	isEliminableCastPair (Instruction::CastOps firstOpcode, Instruction::CastOps secondOpcode, Type SrcTy, Type MidTy, Type DstTy, Type SrcIntPtrTy, Type MidIntPtrTy, Type DstIntPtrTy)
	Determine if a cast pair is eliminable. More...

static bool	castIsValid (Instruction::CastOps op, Value S, Type DstTy)
	Determine if a cast is valid without creating one. More...

static bool	classof (const Instruction *I)
	Methods for support type inquiry through isa, cast, and dyn_cast: More...

static bool	classof (const Value *V)

Static Public Member Functions inherited from llvm::UnaryInstruction
static bool	classof (const Instruction *I)

static bool	classof (const Value *V)

Static Public Member Functions inherited from llvm::Instruction
static const char *	getOpcodeName (unsigned OpCode)

static bool	isTerminator (unsigned OpCode)

static bool	isBinaryOp (unsigned Opcode)

static bool	isShift (unsigned Opcode)
	Determine if the Opcode is one of the shift instructions. More...

static bool	isCast (unsigned OpCode)
	Determine if the OpCode is one of the CastInst instructions. More...

static bool	isAssociative (unsigned op)

static bool	isCommutative (unsigned op)

static bool	isIdempotent (unsigned op)

static bool	isNilpotent (unsigned op)

static bool	classof (const Value *V)
	Methods for support type inquiry through isa, cast, and dyn_cast: More...

Static Public Member Functions inherited from llvm::User
static bool	classof (const Value *V)

Protected Member Functions
	CastInst (Type Ty, unsigned iType, Value S, const Twine &NameStr="", Instruction *InsertBefore=0)
	Constructor with insert-before-instruction semantics for subclasses. More...

	CastInst (Type Ty, unsigned iType, Value S, const Twine &NameStr, BasicBlock *InsertAtEnd)
	Constructor with insert-at-end-of-block semantics for subclasses. More...

Protected Member Functions inherited from llvm::UnaryInstruction
	UnaryInstruction (Type Ty, unsigned iType, Value V, Instruction *IB=0)

	UnaryInstruction (Type Ty, unsigned iType, Value V, BasicBlock *IAE)

Protected Member Functions inherited from llvm::Instruction
void	setInstructionSubclassData (unsigned short D)

unsigned	getSubclassDataFromInstruction () const

	Instruction (Type Ty, unsigned iType, Use Ops, unsigned NumOps, Instruction *InsertBefore=0)

	Instruction (Type Ty, unsigned iType, Use Ops, unsigned NumOps, BasicBlock *InsertAtEnd)

virtual Instruction *	clone_impl () const =0

Protected Member Functions inherited from llvm::User
void *	operator new (size_t s, unsigned Us)

	User (Type ty, unsigned vty, Use OpList, unsigned NumOps)

Use *	allocHungoffUses (unsigned) const

void	dropHungoffUses ()

template<int Idx>
Use &	Op ()

template<int Idx>
const Use &	Op () const

Protected Member Functions inherited from llvm::Value
virtual void	printCustom (raw_ostream &O) const

	Value (Type *Ty, unsigned scid)

unsigned short	getSubclassDataFromValue () const

void	setValueSubclassData (unsigned short D)

Protected Member Functions inherited from llvm::ilist_node< Instruction >
	ilist_node ()

Additional Inherited Members
Public Types inherited from llvm::Instruction
enum	OperationEquivalenceFlags { CompareIgnoringAlignment = 1<<0, CompareUsingScalarTypes = 1<<1 }

