#include <Operator.h>

Inheritance diagram for llvm::GEPOperator:

Collaboration diagram for llvm::GEPOperator:

Public Member Functions
bool	isInBounds () const

op_iterator	idx_begin ()

const_op_iterator	idx_begin () const

op_iterator	idx_end ()

const_op_iterator	idx_end () const

Value *	getPointerOperand ()

const Value *	getPointerOperand () const

Type *	getPointerOperandType () const

unsigned	getPointerAddressSpace () const

unsigned	getNumIndices () const

bool	hasIndices () const

bool	hasAllZeroIndices () const

bool	hasAllConstantIndices () const

bool	accumulateConstantOffset (const DataLayout &DL, APInt &Offset) const
	Accumulate the constant address offset of this GEP if possible. More...

Public Member Functions inherited from llvm::Operator
unsigned	getOpcode () const

Public Member Functions inherited from llvm::User
	~User ()

void	operator delete (void *Usr)
	operator delete - free memory allocated for User and Use objects More...

void	operator delete (void *, unsigned)
	placement delete - required by std, but never called. More...

void	operator delete (void *, unsigned, bool)
	placement delete - required by std, but never called. More...

Value *	getOperand (unsigned i) const

void	setOperand (unsigned i, Value *Val)

const Use &	getOperandUse (unsigned i) const

Use &	getOperandUse (unsigned i)

unsigned	getNumOperands () const

op_iterator	op_begin ()

const_op_iterator	op_begin () const

op_iterator	op_end ()

const_op_iterator	op_end () const

value_op_iterator	value_op_begin ()

value_op_iterator	value_op_end ()

void	dropAllReferences ()

void	replaceUsesOfWith (Value From, Value To)

Public Member Functions inherited from llvm::Value
virtual	~Value ()

void	dump () const
	dump - Support for debugging, callable in GDB: V->dump() More...

void	print (raw_ostream &O, AssemblyAnnotationWriter *AAW=0) const

Type *	getType () const

LLVMContext &	getContext () const
	All values hold a context through their type. More...

bool	hasName () const

ValueName *	getValueName () const

void	setValueName (ValueName *VN)

StringRef	getName () const

void	setName (const Twine &Name)

void	takeName (Value *V)

void	replaceAllUsesWith (Value *V)

bool	use_empty () const

use_iterator	use_begin ()

const_use_iterator	use_begin () const

use_iterator	use_end ()

const_use_iterator	use_end () const

User *	use_back ()

const User *	use_back () const

bool	hasOneUse () const

bool	hasNUses (unsigned N) const

bool	hasNUsesOrMore (unsigned N) const

bool	isUsedInBasicBlock (const BasicBlock *BB) const

unsigned	getNumUses () const

void	addUse (Use &U)

unsigned	getValueID () const

unsigned	getRawSubclassOptionalData () const

void	clearSubclassOptionalData ()

bool	hasSameSubclassOptionalData (const Value *V) const

void	intersectOptionalDataWith (const Value *V)

bool	hasValueHandle () const

Value *	stripPointerCasts ()
	Strips off any unneeded pointer casts, all-zero GEPs and aliases from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCasts () const

Value *	stripPointerCastsNoFollowAliases ()
	Strips off any unneeded pointer casts and all-zero GEPs from the specified value, returning the original uncasted value. More...

const Value *	stripPointerCastsNoFollowAliases () const

Value *	stripInBoundsConstantOffsets ()
	Strips off unneeded pointer casts and all-constant GEPs from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsConstantOffsets () const

Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset)
	Strips like `stripInBoundsConstantOffsets` but also accumulates the constant offset stripped. More...

const Value *	stripAndAccumulateInBoundsConstantOffsets (const DataLayout &DL, APInt &Offset) const

Value *	stripInBoundsOffsets ()
	Strips off unneeded pointer casts and any in-bounds offsets from the specified value, returning the original pointer value. More...

const Value *	stripInBoundsOffsets () const

bool	isDereferenceablePointer () const

Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB)

const Value *	DoPHITranslation (const BasicBlock CurBB, const BasicBlock PredBB) const

void	mutateType (Type *Ty)

Static Public Member Functions
static unsigned	getPointerOperandIndex ()

Static Public Member Functions inherited from llvm::ConcreteOperator< Operator, Instruction::GetElementPtr >
static bool	classof (const Instruction *I)

static bool	classof (const ConstantExpr *CE)

static bool	classof (const Value *V)

Static Public Member Functions inherited from llvm::Operator
static unsigned	getOpcode (const Value *V)

static bool	classof (const Instruction *)

static bool	classof (const ConstantExpr *)

static bool	classof (const Value *V)

Static Public Member Functions inherited from llvm::User
static bool	classof (const Value *V)

Friends
class	GetElementPtrInst

class	ConstantExpr

Additional Inherited Members
Public Types inherited from llvm::User
typedef Use *	op_iterator

typedef const Use *	const_op_iterator

Public Types inherited from llvm::Value
enum	ValueTy { ArgumentVal, BasicBlockVal, FunctionVal, GlobalAliasVal, GlobalVariableVal, UndefValueVal, BlockAddressVal, ConstantExprVal, ConstantAggregateZeroVal, ConstantDataArrayVal, ConstantDataVectorVal, ConstantIntVal, ConstantFPVal, ConstantArrayVal, ConstantStructVal, ConstantVectorVal, ConstantPointerNullVal, MDNodeVal, MDStringVal, InlineAsmVal, PseudoSourceValueVal, FixedStackPseudoSourceValueVal, InstructionVal, ConstantFirstVal = FunctionVal, ConstantLastVal = ConstantPointerNullVal }

typedef value_use_iterator< User >	use_iterator

typedef value_use_iterator < const User >	const_use_iterator

Static Public Attributes inherited from llvm::Value
static const unsigned	MaximumAlignment = 1u << 29

