#include <ScheduleDAGInstrs.h>

Inheritance diagram for llvm::ScheduleDAGInstrs:

Collaboration diagram for llvm::ScheduleDAGInstrs:

Public Member Functions
	ScheduleDAGInstrs (MachineFunction &mf, const MachineLoopInfo &mli, const MachineDominatorTree &mdt, bool IsPostRAFlag, LiveIntervals *LIS=0)

virtual	~ScheduleDAGInstrs ()

LiveIntervals *	getLIS () const
	Expose LiveIntervals for use in DAG mutators and such. More...

const TargetSchedModel *	getSchedModel () const
	Get the machine model for instruction scheduling. More...

const MCSchedClassDesc *	getSchedClass (SUnit *SU) const
	Resolve and cache a resolved scheduling class for an SUnit. More...

MachineBasicBlock::iterator	begin () const
	begin - Return an iterator to the top of the current scheduling region. More...

MachineBasicBlock::iterator	end () const
	end - Return an iterator to the bottom of the current scheduling region. More...

SUnit *	newSUnit (MachineInstr *MI)
	newSUnit - Creates a new SUnit and return a ptr to it. More...

SUnit *	getSUnit (MachineInstr *MI) const
	getSUnit - Return an existing SUnit for this MI, or NULL. More...

virtual void	startBlock (MachineBasicBlock *BB)
	startBlock - Prepare to perform scheduling in the given block. More...

virtual void	finishBlock ()
	finishBlock - Clean up after scheduling in the given block. More...

virtual void	enterRegion (MachineBasicBlock *bb, MachineBasicBlock::iterator begin, MachineBasicBlock::iterator end, unsigned regioninstrs)
	Initialize the scheduler state for the next scheduling region. More...

virtual void	exitRegion ()
	Notify that the scheduler has finished scheduling the current region. More...

void	buildSchedGraph (AliasAnalysis AA, RegPressureTracker RPTracker=0, PressureDiffs *PDiffs=0)

void	addSchedBarrierDeps ()

virtual void	schedule ()=0

virtual void	finalizeSchedule ()

virtual void	dumpNode (const SUnit *SU) const

virtual std::string	getGraphNodeLabel (const SUnit *SU) const
	Return a label for a DAG node that points to an instruction. More...

virtual std::string	getDAGName () const
	Return a label for the region of code covered by the DAG. More...

Public Member Functions inherited from llvm::ScheduleDAG
	ScheduleDAG (MachineFunction &mf)

virtual	~ScheduleDAG ()

void	clearDAG ()
	clearDAG - clear the DAG state (between regions). More...

const MCInstrDesc *	getInstrDesc (const SUnit *SU) const

virtual void	viewGraph (const Twine &Name, const Twine &Title)

virtual void	viewGraph ()
	Out-of-line implementation with no arguments is handy for gdb. More...

virtual void	addCustomGraphFeatures (GraphWriter< ScheduleDAG * > &) const

unsigned	VerifyScheduledDAG (bool isBottomUp)

Protected Types
typedef std::vector< std::pair < MachineInstr , MachineInstr > >	DbgValueVector

Protected Member Functions
void	initSUnits ()

void	addPhysRegDataDeps (SUnit *SU, unsigned OperIdx)

void	addPhysRegDeps (SUnit *SU, unsigned OperIdx)

void	addVRegDefDeps (SUnit *SU, unsigned OperIdx)

void	addVRegUseDeps (SUnit *SU, unsigned OperIdx)

Protected Attributes
const MachineLoopInfo &	MLI

const MachineDominatorTree &	MDT

const MachineFrameInfo *	MFI

LiveIntervals *	LIS
	Live Intervals provides reaching defs in preRA scheduling. More...

TargetSchedModel	SchedModel
	TargetSchedModel provides an interface to the machine model. More...

bool	IsPostRA
	isPostRA flag indicates vregs cannot be present. More...

bool	CanHandleTerminators

MachineBasicBlock *	BB
	The block in which to insert instructions. More...

