#include <Dominators.h>

Inheritance diagram for llvm::DominatorTree:

Collaboration diagram for llvm::DominatorTree:

Public Member Functions
	DominatorTree ()

	~DominatorTree ()

DominatorTreeBase< BasicBlock > &	getBase ()

const std::vector< BasicBlock * > &	getRoots () const

BasicBlock *	getRoot () const

DomTreeNode *	getRootNode () const

void	getDescendants (BasicBlock R, SmallVectorImpl< BasicBlock > &Result) const
	Get all nodes dominated by R, including R itself. Return true on success. More...

bool	compare (DominatorTree &Other) const

virtual bool	runOnFunction (Function &F)

virtual void	verifyAnalysis () const

virtual void	getAnalysisUsage (AnalysisUsage &AU) const

bool	dominates (const DomTreeNode A, const DomTreeNode B) const

bool	dominates (const BasicBlock A, const BasicBlock B) const

bool	dominates (const Instruction *Def, const Use &U) const

bool	dominates (const Instruction Def, const Instruction User) const

bool	dominates (const Instruction Def, const BasicBlock BB) const

bool	dominates (const BasicBlockEdge &BBE, const Use &U) const

bool	dominates (const BasicBlockEdge &BBE, const BasicBlock *BB) const

bool	properlyDominates (const DomTreeNode A, const DomTreeNode B) const

bool	properlyDominates (const BasicBlock A, const BasicBlock B) const

BasicBlock *	findNearestCommonDominator (BasicBlock A, BasicBlock B)

const BasicBlock *	findNearestCommonDominator (const BasicBlock A, const BasicBlock B)

DomTreeNode *	operator[] (BasicBlock *BB) const

DomTreeNode *	getNode (BasicBlock *BB) const

DomTreeNode *	addNewBlock (BasicBlock BB, BasicBlock DomBB)

void	changeImmediateDominator (BasicBlock N, BasicBlock NewIDom)

void	changeImmediateDominator (DomTreeNode N, DomTreeNode NewIDom)

void	eraseNode (BasicBlock *BB)

void	splitBlock (BasicBlock *NewBB)

bool	isReachableFromEntry (const BasicBlock *A) const

bool	isReachableFromEntry (const Use &U) const

virtual void	releaseMemory ()

virtual void	print (raw_ostream &OS, const Module *M=0) const

Public Member Functions inherited from llvm::FunctionPass
	FunctionPass (char &pid)

Pass *	createPrinterPass (raw_ostream &O, const std::string &Banner) const
	createPrinterPass - Get a function printer pass. More...

virtual void	assignPassManager (PMStack &PMS, PassManagerType T)

virtual PassManagerType	getPotentialPassManagerType () const
	Return what kind of Pass Manager can manage this pass. More...

Public Member Functions inherited from llvm::Pass
	Pass (PassKind K, char &pid)

virtual	~Pass ()

PassKind	getPassKind () const

virtual const char *	getPassName () const

AnalysisID	getPassID () const
	getPassID - Return the PassID number that corresponds to this pass. More...

virtual bool	doInitialization (Module &)

virtual bool	doFinalization (Module &)

void	dump () const

virtual void	preparePassManager (PMStack &)
	Check if available pass managers are suitable for this pass or not. More...

void	setResolver (AnalysisResolver *AR)

AnalysisResolver *	getResolver () const

virtual void *	getAdjustedAnalysisPointer (AnalysisID ID)

virtual ImmutablePass *	getAsImmutablePass ()

virtual PMDataManager *	getAsPMDataManager ()

virtual void	dumpPassStructure (unsigned Offset=0)

template<typename AnalysisType >
AnalysisType *	getAnalysisIfAvailable () const

bool	mustPreserveAnalysisID (char &AID) const

template<typename AnalysisType >
AnalysisType &	getAnalysis () const

template<typename AnalysisType >
AnalysisType &	getAnalysis (Function &F)

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI) const

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI, Function &F)

Public Attributes
DominatorTreeBase< BasicBlock > *	DT

Static Public Attributes
static char	ID = 0

Additional Inherited Members
Static Public Member Functions inherited from llvm::Pass
static const PassInfo *	lookupPassInfo (const void *TI)

static const PassInfo *	lookupPassInfo (StringRef Arg)

static Pass *	createPass (AnalysisID ID)

Detailed Description

DominatorTree Class - Concrete subclass of DominatorTreeBase that is used to compute a normal dominator tree.

Definition at line 740 of file Dominators.h.

Constructor & Destructor Documentation

llvm::DominatorTree::DominatorTree ( )

inline

Definition at line 745 of file Dominators.h.

References DT, llvm::PassRegistry::getPassRegistry(), and llvm::initializeDominatorTreePass().

llvm::DominatorTree::~DominatorTree ( )

inline

Definition at line 750 of file Dominators.h.

References DT.

Member Function Documentation

DomTreeNode* llvm::DominatorTree::addNewBlock	(	BasicBlock *	BB,
		BasicBlock *	DomBB
	)

inline

addNewBlock - Add a new node to the dominator tree information. This creates a new node as a child of DomBB dominator node,linking it into the children list of the immediate dominator.