Protected Member Functions inherited from llvm::Operator
	~Operator ()

Protected Member Functions inherited from llvm::User
void *	operator new (size_t s, unsigned Us)

	User (Type ty, unsigned vty, Use OpList, unsigned NumOps)

Use *	allocHungoffUses (unsigned) const

void	dropHungoffUses ()

template<int Idx>
Use &	Op ()

template<int Idx>
const Use &	Op () const

Protected Member Functions inherited from llvm::Value
virtual void	printCustom (raw_ostream &O) const

	Value (Type *Ty, unsigned scid)

unsigned short	getSubclassDataFromValue () const

void	setValueSubclassData (unsigned short D)

Static Protected Member Functions inherited from llvm::User
template<int Idx, typename U >
static Use &	OpFrom (const U *that)

Protected Attributes inherited from llvm::User
Use *	OperandList

unsigned	NumOperands

Protected Attributes inherited from llvm::Value
unsigned char	SubclassOptionalData: 7

Detailed Description

Definition at line 357 of file Operator.h.

Member Function Documentation

bool llvm::GEPOperator::accumulateConstantOffset	(	const DataLayout &	DL,
		APInt &	Offset
	)		const

inline

Accumulate the constant address offset of this GEP if possible.

This routine accepts an APInt into which it will accumulate the constant offset of this GEP if the GEP is in fact constant. If the GEP is not all-constant, it returns false and the value of the offset APInt is undefined (it is not preserved!). The APInt passed into this routine must be at exactly as wide as the IntPtr type for the address space of the base GEP pointer.

Definition at line 444 of file Operator.h.

References llvm::dyn_cast(), llvm::gep_type_begin(), llvm::gep_type_end(), llvm::APInt::getBitWidth(), llvm::StructLayout::getElementOffset(), llvm::DataLayout::getPointerSizeInBits(), llvm::DataLayout::getStructLayout(), llvm::DataLayout::getTypeAllocSize(), llvm::ConstantInt::getValue(), llvm::ConstantInt::getZExtValue(), llvm::ConstantInt::isZero(), and llvm::APInt::sextOrTrunc().

Referenced by IsConstantOffsetFromGlobal(), and llvm::ObjectSizeOffsetVisitor::visitGEPOperator().

unsigned llvm::GEPOperator::getNumIndices ( ) const

inline

Definition at line 404 of file Operator.h.

References llvm::User::getNumOperands().

unsigned llvm::GEPOperator::getPointerAddressSpace ( ) const

inline

getPointerAddressSpace - Method to return the address space of the pointer operand.

Definition at line 400 of file Operator.h.

Referenced by DecomposeGEPExpression(), and isGEPKnownNonNull().

Value* llvm::GEPOperator::getPointerOperand ( )

inline

Definition at line 382 of file Operator.h.

References llvm::User::getOperand().

Referenced by llvm::DependenceAnalysis::depends(), llvm::DependenceAnalysis::getSplitIteration(), isGEPKnownNonNull(), llvm::ObjectSizeOffsetVisitor::visitGEPOperator(), and llvm::ObjectSizeOffsetEvaluator::visitGEPOperator().

const Value* llvm::GEPOperator::getPointerOperand ( ) const

inline

Definition at line 385 of file Operator.h.

References llvm::User::getOperand().

static unsigned llvm::GEPOperator::getPointerOperandIndex ( )

inlinestatic

Definition at line 388 of file Operator.h.

Type* llvm::GEPOperator::getPointerOperandType ( ) const

inline

getPointerOperandType - Method to return the pointer operand as a PointerType.

Definition at line 394 of file Operator.h.

References getPointerOperand().

Referenced by llvm::DependenceAnalysis::depends(), and llvm::DependenceAnalysis::getSplitIteration().

bool llvm::GEPOperator::hasAllConstantIndices ( ) const

inline

hasAllConstantIndices - Return true if all of the indices of this GEP are constant integers. If so, the result pointer and the first operand have a constant offset between them.

Definition at line 428 of file Operator.h.

References I.

Referenced by llvm::InstCombiner::FoldGEPICmp().

bool llvm::GEPOperator::hasAllZeroIndices ( ) const

inline

hasAllZeroIndices - Return true if all of the indices of this GEP are zeros. If so, the result pointer and the first operand have the same value, just potentially different types.

Definition at line 415 of file Operator.h.

References llvm::CallingConv::C, and I.

Referenced by DecomposeGEPExpression(), and shouldMergeGEPs().

bool llvm::GEPOperator::hasIndices ( ) const

inline

Definition at line 408 of file Operator.h.

References llvm::User::getNumOperands().

op_iterator llvm::GEPOperator::idx_begin ( )

inline

Definition at line 377 of file Operator.h.

References llvm::User::op_begin().

Referenced by llvm::DependenceAnalysis::depends(), and llvm::DependenceAnalysis::getSplitIteration().