enum	TermOps

enum	BinaryOps

enum	MemoryOps

enum	CastOps

enum	OtherOps

Public Types inherited from llvm::User
typedef Use *	op_iterator

typedef const Use *	const_op_iterator

Public Types inherited from llvm::Value
enum	ValueTy { ArgumentVal, BasicBlockVal, FunctionVal, GlobalAliasVal, GlobalVariableVal, UndefValueVal, BlockAddressVal, ConstantExprVal, ConstantAggregateZeroVal, ConstantDataArrayVal, ConstantDataVectorVal, ConstantIntVal, ConstantFPVal, ConstantArrayVal, ConstantStructVal, ConstantVectorVal, ConstantPointerNullVal, MDNodeVal, MDStringVal, InlineAsmVal, PseudoSourceValueVal, FixedStackPseudoSourceValueVal, InstructionVal, ConstantFirstVal = FunctionVal, ConstantLastVal = ConstantPointerNullVal }

typedef value_use_iterator< User >	use_iterator

typedef value_use_iterator < const User >	const_use_iterator

Static Public Attributes inherited from llvm::Value
static const unsigned	MaximumAlignment = 1u << 29

Static Protected Member Functions inherited from llvm::User
template<int Idx, typename U >
static Use &	OpFrom (const U *that)

Protected Attributes inherited from llvm::User
Use *	OperandList

unsigned	NumOperands

Protected Attributes inherited from llvm::Value
unsigned char	SubclassOptionalData: 7

Detailed Description

Base class of casting instructions.

CastInst - This is the base class for all instructions that perform data casts. It is simply provided so that instruction category testing can be performed with code like:

if (isa<CastInst>(Instr)) { ... }

Definition at line 387 of file InstrTypes.h.

Constructor & Destructor Documentation

llvm::CastInst::CastInst	(	Type *	Ty,
		unsigned	iType,
		Value *	S,
		const Twine &	NameStr = `""`,
		Instruction *	InsertBefore = `0`
	)

inlineprotected

Constructor with insert-before-instruction semantics for subclasses.

Definition at line 391 of file InstrTypes.h.

llvm::CastInst::CastInst	(	Type *	Ty,
		unsigned	iType,
		Value *	S,
		const Twine &	NameStr,
		BasicBlock *	InsertAtEnd
	)

inlineprotected

Constructor with insert-at-end-of-block semantics for subclasses.

Definition at line 397 of file InstrTypes.h.

Member Function Documentation

bool CastInst::castIsValid	(	Instruction::CastOps	op,
		Value *	S,
		Type *	DstTy
	)

static

Determine if a cast is valid without creating one.

This method can be used to determine if a cast from S to DstTy using Opcode op is valid or not.

Returns: true iff the proposed cast is valid.

Check that the construction parameters for a CastInst are correct. This could be broken out into the separate constructors but it is useful to have it in one place and to eliminate the redundant code for getting the sizes of the types involved.

Definition at line 2753 of file Instructions.cpp.

References llvm::Type::getPointerAddressSpace(), llvm::Type::getPrimitiveSizeInBits(), llvm::Type::getScalarSizeInBits(), llvm::Type::getScalarType(), llvm::Value::getType(), llvm::Type::getVectorNumElements(), llvm::Type::isAggregateType(), llvm::Type::isFirstClassType(), llvm::Type::isFPOrFPVectorTy(), llvm::Type::isIntegerTy(), llvm::Type::isIntOrIntVectorTy(), llvm::Type::isPointerTy(), llvm::Type::isPtrOrPtrVectorTy(), and llvm::Type::isVectorTy().

Referenced by llvm::AddrSpaceCastInst::AddrSpaceCastInst(), llvm::BitCastInst::BitCastInst(), Create(), llvm::FPExtInst::FPExtInst(), llvm::FPToSIInst::FPToSIInst(), llvm::FPToUIInst::FPToUIInst(), llvm::FPTruncInst::FPTruncInst(), llvm::ConstantExpr::getAddrSpaceCast(), llvm::ConstantExpr::getBitCast(), llvm::ConstantExpr::getCast(), llvm::IntToPtrInst::IntToPtrInst(), llvm::PtrToIntInst::PtrToIntInst(), llvm::SExtInst::SExtInst(), llvm::SIToFPInst::SIToFPInst(), llvm::TruncInst::TruncInst(), llvm::UIToFPInst::UIToFPInst(), and llvm::ZExtInst::ZExtInst().

static bool llvm::CastInst::classof ( const Instruction * I )

inlinestatic

Methods for support type inquiry through isa, cast, and dyn_cast:

Definition at line 619 of file InstrTypes.h.

