#include <MachineDominators.h>

Inheritance diagram for llvm::MachineDominatorTree:

Collaboration diagram for llvm::MachineDominatorTree:

Public Member Functions
	MachineDominatorTree ()

	~MachineDominatorTree ()

DominatorTreeBase < MachineBasicBlock > &	getBase ()

virtual void	getAnalysisUsage (AnalysisUsage &AU) const

const std::vector < MachineBasicBlock * > &	getRoots () const

MachineBasicBlock *	getRoot () const

MachineDomTreeNode *	getRootNode () const

virtual bool	runOnMachineFunction (MachineFunction &F)

bool	dominates (const MachineDomTreeNode A, const MachineDomTreeNode B) const

bool	dominates (const MachineBasicBlock A, const MachineBasicBlock B) const

bool	dominates (const MachineInstr A, const MachineInstr B) const

bool	properlyDominates (const MachineDomTreeNode A, const MachineDomTreeNode B) const

bool	properlyDominates (const MachineBasicBlock A, const MachineBasicBlock B) const

MachineBasicBlock *	findNearestCommonDominator (MachineBasicBlock A, MachineBasicBlock B)

MachineDomTreeNode *	operator[] (MachineBasicBlock *BB) const

MachineDomTreeNode *	getNode (MachineBasicBlock *BB) const

MachineDomTreeNode *	addNewBlock (MachineBasicBlock BB, MachineBasicBlock DomBB)

void	changeImmediateDominator (MachineBasicBlock N, MachineBasicBlock NewIDom)

void	changeImmediateDominator (MachineDomTreeNode N, MachineDomTreeNode NewIDom)

void	eraseNode (MachineBasicBlock *BB)

void	splitBlock (MachineBasicBlock *NewBB)

bool	isReachableFromEntry (const MachineBasicBlock *A)

virtual void	releaseMemory ()

virtual void	print (raw_ostream &OS, const Module *) const

Public Member Functions inherited from llvm::FunctionPass
	FunctionPass (char &pid)

Pass *	createPrinterPass (raw_ostream &O, const std::string &Banner) const
	createPrinterPass - Get a function printer pass. More...

virtual void	assignPassManager (PMStack &PMS, PassManagerType T)

virtual PassManagerType	getPotentialPassManagerType () const
	Return what kind of Pass Manager can manage this pass. More...

Public Member Functions inherited from llvm::Pass
	Pass (PassKind K, char &pid)

virtual	~Pass ()

PassKind	getPassKind () const

virtual const char *	getPassName () const

AnalysisID	getPassID () const
	getPassID - Return the PassID number that corresponds to this pass. More...

virtual bool	doInitialization (Module &)

virtual bool	doFinalization (Module &)

void	dump () const

virtual void	preparePassManager (PMStack &)
	Check if available pass managers are suitable for this pass or not. More...

void	setResolver (AnalysisResolver *AR)

AnalysisResolver *	getResolver () const

virtual void *	getAdjustedAnalysisPointer (AnalysisID ID)

virtual ImmutablePass *	getAsImmutablePass ()

virtual PMDataManager *	getAsPMDataManager ()

virtual void	verifyAnalysis () const

virtual void	dumpPassStructure (unsigned Offset=0)

template<typename AnalysisType >
AnalysisType *	getAnalysisIfAvailable () const

bool	mustPreserveAnalysisID (char &AID) const

template<typename AnalysisType >
AnalysisType &	getAnalysis () const

template<typename AnalysisType >
AnalysisType &	getAnalysis (Function &F)

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI) const

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI, Function &F)

Public Attributes
DominatorTreeBase < MachineBasicBlock > *	DT

Static Public Attributes
static char	ID = 0

Additional Inherited Members
Static Public Member Functions inherited from llvm::Pass
static const PassInfo *	lookupPassInfo (const void *TI)

static const PassInfo *	lookupPassInfo (StringRef Arg)

static Pass *	createPass (AnalysisID ID)

Protected Member Functions inherited from llvm::MachineFunctionPass
	MachineFunctionPass (char &ID)

Detailed Description

DominatorTree Class - Concrete subclass of DominatorTreeBase that is used to compute a normal dominator tree.