Definition at line 851 of file Dominators.h.

References DT.

Referenced by llvm::SplitCriticalEdge().

void llvm::DominatorTree::changeImmediateDominator	(	BasicBlock *	N,
		BasicBlock *	NewIDom
	)

inline

changeImmediateDominator - This method is used to update the dominator tree information when a node's immediate dominator changes.

Definition at line 858 of file Dominators.h.

References DT.

Referenced by llvm::MergeBasicBlockIntoOnlyPred(), and llvm::SplitCriticalEdge().

void llvm::DominatorTree::changeImmediateDominator	(	DomTreeNode *	N,
		DomTreeNode *	NewIDom
	)

inline

Definition at line 862 of file Dominators.h.

References DT.

bool llvm::DominatorTree::compare ( DominatorTree & Other ) const

inline

compare - Return false if the other dominator tree matches this dominator tree. Otherwise return true.

Definition at line 780 of file Dominators.h.

References DT, getBase(), llvm::DomTreeNodeBase< NodeT >::getBlock(), and getRootNode().

Referenced by verifyAnalysis().

bool llvm::DominatorTree::dominates	(	const DomTreeNode *	A,
		const DomTreeNode *	B
	)		const

inline

Definition at line 801 of file Dominators.h.

References DT.

Referenced by BlockDominatesAnExit(), llvm::Region::contains(), dominates(), llvm::ScalarEvolution::getAddRecExpr(), llvm::Region::getExpandedRegion(), getInsertPointForUses(), llvm::SCEVExpander::getIVIncOperand(), llvm::RegionInfo::getMaxRegionExit(), llvm::SCEVExpander::hoistIVInc(), isPotentiallyReachableInner(), IVUseShouldUsePostIncValue(), llvm::PHITransAddr::PHITranslateValue(), PickMostRelevantLoop(), rewriteSingleStoreAlloca(), llvm::SplitCriticalEdge(), and ValueDominatesPHI().

bool llvm::DominatorTree::dominates	(	const BasicBlock *	A,
		const BasicBlock *	B
	)		const

inline

Definition at line 805 of file Dominators.h.

References DT.

bool DominatorTree::dominates	(	const Instruction *	Def,
		const Use &	U
	)		const

Definition at line 237 of file Dominators.cpp.

References dominates(), llvm::Instruction::getParent(), llvm::Use::getUser(), I, and isReachableFromEntry().

bool DominatorTree::dominates	(	const Instruction *	Def,
		const Instruction *	User
	)		const

Definition at line 99 of file Dominators.cpp.

References llvm::BasicBlock::begin(), llvm::tgtok::Def, dominates(), llvm::Instruction::getParent(), I, and isReachableFromEntry().

bool DominatorTree::dominates	(	const Instruction *	Def,
		const BasicBlock *	BB
	)		const

Definition at line 136 of file Dominators.cpp.

References llvm::tgtok::Def, dominates(), llvm::dyn_cast(), llvm::InvokeInst::getNormalDest(), llvm::Instruction::getParent(), and isReachableFromEntry().

bool DominatorTree::dominates	(	const BasicBlockEdge &	BBE,
		const Use &	U
	)		const

Definition at line 213 of file Dominators.cpp.

References dominates(), llvm::dyn_cast(), llvm::BasicBlockEdge::getEnd(), llvm::BasicBlock::getParent(), llvm::BasicBlockEdge::getStart(), llvm::Use::getUser(), and llvm::BasicBlockEdge::isSingleEdge().

bool DominatorTree::dominates	(	const BasicBlockEdge &	BBE,
		const BasicBlock *	BB
	)		const

Definition at line 162 of file Dominators.cpp.

References dominates(), llvm::BasicBlockEdge::getEnd(), llvm::BasicBlock::getSinglePredecessor(), llvm::BasicBlockEdge::getStart(), llvm::BasicBlockEdge::isSingleEdge(), llvm::pred_begin(), and llvm::pred_end().

void llvm::DominatorTree::eraseNode ( BasicBlock * BB )

inline

eraseNode - Removes a node from the dominator tree. Block must not dominate any other blocks. Removes node from its immediate dominator's children list. Deletes dominator node associated with basic block BB.

Definition at line 869 of file Dominators.h.

References DT.

Referenced by llvm::MergeBasicBlockIntoOnlyPred().

BasicBlock* llvm::DominatorTree::findNearestCommonDominator	(	BasicBlock *	A,
		BasicBlock *	B
	)

inline

findNearestCommonDominator - Find nearest common dominator basic block for basic block A and B. If there is no such block then return NULL.

Definition at line 828 of file Dominators.h.

References DT.

Referenced by getInsertPointForUses().

const BasicBlock* llvm::DominatorTree::findNearestCommonDominator	(	const BasicBlock *	A,
		const BasicBlock *	B
	)

inline

Definition at line 832 of file Dominators.h.