References llvm::Instruction::isCast().

static bool llvm::CastInst::classof ( const Value * V )

inlinestatic

Definition at line 622 of file InstrTypes.h.

CastInst * CastInst::Create	(	Instruction::CastOps	op,
		Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Construct any of the CastInst subclasses.

Provides a way to construct any of the CastInst subclasses using an opcode instead of the subclass's constructor. The opcode must be in the CastOps category (Instruction::isCast(opcode) returns true). This constructor has insert-before-instruction semantics to automatically insert the new CastInst before InsertBefore (if it is non-null).

Parameters

op	The opcode of the cast instruction
S	The value to be casted (operand 0)
Ty	The type to which cast should be made
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2350 of file Instructions.cpp.

References castIsValid(), and llvm_unreachable.

Referenced by BuildNew(), llvm::InstCombiner::commonCastTransforms(), llvm::NoFolder::CreateCast(), llvm::IRBuilder< true, TargetFolder >::CreateCast(), CreateFPCast(), CreateIntegerCast(), CreatePointerCast(), CreateSExtOrBitCast(), CreateTruncOrBitCast(), CreateZExtOrBitCast(), llvm::InstCombiner::FoldSelectOpOp(), llvm::ConstantExpr::getAsInstruction(), OptimizeNoopCopyExpression(), llvm::UpgradeBitCastInst(), llvm::InstCombiner::visitAnd(), llvm::InstCombiner::visitBitCast(), llvm::InstCombiner::visitCallInst(), llvm::InstCombiner::visitExtractElementInst(), llvm::InstCombiner::visitGetElementPtrInst(), llvm::InstCombiner::visitOr(), and llvm::InstCombiner::visitXor().

CastInst * CastInst::Create	(	Instruction::CastOps	op,
		Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Construct any of the CastInst subclasses.

Provides a way to construct any of the CastInst subclasses using an opcode instead of the subclass's constructor. The opcode must be in the CastOps category. This constructor has insert-at-end-of-block semantics to automatically insert the new CastInst at the end of InsertAtEnd (if its non-null).

Parameters

op	The opcode for the cast instruction
S	The value to be casted (operand 0)
Ty	The type to which operand is casted
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2372 of file Instructions.cpp.

References castIsValid(), and llvm_unreachable.

CastInst * CastInst::CreateFPCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create an FPExt, BitCast, or FPTrunc for fp -> fp casts.

Parameters

S	The floating point value to be casted
Ty	The floating point type to cast to
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2513 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), llvm::Value::getType(), and llvm::Type::isFPOrFPVectorTy().

Referenced by llvm::NoFolder::CreateFPCast(), and llvm::IRBuilder< true, TargetFolder >::CreateFPCast().

CastInst * CastInst::CreateFPCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create an FPExt, BitCast, or FPTrunc for fp -> fp casts.

Parameters

S	The floating point value to be casted
Ty	The floating point type to cast to
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2526 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), llvm::Value::getType(), and llvm::Type::isFPOrFPVectorTy().

CastInst * CastInst::CreateIntegerCast	(	Value *	S,
		Type *	Ty,
		bool	isSigned,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create a ZExt, BitCast, or Trunc for int -> int casts.

Parameters

S	The pointer value to be casted (operand 0)
Ty	The type to which cast should be made
isSigned	Whether to regard S as signed or not
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2485 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), llvm::Value::getType(), and llvm::Type::isIntOrIntVectorTy().

Referenced by llvm::NoFolder::CreateIntCast(), llvm::IRBuilder< true, TargetFolder >::CreateIntCast(), createMalloc(), llvm::InstCombiner::visitPtrToInt(), and llvm::InstCombiner::visitTrunc().

CastInst * CastInst::CreateIntegerCast	(	Value *	S,
		Type *	Ty,
		bool	isSigned,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create a ZExt, BitCast, or Trunc for int -> int casts.