Definition at line 40 of file MachineDominators.h.

Constructor & Destructor Documentation

MachineDominatorTree::MachineDominatorTree ( )

Definition at line 43 of file MachineDominators.cpp.

References DT, llvm::PassRegistry::getPassRegistry(), and llvm::initializeMachineDominatorTreePass().

MachineDominatorTree::~MachineDominatorTree ( )

Definition at line 49 of file MachineDominators.cpp.

References DT.

Member Function Documentation

MachineDomTreeNode* llvm::MachineDominatorTree::addNewBlock	(	MachineBasicBlock *	BB,
		MachineBasicBlock *	DomBB
	)

inline

addNewBlock - Add a new node to the dominator tree information. This creates a new node as a child of DomBB dominator node,linking it into the children list of the immediate dominator.

Definition at line 132 of file MachineDominators.h.

References DT.

void llvm::MachineDominatorTree::changeImmediateDominator	(	MachineBasicBlock *	N,
		MachineBasicBlock *	NewIDom
	)

inline

changeImmediateDominator - This method is used to update the dominator tree information when a node's immediate dominator changes.

Definition at line 140 of file MachineDominators.h.

References DT.

void llvm::MachineDominatorTree::changeImmediateDominator	(	MachineDomTreeNode *	N,
		MachineDomTreeNode *	NewIDom
	)

inline

Definition at line 145 of file MachineDominators.h.

References DT.

bool llvm::MachineDominatorTree::dominates	(	const MachineDomTreeNode *	A,
		const MachineDomTreeNode *	B
	)		const

inline

Definition at line 71 of file MachineDominators.h.

References DT.

bool llvm::MachineDominatorTree::dominates	(	const MachineBasicBlock *	A,
		const MachineBasicBlock *	B
	)		const

inline

Definition at line 76 of file MachineDominators.h.

References DT.

bool llvm::MachineDominatorTree::dominates	(	const MachineInstr *	A,
		const MachineInstr *	B
	)		const

inline

Definition at line 83 of file MachineDominators.h.

References llvm::ARM_PROC::A, llvm::MachineBasicBlock::begin(), DT, llvm::MachineInstr::getParent(), and I.

void llvm::MachineDominatorTree::eraseNode ( MachineBasicBlock * BB )

inline

eraseNode - Removes a node from the dominator tree. Block must not dominate any other blocks. Removes node from its immediate dominator's children list. Deletes dominator node associated with basic block BB.

Definition at line 153 of file MachineDominators.h.

References DT.

MachineBasicBlock* llvm::MachineDominatorTree::findNearestCommonDominator	(	MachineBasicBlock *	A,
		MachineBasicBlock *	B
	)

inline

findNearestCommonDominator - Find nearest common dominator basic block for basic block A and B. If there is no such block then return NULL.

Definition at line 113 of file MachineDominators.h.

References DT.

virtual void llvm::MachineDominatorTree::getAnalysisUsage ( AnalysisUsage & AU ) const

virtual

getAnalysisUsage - Subclasses that override getAnalysisUsage must call this.

For MachineFunctionPasses, calling AU.preservesCFG() indicates that the pass does not modify the MachineBasicBlock CFG.

Reimplemented from llvm::MachineFunctionPass.

DominatorTreeBase<MachineBasicBlock>& llvm::MachineDominatorTree::getBase ( )

inline

Definition at line 49 of file MachineDominators.h.

References DT.

MachineDomTreeNode* llvm::MachineDominatorTree::getNode ( MachineBasicBlock * BB ) const

inline

getNode - return the (Post)DominatorTree node for the specified basic block. This is the same as using operator[] on this class.

Definition at line 125 of file MachineDominators.h.

References DT.