References DT.

virtual void llvm::DominatorTree::getAnalysisUsage ( AnalysisUsage & ) const

inlinevirtual

getAnalysisUsage - This function should be overriden by passes that need analysis information to do their job. If a pass specifies that it uses a particular analysis result to this function, it can then use the getAnalysis<AnalysisType>() function, below.

Reimplemented from llvm::Pass.

Definition at line 797 of file Dominators.h.

References llvm::AnalysisUsage::setPreservesAll().

DominatorTreeBase<BasicBlock>& llvm::DominatorTree::getBase ( )

inline

Definition at line 754 of file Dominators.h.

References DT.

Referenced by compare(), and verifyAnalysis().

void llvm::DominatorTree::getDescendants	(	BasicBlock *	R,
		SmallVectorImpl< BasicBlock * > &	Result
	)		const

inline

Get all nodes dominated by R, including R itself. Return true on success.

Definition at line 773 of file Dominators.h.

References DT.

DomTreeNode* llvm::DominatorTree::getNode ( BasicBlock * BB ) const

inline

getNode - return the (Post)DominatorTree node for the specified basic block. This is the same as using operator[] on this class.

Definition at line 844 of file Dominators.h.

References DT.

Referenced by BlockDominatesAnExit(), llvm::Region::contains(), llvm::Region::getEnteringBlock(), isSimplifiedLoopNest(), llvm::MergeBasicBlockIntoOnlyPred(), and llvm::SplitCriticalEdge().

BasicBlock* llvm::DominatorTree::getRoot ( ) const

inline

Definition at line 764 of file Dominators.h.

References DT.

Referenced by verifyAnalysis().

DomTreeNode* llvm::DominatorTree::getRootNode ( ) const

inline

Definition at line 768 of file Dominators.h.

References DT.

Referenced by compare(), llvm::GraphTraits< DominatorTree * >::getEntryNode(), and llvm::DOTGraphTraits< DominatorTree * >::getNodeLabel().

const std::vector<BasicBlock*>& llvm::DominatorTree::getRoots ( ) const

inline

getRoots - Return the root blocks of the current CFG. This may include multiple blocks if we are computing post dominators. For forward dominators, this will always be a single block (the entry node).

Definition at line 760 of file Dominators.h.

References DT.

Referenced by llvm::DominanceFrontier::runOnFunction().

bool llvm::DominatorTree::isReachableFromEntry ( const BasicBlock * A ) const

inline

Definition at line 879 of file Dominators.h.

References DT.

Referenced by dominates(), FindUnconditionalPreds(), llvm::Loop::isLCSSAForm(), isPotentiallyReachableInner(), isReachableFromEntry(), and ValueDominatesPHI().

bool DominatorTree::isReachableFromEntry ( const Use & U ) const

Definition at line 289 of file Dominators.cpp.

References llvm::dyn_cast(), llvm::Instruction::getParent(), llvm::Use::getUser(), I, and isReachableFromEntry().

DomTreeNode* llvm::DominatorTree::operator[] ( BasicBlock * BB ) const

inline

Definition at line 837 of file Dominators.h.

References DT.

void DominatorTree::print	(	raw_ostream &	O,
		const Module *	M = `0`
	)		const

virtual

print - Print out the internal state of the pass. This is called by Analyze to print out the contents of an analysis. Otherwise it is not necessary to implement this method. Beware that the module pointer MAY be null. This automatically forwards to a virtual function that does not provide the Module* in case the analysis doesn't need it it can just be ignored.

Reimplemented from llvm::Pass.

Definition at line 92 of file Dominators.cpp.

References DT.

Referenced by verifyAnalysis().

bool llvm::DominatorTree::properlyDominates	(	const DomTreeNode *	A,
		const DomTreeNode *	B
	)		const

inline

Definition at line 818 of file Dominators.h.

References DT.

Referenced by llvm::DominanceFrontier::calculate(), and isLoopInvariant().

bool llvm::DominatorTree::properlyDominates	(	const BasicBlock *	A,
		const BasicBlock *	B
	)		const

inline

Definition at line 822 of file Dominators.h.

References DT.

virtual void llvm::DominatorTree::releaseMemory ( )

inlinevirtual

releaseMemory() - This member can be implemented by a pass if it wants to be able to release its memory when it is no longer needed. The default behavior of passes is to hold onto memory for the entire duration of their lifetime (which is the entire compile time). For pipelined passes, this is not a big deal because that memory gets recycled every time the pass is invoked on another program unit. For IP passes, it is more important to free memory when it is unused.

Optionally implement this function to release pass memory when it is no longer used.

Reimplemented from llvm::Pass.

Definition at line 886 of file Dominators.h.

References DT.

virtual bool llvm::DominatorTree::runOnFunction ( Function & F )

virtual

runOnFunction - Virtual method overriden by subclasses to do the per-function processing of the pass.

Implements llvm::FunctionPass.

void llvm::DominatorTree::splitBlock ( BasicBlock * NewBB )

inline

splitBlock - BB is split and now it has one successor. Update dominator tree to reflect this change.

Definition at line 875 of file Dominators.h.