Parameters

S	The integer value to be casted (operand 0)
Ty	The integer type to which operand is casted
isSigned	Whether to regard S as signed or not
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2499 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), llvm::Value::getType(), and llvm::Type::isIntOrIntVectorTy().

CastInst * CastInst::CreatePointerCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create a BitCast or a PtrToInt cast instruction.

Parameters

S	The pointer value to be casted (operand 0)
Ty	The type to which operand is casted
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2442 of file Instructions.cpp.

References Create(), llvm::Type::getPointerAddressSpace(), llvm::Value::getType(), llvm::Type::getVectorNumElements(), llvm::Type::isIntOrIntVectorTy(), llvm::Type::isPtrOrPtrVectorTy(), and llvm::Type::isVectorTy().

Referenced by llvm::NoFolder::CreatePointerCast(), and llvm::IRBuilder< true, TargetFolder >::CreatePointerCast().

CastInst * CastInst::CreatePointerCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create a BitCast or a PtrToInt cast instruction.

Parameters

S	The pointer value to be casted (operand 0)
Ty	The type to which cast should be made
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2464 of file Instructions.cpp.

References Create(), llvm::Type::getPointerAddressSpace(), llvm::Value::getType(), llvm::Type::getVectorNumElements(), llvm::Type::isIntOrIntVectorTy(), llvm::Type::isPtrOrPtrVectorTy(), and llvm::Type::isVectorTy().

CastInst * CastInst::CreateSExtOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create a SExt or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which cast should be made
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2410 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

Referenced by llvm::NoFolder::CreateSExtOrBitCast(), llvm::IRBuilder< true, TargetFolder >::CreateSExtOrBitCast(), llvm::InstCombiner::visitCallInst(), and llvm::InstCombiner::visitSub().

CastInst * CastInst::CreateSExtOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create a SExt or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which operand is casted
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2418 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

CastInst * CastInst::CreateTruncOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create a Trunc or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which cast should be made
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2426 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

Referenced by llvm::NoFolder::CreateTruncOrBitCast(), and llvm::IRBuilder< true, TargetFolder >::CreateTruncOrBitCast().

CastInst * CastInst::CreateTruncOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create a Trunc or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which operand is casted
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2434 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

CastInst * CastInst::CreateZExtOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name = `""`,
		Instruction *	InsertBefore = `0`
	)

static

Create a ZExt or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which cast should be made
Name	Name for the instruction
InsertBefore	Place to insert the instruction

Definition at line 2394 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

Referenced by llvm::NoFolder::CreateZExtOrBitCast(), llvm::IRBuilder< true, TargetFolder >::CreateZExtOrBitCast(), llvm::InstCombiner::visitCallInst(), and llvm::InstCombiner::visitSub().

CastInst * CastInst::CreateZExtOrBitCast	(	Value *	S,
		Type *	Ty,
		const Twine &	Name,
		BasicBlock *	InsertAtEnd
	)

static

Create a ZExt or BitCast cast instruction.

Parameters

S	The value to be casted (operand 0)
Ty	The type to which operand is casted
Name	The name for the instruction
InsertAtEnd	The block to insert the instruction into

Definition at line 2402 of file Instructions.cpp.

References Create(), llvm::Type::getScalarSizeInBits(), and llvm::Value::getType().

Instruction::CastOps CastInst::getCastOpcode	(	const Value *	Val,
		bool	SrcIsSigned,
		Type *	Ty,
		bool	DstIsSigned
	)

static

Infer the opcode for cast operand and type.

Returns the opcode necessary to cast Val into Ty using usual casting rules.

Parameters

Val	The value to cast
SrcIsSigned	Whether to treat the source as signed
Ty	The Type to which the value should be casted
DstIsSigned	Whether to treate the dest. as signed

Definition at line 2650 of file Instructions.cpp.

References llvm::Type::getPointerAddressSpace(), llvm::Type::getPrimitiveSizeInBits(), llvm::Value::getType(), llvm::Type::isFirstClassType(), llvm::Type::isFloatingPointTy(), llvm::Type::isIntegerTy(), llvm::Type::isPointerTy(), llvm::Type::isVectorTy(), llvm::Type::isX86_MMXTy(), and llvm_unreachable.