MachineBasicBlock* llvm::MachineDominatorTree::getRoot ( ) const

inline

Definition at line 61 of file MachineDominators.h.

References DT.

MachineDomTreeNode* llvm::MachineDominatorTree::getRootNode ( ) const

inline

Definition at line 65 of file MachineDominators.h.

References DT.

Referenced by llvm::GraphTraits< MachineDominatorTree * >::getEntryNode().

const std::vector<MachineBasicBlock*>& llvm::MachineDominatorTree::getRoots ( ) const

inline

getRoots - Return the root blocks of the current CFG. This may include multiple blocks if we are computing post dominators. For forward dominators, this will always be a single block (the entry node).

Definition at line 57 of file MachineDominators.h.

References DT.

bool llvm::MachineDominatorTree::isReachableFromEntry ( const MachineBasicBlock * A )

inline

isReachableFromEntry - Return true if A is dominated by the entry block of the function containing it.

Definition at line 165 of file MachineDominators.h.

References DT.

MachineDomTreeNode* llvm::MachineDominatorTree::operator[] ( MachineBasicBlock * BB ) const

inline

Definition at line 118 of file MachineDominators.h.

References DT.

void MachineDominatorTree::print	(	raw_ostream &	O,
		const Module *	M
	)		const

virtual

print - Print out the internal state of the pass. This is called by Analyze to print out the contents of an analysis. Otherwise it is not necessary to implement this method. Beware that the module pointer MAY be null. This automatically forwards to a virtual function that does not provide the Module* in case the analysis doesn't need it it can just be ignored.

Reimplemented from llvm::Pass.

Definition at line 57 of file MachineDominators.cpp.

References DT.

bool llvm::MachineDominatorTree::properlyDominates	(	const MachineDomTreeNode *	A,
		const MachineDomTreeNode *	B
	)		const

inline

Definition at line 101 of file MachineDominators.h.

References DT.

bool llvm::MachineDominatorTree::properlyDominates	(	const MachineBasicBlock *	A,
		const MachineBasicBlock *	B
	)		const

inline

Definition at line 106 of file MachineDominators.h.

References DT.

void MachineDominatorTree::releaseMemory ( )

virtual

releaseMemory() - This member can be implemented by a pass if it wants to be able to release its memory when it is no longer needed. The default behavior of passes is to hold onto memory for the entire duration of their lifetime (which is the entire compile time). For pipelined passes, this is not a big deal because that memory gets recycled every time the pass is invoked on another program unit. For IP passes, it is more important to free memory when it is unused.

Optionally implement this function to release pass memory when it is no longer used.

Reimplemented from llvm::Pass.

Definition at line 53 of file MachineDominators.cpp.

References DT.

bool MachineDominatorTree::runOnMachineFunction ( MachineFunction & MF )

virtual

runOnMachineFunction - This method must be overloaded to perform the desired machine code transformation or analysis.

Implements llvm::MachineFunctionPass.

Definition at line 37 of file MachineDominators.cpp.

References DT.

void llvm::MachineDominatorTree::splitBlock ( MachineBasicBlock * NewBB )

inline

splitBlock - BB is split and now it has one successor. Update dominator tree to reflect this change.

Definition at line 159 of file MachineDominators.h.

References DT.

Member Data Documentation

DominatorTreeBase<MachineBasicBlock>* llvm::MachineDominatorTree::DT

Definition at line 43 of file MachineDominators.h.

Referenced by addNewBlock(), changeImmediateDominator(), dominates(), eraseNode(), findNearestCommonDominator(), getBase(), getNode(), getRoot(), getRootNode(), getRoots(), isReachableFromEntry(), MachineDominatorTree(), operator[](), print(), properlyDominates(), releaseMemory(), runOnMachineFunction(), splitBlock(), and ~MachineDominatorTree().

char MachineDominatorTree::ID = 0

static

Definition at line 42 of file MachineDominators.h.

The documentation for this class was generated from the following files:
