llvm::ScheduleDAG Class Reference

#include <ScheduleDAG.h>

Inheritance diagram for llvm::ScheduleDAG:

Collaboration diagram for llvm::ScheduleDAG:

Public Member Functions
	ScheduleDAG (MachineFunction &mf)
virtual	~ScheduleDAG ()
void	clearDAG ()
	clearDAG - clear the DAG state (between regions). More...
const MCInstrDesc *	getInstrDesc (const SUnit *SU) const
virtual void	viewGraph (const Twine &Name, const Twine &Title)
virtual void	viewGraph ()
	Out-of-line implementation with no arguments is handy for gdb. More...
virtual void	dumpNode (const SUnit *SU) const =0
virtual std::string	getGraphNodeLabel (const SUnit *SU) const =0
virtual std::string	getDAGName () const =0
	getDAGLabel - Return a label for the region of code covered by the DAG. More...
virtual void	addCustomGraphFeatures (GraphWriter< ScheduleDAG * > &) const
unsigned	VerifyScheduledDAG (bool isBottomUp)

Public Attributes
const TargetMachine &	TM
const TargetInstrInfo *	TII
const TargetRegisterInfo *	TRI
MachineFunction &	MF
MachineRegisterInfo &	MRI
std::vector< SUnit >	SUnits
SUnit	EntrySU
SUnit	ExitSU
bool	StressSched

Detailed Description

Definition at line 538 of file ScheduleDAG.h.

Constructor & Destructor Documentation

ScheduleDAG::ScheduleDAG ( MachineFunction &  mf )

explicit

Definition at line 36 of file ScheduleDAG.cpp.

References StressSched, and StressSchedOpt.

ScheduleDAG::~ScheduleDAG ( )

virtual

Definition at line 47 of file ScheduleDAG.cpp.

Member Function Documentation

virtual void llvm::ScheduleDAG::addCustomGraphFeatures ( GraphWriter< ScheduleDAG * > &  ) const

inlinevirtual

addCustomGraphFeatures - Add custom features for a visualization of the ScheduleDAG.

Definition at line 586 of file ScheduleDAG.h.

Referenced by llvm::DOTGraphTraits< ScheduleDAG * >::addCustomGraphFeatures().

void ScheduleDAG::clearDAG

(

)

clearDAG - clear the DAG state (between regions).

Clear the DAG state (e.g. between scheduling regions).

Definition at line 50 of file ScheduleDAG.cpp.

References EntrySU, ExitSU, and SUnits.

Referenced by llvm::ScheduleDAGInstrs::buildSchedGraph(), and llvm::ScheduleDAGSDNodes::Run().

virtual void llvm::ScheduleDAG::dumpNode ( const SUnit *  SU ) const

pure virtual

Implemented in llvm::ScheduleDAGInstrs, and llvm::ScheduleDAGSDNodes.

Referenced by llvm::SUnit::dump(), and llvm::ScoreboardHazardRecognizer::getHazardType().

virtual std::string llvm::ScheduleDAG::getDAGName ( ) const

pure virtual

getDAGLabel - Return a label for the region of code covered by the DAG.

Implemented in llvm::ScheduleDAGInstrs, and llvm::ScheduleDAGSDNodes.

Referenced by viewGraph().

virtual std::string llvm::ScheduleDAG::getGraphNodeLabel ( const SUnit *  SU ) const

pure virtual

getGraphNodeLabel - Return a label for an SUnit node in a visualization of the ScheduleDAG.

Implemented in llvm::ScheduleDAGInstrs, and llvm::ScheduleDAGSDNodes.

Referenced by llvm::DOTGraphTraits< ScheduleDAGMI * >::getNodeDescription().

const MCInstrDesc* llvm::ScheduleDAG::getInstrDesc ( const SUnit *  SU ) const

inline

getInstrDesc - Return the MCInstrDesc of this SUnit. Return NULL for SDNodes without a machine opcode.

Definition at line 564 of file ScheduleDAG.h.

References llvm::MachineInstr::getDesc(), llvm::SUnit::getInstr(), llvm::SUnit::getNode(), and llvm::SUnit::isInstr().

Referenced by llvm::PPCScoreboardHazardRecognizer::EmitInstruction(), llvm::ScoreboardHazardRecognizer::EmitInstruction(), and llvm::ScoreboardHazardRecognizer::getHazardType().

unsigned ScheduleDAG::VerifyScheduledDAG

(

bool

isBottomUp

)

VerifyScheduledDAG - Verify that all SUnits were scheduled and that their state is consistent. Return the number of scheduled SUnits.

VerifyScheduledDAG - Verify that all SUnits were scheduled and that their state is consistent. Return the number of scheduled nodes.

Definition at line 383 of file ScheduleDAG.cpp.

References llvm::dbgs(), and SUnits.

Referenced by llvm::ScheduleDAGSDNodes::VerifyScheduledSequence().

void ScheduleDAG::viewGraph ( const Twine &  Name, const Twine &  Title  )

virtual

viewGraph - Pop up a GraphViz/gv window with the ScheduleDAG rendered using 'dot'.

viewGraph - Pop up a ghostview window with the reachable parts of the DAG rendered using 'dot'.

Reimplemented in llvm::ScheduleDAGMI.

Definition at line 87 of file ScheduleDAGPrinter.cpp.

References llvm::errs(), and llvm::ViewGraph().

void ScheduleDAG::viewGraph ( )

virtual

Out-of-line implementation with no arguments is handy for gdb.

Reimplemented in llvm::ScheduleDAGMI.

Definition at line 98 of file ScheduleDAGPrinter.cpp.

References getDAGName().

Member Data Documentation

SUnit llvm::ScheduleDAG::EntrySU

Definition at line 546 of file ScheduleDAG.h.

Referenced by clearDAG(), llvm::ScheduleDAGInstrs::getGraphNodeLabel(), llvm::ScheduleDAGMI::initQueues(), and llvm::ScheduleDAGMI::releasePred().

SUnit llvm::ScheduleDAG::ExitSU

Definition at line 547 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGMI::addEdge(), llvm::ScheduleDAGInstrs::addPhysRegDeps(), llvm::ScheduleDAGInstrs::addSchedBarrierDeps(), llvm::ScheduleDAGInstrs::addVRegDefDeps(), llvm::ScheduleDAGInstrs::buildSchedGraph(), llvm::ScheduleDAGMI::canAddEdge(), clearDAG(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), llvm::ScheduleDAGMI::findRootsAndBiasEdges(), llvm::ScheduleDAGInstrs::getGraphNodeLabel(), llvm::ScheduleDAGMI::initQueues(), llvm::ScheduleDAGMI::releaseSucc(), and llvm::ScheduleDAGMI::updatePressureDiffs().

MachineFunction& llvm::ScheduleDAG::MF

Definition at line 543 of file ScheduleDAG.h.

Referenced by llvm::DOTGraphTraits< ScheduleDAG * >::getGraphName(), llvm::DOTGraphTraits< ScheduleDAGMI * >::getGraphName(), llvm::R600SchedStrategy::initialize(), and llvm::ConvergingVLIWScheduler::initialize().

MachineRegisterInfo& llvm::ScheduleDAG::MRI

Definition at line 544 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGInstrs::addVRegDefDeps(), llvm::ScheduleDAGInstrs::buildSchedGraph(), llvm::R600SchedStrategy::initialize(), llvm::ScheduleDAGInstrs::ScheduleDAGInstrs(), and llvm::ScheduleDAGMI::updatePressureDiffs().

bool llvm::ScheduleDAG::StressSched

Definition at line 552 of file ScheduleDAG.h.

Referenced by ScheduleDAG().

std::vector<SUnit> llvm::ScheduleDAG::SUnits

Definition at line 545 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGInstrs::buildSchedGraph(), clearDAG(), llvm::ScheduleDAGMI::computeDFSResult(), llvm::ScheduleDAGMI::findRootsAndBiasEdges(), llvm::ScheduleDAGSDNodes::getCustomGraphFeatures(), llvm::ScheduleDAGInstrs::initSUnits(), llvm::ScheduleDAGSDNodes::newSUnit(), llvm::ScheduleDAGInstrs::newSUnit(), llvm::GraphTraits< ScheduleDAG * >::nodes_begin(), llvm::GraphTraits< ScheduleDAG * >::nodes_end(), llvm::VLIWPacketizerList::PacketizeMIs(), llvm::R600SchedStrategy::pickNode(), llvm::VLIWMachineScheduler::postprocessDAG(), llvm::VLIWMachineScheduler::schedule(), llvm::ScheduleDAGMI::schedule(), and VerifyScheduledDAG().

const TargetInstrInfo* llvm::ScheduleDAG::TII

Definition at line 541 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGSDNodes::computeLatency(), llvm::ScheduleDAGSDNodes::computeOperandLatency(), createGenericSched(), llvm::ScoreboardHazardRecognizer::EmitInstruction(), llvm::ScheduleDAGSDNodes::EmitSchedule(), llvm::R600SchedStrategy::initialize(), and llvm::ScheduleDAGInstrs::ScheduleDAGInstrs().

const TargetMachine& llvm::ScheduleDAG::TM

Definition at line 540 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDataDeps(), llvm::ScheduleDAGInstrs::addVRegUseDeps(), llvm::ScheduleDAGInstrs::buildSchedGraph(), llvm::ScheduleDAGInstrs::getGraphNodeLabel(), llvm::R600SchedStrategy::initialize(), and llvm::ScheduleDAGInstrs::ScheduleDAGInstrs().

const TargetRegisterInfo* llvm::ScheduleDAG::TRI

Definition at line 542 of file ScheduleDAG.h.

Referenced by llvm::ScheduleDAGInstrs::addPhysRegDataDeps(), llvm::ScheduleDAGInstrs::addPhysRegDeps(), llvm::ScheduleDAGInstrs::addSchedBarrierDeps(), llvm::ScheduleDAGInstrs::buildSchedGraph(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), createGenericSched(), llvm::SUnit::dumpAll(), llvm::R600SchedStrategy::initialize(), llvm::ScheduleDAGMI::initRegPressure(), llvm::ConvergingVLIWScheduler::traceCandidate(), llvm::ScheduleDAGMI::updatePressureDiffs(), and llvm::ScheduleDAGMI::updateScheduledPressure().

---

The documentation for this class was generated from the following files:

• ScheduleDAG.h
• ScheduleDAG.cpp
• ScheduleDAGPrinter.cpp