MachineBasicBlock::iterator	RegionBegin
	The beginning of the range to be scheduled. More...

MachineBasicBlock::iterator	RegionEnd
	The end of the range to be scheduled. More...

unsigned	NumRegionInstrs
	Instructions in this region (distance(RegionBegin, RegionEnd)). More...

DenseMap< MachineInstr , SUnit >	MISUnitMap

VReg2UseMap	VRegUses

Reg2SUnitsMap	Defs

Reg2SUnitsMap	Uses

VReg2SUnitMap	VRegDefs
	Track the last instruction in this region defining each virtual register. More...

std::vector< SUnit * >	PendingLoads

DbgValueVector	DbgValues

MachineInstr *	FirstDbgValue

Additional Inherited Members
Public Attributes inherited from llvm::ScheduleDAG
const TargetMachine &	TM

const TargetInstrInfo *	TII

const TargetRegisterInfo *	TRI

MachineFunction &	MF

MachineRegisterInfo &	MRI

std::vector< SUnit >	SUnits

SUnit	EntrySU

SUnit	ExitSU

bool	StressSched

Detailed Description

ScheduleDAGInstrs - A ScheduleDAG subclass for scheduling lists of MachineInstrs.

Definition at line 76 of file ScheduleDAGInstrs.h.

Member Typedef Documentation

typedef std::vector<std::pair<MachineInstr *, MachineInstr *> > llvm::ScheduleDAGInstrs::DbgValueVector

protected

DbgValues - Remember instruction that precedes DBG_VALUE. These are generated by buildSchedGraph but persist so they can be referenced when emitting the final schedule.

Definition at line 144 of file ScheduleDAGInstrs.h.

Constructor & Destructor Documentation

ScheduleDAGInstrs::ScheduleDAGInstrs	(	MachineFunction &	mf,
		const MachineLoopInfo &	mli,
		const MachineDominatorTree &	mdt,
		bool	IsPostRAFlag,
		LiveIntervals *	LIS = `0`
	)

explicit

Definition at line 47 of file ScheduleDAGInstrs.cpp.

References DbgValues, llvm::MachineRegisterInfo::getNumVirtRegs(), llvm::MCSubtargetInfo::getSchedModel(), llvm::TargetMachine::getSubtarget(), llvm::TargetSchedModel::init(), IsPostRA, LIS, llvm::ScheduleDAG::MRI, SchedModel, llvm::A64DB::ST, llvm::ScheduleDAG::TII, and llvm::ScheduleDAG::TM.

virtual llvm::ScheduleDAGInstrs::~ScheduleDAGInstrs ( )

inlinevirtual

Definition at line 155 of file ScheduleDAGInstrs.h.

Member Function Documentation

void ScheduleDAGInstrs::addPhysRegDataDeps	(	SUnit *	SU,
		unsigned	OperIdx
	)

protected

MO is an operand of SU's instruction that defines a physical register. Add data dependencies from SU to any uses of the physical register.

Definition at line 243 of file ScheduleDAGInstrs.cpp.

References llvm::SUnit::addPred(), llvm::SDep::Artificial, llvm::TargetSchedModel::computeOperandLatency(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::contains(), llvm::SDep::Data, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::end(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::find(), llvm::SUnit::getInstr(), llvm::MachineInstr::getOperand(), llvm::MachineOperand::getReg(), llvm::TargetMachine::getSubtarget(), llvm::SUnit::hasPhysRegDefs, I, llvm::MachineOperand::isDef(), llvm::MCRegAliasIterator::isValid(), SchedModel, llvm::SDep::setLatency(), llvm::A64DB::ST, llvm::ScheduleDAG::TM, llvm::ScheduleDAG::TRI, and Uses.

Referenced by addPhysRegDeps().

void ScheduleDAGInstrs::addPhysRegDeps	(	SUnit *	SU,
		unsigned	OperIdx
	)

protected

addPhysRegDeps - Add register dependencies (data, anti, and output) from this SUnit to following instructions in the same scheduling region that depend the physical register referenced at OperIdx.

Definition at line 286 of file ScheduleDAGInstrs.cpp.

References addPhysRegDataDeps(), llvm::SUnit::addPred(), llvm::SDep::Anti, llvm::TargetSchedModel::computeOutputLatency(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::contains(), Defs, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::end(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::equal_range(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::erase(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::eraseAll(), llvm::ScheduleDAG::ExitSU, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::find(), llvm::SUnit::getInstr(), llvm::MachineInstr::getOperand(), llvm::MachineOperand::getReg(), llvm::SUnit::hasPhysRegUses, I, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::insert(), llvm::SUnit::isCall, llvm::MachineOperand::isDead(), llvm::MachineOperand::isDef(), llvm::MachineOperand::isUse(), llvm::MCRegAliasIterator::isValid(), llvm::A64CC::MI, llvm::SDep::Output, P, llvm::MachineInstr::registerDefIsDead(), SchedModel, llvm::SDep::setLatency(), llvm::ScheduleDAG::TRI, and Uses.

Referenced by buildSchedGraph().

void ScheduleDAGInstrs::addSchedBarrierDeps ( )

addSchedBarrierDeps - Add dependencies from instructions in the current list of instructions being scheduled to scheduling barrier. We want to make sure instructions which define registers that are either used by the terminator or are live-out are properly scheduled. This is especially important when the definition latency of the return value(s) are too high to be hidden by the branch or when the liveout registers used by instructions in the fallthrough block.

addSchedBarrierDeps - Add dependencies from instructions in the current list of instructions being scheduled to scheduling barrier by adding the exit SU to the register defs and use list. This is because we want to make sure instructions which define registers that are either used by the terminator or are live-out are properly scheduled. This is especially important when the definition latency of the return value(s) are too high to be hidden by the branch or when the liveout registers used by instructions in the fallthrough block.

Definition at line 204 of file ScheduleDAGInstrs.cpp.

References addVRegUseDeps(), BB, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::contains(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::empty(), llvm::MachineBasicBlock::end(), llvm::ScheduleDAG::ExitSU, llvm::MachineInstr::getNumOperands(), llvm::MachineInstr::getOperand(), llvm::MachineOperand::getReg(), I, llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::insert(), llvm::MachineInstr::isBarrier(), llvm::MachineInstr::isCall(), llvm::MachineOperand::isDef(), llvm::TargetRegisterInfo::isPhysicalRegister(), IsPostRA, llvm::MachineOperand::isReg(), llvm::MachineOperand::readsReg(), RegionEnd, llvm::SUnit::setInstr(), llvm::MachineBasicBlock::succ_begin(), llvm::MachineBasicBlock::succ_end(), llvm::ScheduleDAG::TRI, and Uses.

Referenced by buildSchedGraph().

void ScheduleDAGInstrs::addVRegDefDeps	(	SUnit *	SU,
		unsigned	OperIdx
	)

protected

addVRegDefDeps - Add register output and data dependencies from this SUnit to instructions that occur later in the same scheduling region if they read from or write to the virtual register defined at OperIdx.

TODO: Hoist loop induction variable increments. This has to be reevaluated. Generally, IV scheduling should be done before coalescing.

Definition at line 365 of file ScheduleDAGInstrs.cpp.

References llvm::SUnit::addPred(), llvm::TargetSchedModel::computeOutputLatency(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::end(), llvm::ScheduleDAG::ExitSU, llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::find(), llvm::SUnit::getInstr(), llvm::MachineInstr::getOperand(), llvm::MachineOperand::getReg(), llvm::MachineRegisterInfo::hasOneDef(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::insert(), llvm::A64CC::MI, llvm::ScheduleDAG::MRI, llvm::SDep::Output, SchedModel, llvm::SDep::setLatency(), and VRegDefs.

Referenced by buildSchedGraph().

void ScheduleDAGInstrs::addVRegUseDeps	(	SUnit *	SU,
		unsigned	OperIdx
	)

protected

addVRegUseDeps - Add a register data dependency if the instruction that defines the virtual register used at OperIdx is mapped to an SUnit. Add a register antidependency from this SUnit to instructions that occur later in the same scheduling region if they write the virtual register.

TODO: Handle ExitSU "uses" properly.

Definition at line 403 of file ScheduleDAGInstrs.cpp.

References llvm::SUnit::addPred(), llvm::TargetSubtargetInfo::adjustSchedDependency(), llvm::SDep::Anti, llvm::TargetSchedModel::computeOperandLatency(), llvm::SDep::Data, llvm::tgtok::Def, llvm::VNInfo::def, llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::end(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::end(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::find(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::find(), llvm::MachineInstr::findRegisterDefOperandIdx(), llvm::SUnit::getInstr(), llvm::LiveIntervals::getInstructionFromIndex(), llvm::LiveIntervals::getInstructionIndex(), llvm::LiveIntervals::getInterval(), llvm::MachineInstr::getOperand(), llvm::MachineOperand::getReg(), llvm::TargetMachine::getSubtarget(), getSUnit(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::insert(), LIS, llvm::A64CC::MI, llvm::LiveRange::Query(), SchedModel, llvm::SDep::setLatency(), llvm::A64DB::ST, llvm::ScheduleDAG::TM, llvm::LiveQueryResult::valueIn(), VRegDefs, and VRegUses.

Referenced by addSchedBarrierDeps(), and buildSchedGraph().

MachineBasicBlock::iterator llvm::ScheduleDAGInstrs::begin ( ) const

inline

begin - Return an iterator to the top of the current scheduling region.

Definition at line 171 of file ScheduleDAGInstrs.h.

References RegionBegin.

Referenced by llvm::ScheduleDAGMI::dumpSchedule(), enterRegion(), and llvm::ScheduleDAGMI::schedule().

void ScheduleDAGInstrs::buildSchedGraph	(	AliasAnalysis *	AA,
		RegPressureTracker *	RPTracker = `0`,
		PressureDiffs *	PDiffs = `0`
	)

buildSchedGraph - Build SUnits from the MachineBasicBlock that we are input.

If RegPressure is non null, compute register pressure as a side effect. The DAG builder is an efficient place to do it because it already visits operands.

Definition at line 696 of file ScheduleDAGInstrs.cpp.

References addChainDependency(), addPhysRegDeps(), llvm::SUnit::addPred(), addSchedBarrierDeps(), addVRegDefDeps(), addVRegUseDeps(), adjustChainDeps(), llvm::SDep::Artificial, llvm::SDep::Barrier, llvm::MapVector< KeyT, ValueT, MapType, VectorType >::begin(), llvm::SmallVectorTemplateCommon< T, typename >::begin(), CanHandleTerminators, llvm::MapVector< KeyT, ValueT, MapType, VectorType >::clear(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::clear(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::clear(), llvm::ScheduleDAG::clearDAG(), DbgValues, Defs, llvm::SmallVectorBase::empty(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::empty(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::empty(), EnableAASchedMI, llvm::MapVector< KeyT, ValueT, MapType, VectorType >::end(), llvm::SmallVectorTemplateCommon< T, typename >::end(), llvm::ScheduleDAG::ExitSU, llvm::MapVector< KeyT, ValueT, MapType, VectorType >::find(), FirstDbgValue, llvm::MachineInstr::getNumOperands(), llvm::MCRegisterInfo::getNumRegs(), llvm::MachineRegisterInfo::getNumVirtRegs(), llvm::MachineInstr::getOperand(), llvm::RegPressureTracker::getPos(), llvm::MachineOperand::getReg(), llvm::TargetMachine::getSubtarget(), getUnderlyingObjectsForInstr(), I, llvm::ARM_PROC::IE, llvm::PressureDiffs::init(), initSUnits(), llvm::MachineInstr::isDebugValue(), llvm::MachineOperand::isDef(), isGlobalMemoryObject(), llvm::MachineInstr::isInvariantLoad(), llvm::MachineInstr::isLabel(), llvm::TargetRegisterInfo::isPhysicalRegister(), IsPostRA, llvm::SUnit::isPred(), llvm::MachineOperand::isReg(), llvm::MachineInstr::isTerminator(), llvm::SUnit::Latency, llvm::MachineInstr::mayLoad(), llvm::MachineInstr::mayStore(), MFI, llvm::A64CC::MI, MII, MISUnitMap, llvm::ScheduleDAG::MRI, llvm::SUnit::NodeNum, llvm::SUnit::NumSuccs, PendingLoads, llvm::prior(), llvm::MachineOperand::readsReg(), llvm::RegPressureTracker::recede(), RegionBegin, RegionEnd, llvm::SDep::setLatency(), llvm::SparseSet< ValueT, KeyFunctorT, SparseT >::setUniverse(), llvm::SparseMultiSet< ValueT, KeyFunctorT, SparseT >::setUniverse(), llvm::MapVector< KeyT, ValueT, MapType, VectorType >::size(), llvm::A64DB::ST, llvm::ScheduleDAG::SUnits, llvm::ScheduleDAG::TM, llvm::ScheduleDAG::TRI, llvm::TargetSubtargetInfo::useAA(), Uses, VRegDefs, and VRegUses.

Referenced by llvm::ScheduleDAGMI::buildDAGWithRegPressure(), and llvm::DefaultVLIWScheduler::schedule().

void ScheduleDAGInstrs::dumpNode ( const SUnit * SU ) const

virtual

Implements llvm::ScheduleDAG.

Definition at line 1002 of file ScheduleDAGInstrs.cpp.

References llvm::MachineInstr::dump(), and llvm::SUnit::getInstr().

MachineBasicBlock::iterator llvm::ScheduleDAGInstrs::end ( ) const

inline

end - Return an iterator to the bottom of the current scheduling region.

Definition at line 174 of file ScheduleDAGInstrs.h.

References RegionEnd.

Referenced by llvm::ScheduleDAGMI::dumpSchedule(), and enterRegion().

void ScheduleDAGInstrs::enterRegion	(	MachineBasicBlock *	bb,
		MachineBasicBlock::iterator	begin,
		MachineBasicBlock::iterator	end,
		unsigned	regioninstrs
	)

virtual

Initialize the scheduler state for the next scheduling region.

Initialize the DAG and common scheduler state for the current scheduling region. This does not actually create the DAG, only clears it. The scheduling driver may call BuildSchedGraph multiple times per scheduling region.

Reimplemented in llvm::ScheduleDAGMI.

Definition at line 180 of file ScheduleDAGInstrs.cpp.

References BB, begin(), end(), NumRegionInstrs, RegionBegin, and RegionEnd.

Referenced by llvm::ScheduleDAGMI::enterRegion(), and llvm::VLIWPacketizerList::PacketizeMIs().

void ScheduleDAGInstrs::exitRegion ( )

virtual

Notify that the scheduler has finished scheduling the current region.

Close the current scheduling region. Don't clear any state in case the driver wants to refer to the previous scheduling region.

Definition at line 192 of file ScheduleDAGInstrs.cpp.

Referenced by llvm::VLIWPacketizerList::PacketizeMIs().

virtual void llvm::ScheduleDAGInstrs::finalizeSchedule ( )

inlinevirtual

finalizeSchedule - Allow targets to perform final scheduling actions at the level of the whole MachineFunction. By default does nothing.

Definition at line 220 of file ScheduleDAGInstrs.h.

void ScheduleDAGInstrs::finishBlock ( )

virtual

finishBlock - Clean up after scheduling in the given block.

Definition at line 171 of file ScheduleDAGInstrs.cpp.

References BB.

Referenced by llvm::VLIWPacketizerList::PacketizeMIs().

std::string ScheduleDAGInstrs::getDAGName ( ) const

virtual

Return a label for the region of code covered by the DAG.

Return the basic block label. It is not necessarilly unique because a block contains multiple scheduling regions. But it is fine for visualization.

Implements llvm::ScheduleDAG.

Definition at line 1022 of file ScheduleDAGInstrs.cpp.

References BB, and llvm::MachineBasicBlock::getFullName().

Referenced by llvm::ScheduleDAGMI::viewGraph().

std::string ScheduleDAGInstrs::getGraphNodeLabel ( const SUnit * SU ) const

virtual

Return a label for a DAG node that points to an instruction.

Implements llvm::ScheduleDAG.

Definition at line 1008 of file ScheduleDAGInstrs.cpp.

References llvm::ScheduleDAG::EntrySU, llvm::ScheduleDAG::ExitSU, llvm::SUnit::getInstr(), llvm::MachineInstr::print(), llvm::raw_string_ostream::str(), and llvm::ScheduleDAG::TM.

LiveIntervals* llvm::ScheduleDAGInstrs::getLIS ( ) const

inline

Expose LiveIntervals for use in DAG mutators and such.

Definition at line 158 of file ScheduleDAGInstrs.h.

References LIS.

const MCSchedClassDesc* llvm::ScheduleDAGInstrs::getSchedClass ( SUnit * SU ) const

inline

Resolve and cache a resolved scheduling class for an SUnit.

Definition at line 164 of file ScheduleDAGInstrs.h.

References llvm::SUnit::getInstr(), llvm::TargetSchedModel::hasInstrSchedModel(), llvm::TargetSchedModel::resolveSchedClass(), llvm::SUnit::SchedClass, and SchedModel.

const TargetSchedModel* llvm::ScheduleDAGInstrs::getSchedModel ( ) const

inline

Get the machine model for instruction scheduling.

Definition at line 161 of file ScheduleDAGInstrs.h.

References SchedModel.

Referenced by llvm::ConvergingVLIWScheduler::initialize().

SUnit * llvm::ScheduleDAGInstrs::getSUnit ( MachineInstr * MI ) const

inline

getSUnit - Return an existing SUnit for this MI, or NULL.

Definition at line 251 of file ScheduleDAGInstrs.h.

References I, and MISUnitMap.

Referenced by addVRegUseDeps(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), and llvm::ScheduleDAGMI::dumpSchedule().

void ScheduleDAGInstrs::initSUnits ( )

protected

Create an SUnit for each real instruction, numbered in top-down toplological order. The instruction order A < B, implies that no edge exists from B to A.

Map each real instruction to its SUnit.

After initSUnits, the SUnits vector cannot be resized and the scheduler may hang onto SUnit pointers. We may relax this in the future by using SUnit IDs instead of pointers.

MachineScheduler relies on initSUnits numbering the nodes by their order in the original instruction list.

Definition at line 672 of file ScheduleDAGInstrs.cpp.

References llvm::TargetSchedModel::computeInstrLatency(), llvm::SUnit::getInstr(), I, llvm::SUnit::isCall, llvm::MachineInstr::isCall(), llvm::SUnit::isCommutable, llvm::MachineInstr::isCommutable(), llvm::MachineInstr::isDebugValue(), llvm::SUnit::Latency, llvm::A64CC::MI, MISUnitMap, newSUnit(), NumRegionInstrs, RegionBegin, RegionEnd, SchedModel, and llvm::ScheduleDAG::SUnits.

Referenced by buildSchedGraph().

SUnit * llvm::ScheduleDAGInstrs::newSUnit ( MachineInstr * MI )

inline

newSUnit - Creates a new SUnit and return a ptr to it.

Definition at line 239 of file ScheduleDAGInstrs.h.

References llvm::ScheduleDAG::SUnits.

Referenced by initSUnits().

virtual void llvm::ScheduleDAGInstrs::schedule ( )

pure virtual

schedule - Order nodes according to selected style, filling in the Sequence member.

Typically, a scheduling algorithm will implement schedule() without overriding enterRegion() or exitRegion().

Implemented in llvm::ScheduleDAGMI, llvm::DefaultVLIWScheduler, and llvm::VLIWMachineScheduler.

void ScheduleDAGInstrs::startBlock ( MachineBasicBlock * BB )

virtual

startBlock - Prepare to perform scheduling in the given block.

Definition at line 167 of file ScheduleDAGInstrs.cpp.

References BB.

Referenced by llvm::VLIWPacketizerList::PacketizeMIs().

Member Data Documentation

MachineBasicBlock* llvm::ScheduleDAGInstrs::BB

protected

The block in which to insert instructions.

State specific to the current scheduling region.

Definition at line 102 of file ScheduleDAGInstrs.h.

Referenced by addSchedBarrierDeps(), llvm::ScheduleDAGMI::buildDAGWithRegPressure(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), enterRegion(), finishBlock(), getDAGName(), llvm::ScheduleDAGMI::initRegPressure(), llvm::ScheduleDAGMI::moveInstruction(), llvm::ScheduleDAGMI::placeDebugValues(), llvm::VLIWMachineScheduler::schedule(), startBlock(), and llvm::ScheduleDAGMI::updatePressureDiffs().

bool llvm::ScheduleDAGInstrs::CanHandleTerminators

protected

The standard DAG builder does not normally include terminators as DAG nodes because it does not create the necessary dependencies to prevent reordering. A specialized scheduler can overide TargetInstrInfo::isSchedulingBoundary then enable this flag to indicate it has taken responsibility for scheduling the terminator correctly.

Definition at line 96 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph(), and llvm::DefaultVLIWScheduler::DefaultVLIWScheduler().

DbgValueVector llvm::ScheduleDAGInstrs::DbgValues

protected

Definition at line 145 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph(), llvm::ScheduleDAGMI::placeDebugValues(), and ScheduleDAGInstrs().

Reg2SUnitsMap llvm::ScheduleDAGInstrs::Defs

protected

State internal to DAG building.

Defs, Uses - Remember where defs and uses of each register are as we iterate upward through the instructions. This is allocated here instead of inside BuildSchedGraph to avoid the need for it to be initialized and destructed for each block.

Definition at line 129 of file ScheduleDAGInstrs.h.

Referenced by addPhysRegDeps(), and buildSchedGraph().

MachineInstr* llvm::ScheduleDAGInstrs::FirstDbgValue

protected

Definition at line 146 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph(), and llvm::ScheduleDAGMI::placeDebugValues().

bool llvm::ScheduleDAGInstrs::IsPostRA

protected

isPostRA flag indicates vregs cannot be present.

Definition at line 89 of file ScheduleDAGInstrs.h.

Referenced by addSchedBarrierDeps(), buildSchedGraph(), and ScheduleDAGInstrs().

LiveIntervals* llvm::ScheduleDAGInstrs::LIS

protected

Live Intervals provides reaching defs in preRA scheduling.

Definition at line 83 of file ScheduleDAGInstrs.h.

Referenced by addVRegUseDeps(), getLIS(), and ScheduleDAGInstrs().

const MachineDominatorTree& llvm::ScheduleDAGInstrs::MDT

protected

Definition at line 79 of file ScheduleDAGInstrs.h.

const MachineFrameInfo* llvm::ScheduleDAGInstrs::MFI

protected

Definition at line 80 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph().

DenseMap<MachineInstr*, SUnit*> llvm::ScheduleDAGInstrs::MISUnitMap

protected

After calling BuildSchedGraph, each machine instruction in the current scheduling region is mapped to an SUnit.

Definition at line 115 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph(), getSUnit(), and initSUnits().

const MachineLoopInfo& llvm::ScheduleDAGInstrs::MLI

protected

Definition at line 78 of file ScheduleDAGInstrs.h.

Referenced by llvm::VLIWMachineScheduler::schedule().

unsigned llvm::ScheduleDAGInstrs::NumRegionInstrs

protected

Instructions in this region (distance(RegionBegin, RegionEnd)).

Definition at line 111 of file ScheduleDAGInstrs.h.

Referenced by enterRegion(), and initSUnits().

std::vector<SUnit *> llvm::ScheduleDAGInstrs::PendingLoads

protected

PendingLoads - Remember where unknown loads are after the most recent unknown store, as we iterate. As with Defs and Uses, this is here to minimize construction/destruction.

Definition at line 138 of file ScheduleDAGInstrs.h.

Referenced by buildSchedGraph().

MachineBasicBlock::iterator llvm::ScheduleDAGInstrs::RegionBegin

protected

The beginning of the range to be scheduled.

Definition at line 105 of file ScheduleDAGInstrs.h.

Referenced by begin(), buildSchedGraph(), enterRegion(), llvm::ScheduleDAGMI::initQueues(), llvm::ScheduleDAGMI::initRegPressure(), initSUnits(), llvm::ScheduleDAGMI::moveInstruction(), and llvm::ScheduleDAGMI::placeDebugValues().

MachineBasicBlock::iterator llvm::ScheduleDAGInstrs::RegionEnd

protected

The end of the range to be scheduled.

Definition at line 108 of file ScheduleDAGInstrs.h.

Referenced by addSchedBarrierDeps(), llvm::ScheduleDAGMI::buildDAGWithRegPressure(), buildSchedGraph(), end(), enterRegion(), llvm::ScheduleDAGMI::enterRegion(), llvm::ScheduleDAGMI::initQueues(), llvm::ScheduleDAGMI::initRegPressure(), initSUnits(), and llvm::ScheduleDAGMI::placeDebugValues().

TargetSchedModel llvm::ScheduleDAGInstrs::SchedModel

protected

TargetSchedModel provides an interface to the machine model.

Definition at line 86 of file ScheduleDAGInstrs.h.

Referenced by addPhysRegDataDeps(), addPhysRegDeps(), addVRegDefDeps(), addVRegUseDeps(), getSchedClass(), getSchedModel(), initSUnits(), and ScheduleDAGInstrs().

Reg2SUnitsMap llvm::ScheduleDAGInstrs::Uses

protected

Definition at line 130 of file ScheduleDAGInstrs.h.

Referenced by addPhysRegDataDeps(), addPhysRegDeps(), addSchedBarrierDeps(), and buildSchedGraph().

VReg2SUnitMap llvm::ScheduleDAGInstrs::VRegDefs

protected

Track the last instruction in this region defining each virtual register.

Definition at line 133 of file ScheduleDAGInstrs.h.

Referenced by addVRegDefDeps(), addVRegUseDeps(), and buildSchedGraph().

VReg2UseMap llvm::ScheduleDAGInstrs::VRegUses

protected

After calling BuildSchedGraph, each vreg used in the scheduling region is mapped to a set of SUnits. These include all local vreg uses, not just the uses for a singly defined vreg.

Definition at line 120 of file ScheduleDAGInstrs.h.

Referenced by addVRegUseDeps(), buildSchedGraph(), llvm::ScheduleDAGMI::computeCyclicCriticalPath(), and llvm::ScheduleDAGMI::updatePressureDiffs().

The documentation for this class was generated from the following files:

Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation

State specific to the current scheduling region.

State internal to DAG building.