Referenced by CastGEPIndices(), llvm::ConstantFoldCastInstruction(), getFoldedAlignOf(), getFoldedOffsetOf(), and getFoldedSizeOf().

Type* llvm::CastInst::getDestTy ( ) const

inline

Return the destination type, as a convenience.

Definition at line 610 of file InstrTypes.h.

References llvm::Intrinsic::getType().

Instruction::CastOps llvm::CastInst::getOpcode ( ) const

inline

Return the opcode of this CastInst.

Definition at line 603 of file InstrTypes.h.

References llvm::Instruction::getOpcode().

Referenced by llvm::AddrSpaceCastInst::AddrSpaceCastInst(), llvm::BitCastInst::BitCastInst(), llvm::InstCombiner::commonCastTransforms(), llvm::FPExtInst::FPExtInst(), llvm::FPToSIInst::FPToSIInst(), llvm::FPToUIInst::FPToUIInst(), llvm::FPTruncInst::FPTruncInst(), llvm::IntToPtrInst::IntToPtrInst(), isEliminableCastPair(), isIntegerCast(), isLosslessCast(), isNoopCast(), OptimizeNoopCopyExpression(), llvm::PtrToIntInst::PtrToIntInst(), llvm::SExtInst::SExtInst(), llvm::SIToFPInst::SIToFPInst(), llvm::TruncInst::TruncInst(), llvm::UIToFPInst::UIToFPInst(), llvm::InstCombiner::visitFPTrunc(), llvm::InstCombiner::visitICmpInstWithCastAndCast(), llvm::InstCombiner::visitOr(), and llvm::ZExtInst::ZExtInst().

Type* llvm::CastInst::getSrcTy ( ) const

inline

Return the source type, as a convenience.

Definition at line 608 of file InstrTypes.h.

Referenced by llvm::InstCombiner::visitFCmpInst().

bool CastInst::isBitCastable	(	Type *	SrcTy,
		Type *	DestTy
	)

static

Check whether a bitcast between these types is valid.

Parameters

SrcTy	The Type from which the value should be cast.
DestTy	The Type to which the value should be cast.

Definition at line 2602 of file Instructions.cpp.

References llvm::Type::getPrimitiveSizeInBits(), llvm::Type::isFirstClassType(), and llvm::Type::isX86_MMXTy().

bool CastInst::isCastable	(	Type *	SrcTy,
		Type *	DestTy
	)

static

Check whether it is valid to call getCastOpcode for these types.

Parameters

SrcTy	The Type from which the value should be cast.
DestTy	The Type to which the value should be cast.

Definition at line 2541 of file Instructions.cpp.

References llvm::Type::getPrimitiveSizeInBits(), llvm::Type::isFirstClassType(), llvm::Type::isFloatingPointTy(), llvm::Type::isIntegerTy(), llvm::Type::isPointerTy(), llvm::Type::isVectorTy(), and llvm::Type::isX86_MMXTy().

unsigned CastInst::isEliminableCastPair	(	Instruction::CastOps	firstOp,
		Instruction::CastOps	secondOp,
		Type *	SrcTy,
		Type *	MidTy,
		Type *	DstTy,
		Type *	SrcIntPtrTy,
		Type *	MidIntPtrTy,
		Type *	DstIntPtrTy
	)

static

Determine if a cast pair is eliminable.

Determine how a pair of casts can be eliminated, if they can be at all. This is a helper function for both CastInst and ConstantExpr.

Returns: 0 if the CastInst pair can't be eliminated, otherwise returns Instruction::CastOps value for a cast that can replace the pair, casting SrcTy to DstTy.

This function determines if a pair of casts can be eliminated and what opcode should be used in the elimination. This assumes that there are two instructions like this:

F = firstOpcode SrcTy x to MidTy
S = secondOpcode MidTy F to DstTy The function returns a resultOpcode so these two casts can be replaced with:
Replacement = resultOpcode SrcTy x to DstTy If no such cast is permited, the function returns 0.

Parameters

firstOp	Opcode of first cast
secondOp	Opcode of second cast
SrcTy	SrcTy of 1st cast
MidTy	DstTy of 1st cast & SrcTy of 2nd cast
DstTy	DstTy of 2nd cast
SrcIntPtrTy	Integer type corresponding to Ptr SrcTy, or null
MidIntPtrTy	Integer type corresponding to Ptr MidTy, or null
DstIntPtrTy	Integer type corresponding to Ptr DstTy, or null

Definition at line 2125 of file Instructions.cpp.

References llvm::Type::getPointerAddressSpace(), llvm::Type::getScalarSizeInBits(), llvm::Type::isFloatingPointTy(), llvm::Type::isIntegerTy(), llvm::Type::isIntOrIntVectorTy(), llvm::Type::isPtrOrPtrVectorTy(), llvm::Type::isVectorTy(), and llvm_unreachable.

Referenced by foldConstantCastPair(), and isEliminableCastPair().

bool CastInst::isIntegerCast ( ) const

Determine if this is an integer-only cast.

There are several places where we need to know if a cast instruction only deals with integer source and destination types. To simplify that logic, this method is provided.

Returns: true iff the cast has only integral typed operand and dest type.

Definition at line 2045 of file Instructions.cpp.

References getOpcode(), llvm::User::getOperand(), llvm::Value::getType(), and llvm::Type::isIntegerTy().

bool CastInst::isLosslessCast ( ) const

Determine if this is a lossless cast.

A lossless cast is one that does not alter the basic value. It implies a no-op cast but is more stringent, preventing things like int->float, long->double, or int->ptr.

Returns: true iff the cast is lossless.

Definition at line 2058 of file Instructions.cpp.

References getOpcode(), llvm::User::getOperand(), llvm::Value::getType(), and llvm::Type::isPointerTy().

Referenced by isSafeToEliminateVarargsCast().

bool CastInst::isNoopCast	(	Instruction::CastOps	Opcode,
		Type *	SrcTy,
		Type *	DestTy,
		Type *	IntPtrTy
	)

static

Determine if the described cast is a no-op cast.

Determine if the described cast is a no-op.

A no-op cast is one that can be effected without changing any bits. It implies that the source and destination types are the same size. The IntPtrTy argument is used to make accurate determinations for casts involving Integer and Pointer types. They are no-op casts if the integer is the same size as the pointer. However, pointer size varies with platform. Generally, the result of DataLayout::getIntPtrType() should be passed in. If that's not available, use Type::Int64Ty, which will make the isNoopCast call conservative.

This function determines if the CastInst does not require any bits to be changed in order to effect the cast. Essentially, it identifies cases where no code gen is necessary for the cast, hence the name no-op cast. For example, the following are all no-op casts:

bitcast i32* x to i8*

bitcast <2 x i32> x to <4 x i16>

ptrtoint i32* x to i32 ; on 32-bit plaforms only

Parameters

Opcode	Opcode of cast
SrcTy	SrcTy of cast
DestTy	DstTy of cast
IntPtrTy	Integer type corresponding to Ptr types

Definition at line 2083 of file Instructions.cpp.

References llvm::Type::getScalarSizeInBits(), and llvm_unreachable.

Referenced by isNoopCast().

bool CastInst::isNoopCast ( Type * IntPtrTy ) const

Determine if this cast is a no-op cast.

Determine if a cast is a no-op.

Parameters

IntPtrTy Integer type corresponding to pointer

Definition at line 2113 of file Instructions.cpp.

References getOpcode(), llvm::User::getOperand(), llvm::Value::getType(), and isNoopCast().

The documentation for this class was generated from the following files:

Public Member Functions

Static Public Member Functions

Protected Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

bitcast i32* x to i8*

bitcast <2 x i32> x to <4 x i16>

ptrtoint i32* x to i32 ; on 32-bit plaforms only
