#include <HexagonMachineScheduler.h>

Inheritance diagram for llvm::VLIWMachineScheduler:

Collaboration diagram for llvm::VLIWMachineScheduler:

Public Member Functions
	VLIWMachineScheduler (MachineSchedContext C, MachineSchedStrategy S)

virtual void	schedule ()

void	postprocessDAG ()
	Perform platform specific DAG postprocessing. More...

Public Member Functions inherited from llvm::ScheduleDAGMI
	ScheduleDAGMI (MachineSchedContext C, MachineSchedStrategy S)

virtual	~ScheduleDAGMI ()

bool	isTrackingPressure () const
	Return true if register pressure tracking is enabled. More...

void	addMutation (ScheduleDAGMutation *Mutation)

bool	canAddEdge (SUnit SuccSU, SUnit PredSU)
	True if an edge can be added from PredSU to SuccSU without creating a cycle. More...

bool	addEdge (SUnit *SuccSU, const SDep &PredDep)
	Add a DAG edge to the given SU with the given predecessor dependence data. More...

MachineBasicBlock::iterator	top () const

MachineBasicBlock::iterator	bottom () const

void	enterRegion (MachineBasicBlock *bb, MachineBasicBlock::iterator begin, MachineBasicBlock::iterator end, unsigned regioninstrs) LLVM_OVERRIDE

void	moveInstruction (MachineInstr *MI, MachineBasicBlock::iterator InsertPos)

const IntervalPressure &	getTopPressure () const
	Get current register pressure for the top scheduled instructions. More...

const RegPressureTracker &	getTopRPTracker () const

const IntervalPressure &	getBotPressure () const
	Get current register pressure for the bottom scheduled instructions. More...

const RegPressureTracker &	getBotRPTracker () const

const IntervalPressure &	getRegPressure () const
	Get register pressure for the entire scheduling region before scheduling. More...

const std::vector < PressureChange > &	getRegionCriticalPSets () const

PressureDiff &	getPressureDiff (const SUnit *SU)

const SUnit *	getNextClusterPred () const

const SUnit *	getNextClusterSucc () const

void	computeDFSResult ()

const SchedDFSResult *	getDFSResult () const
	Return a non-null DFS result if the scheduling strategy initialized it. More...

BitVector &	getScheduledTrees ()

unsigned	computeCyclicCriticalPath ()
	Compute the cyclic critical path through the DAG. More...

void	viewGraph (const Twine &Name, const Twine &Title) LLVM_OVERRIDE

void	viewGraph () LLVM_OVERRIDE
	Out-of-line implementation with no arguments is handy for gdb. More...

Public Member Functions inherited from llvm::ScheduleDAGInstrs
	ScheduleDAGInstrs (MachineFunction &mf, const MachineLoopInfo &mli, const MachineDominatorTree &mdt, bool IsPostRAFlag, LiveIntervals *LIS=0)

virtual	~ScheduleDAGInstrs ()

LiveIntervals *	getLIS () const
	Expose LiveIntervals for use in DAG mutators and such. More...

const TargetSchedModel *	getSchedModel () const
	Get the machine model for instruction scheduling. More...

const MCSchedClassDesc *	getSchedClass (SUnit *SU) const
	Resolve and cache a resolved scheduling class for an SUnit. More...

MachineBasicBlock::iterator	begin () const
	begin - Return an iterator to the top of the current scheduling region. More...

MachineBasicBlock::iterator	end () const
	end - Return an iterator to the bottom of the current scheduling region. More...

SUnit *	newSUnit (MachineInstr *MI)
	newSUnit - Creates a new SUnit and return a ptr to it. More...

SUnit *	getSUnit (MachineInstr *MI) const
	getSUnit - Return an existing SUnit for this MI, or NULL. More...

virtual void	startBlock (MachineBasicBlock *BB)
	startBlock - Prepare to perform scheduling in the given block. More...

virtual void	finishBlock ()
	finishBlock - Clean up after scheduling in the given block. More...

virtual void	exitRegion ()
	Notify that the scheduler has finished scheduling the current region. More...

void	buildSchedGraph (AliasAnalysis AA, RegPressureTracker RPTracker=0, PressureDiffs *PDiffs=0)

void	addSchedBarrierDeps ()

virtual void	finalizeSchedule ()

virtual void	dumpNode (const SUnit *SU) const

virtual std::string	getGraphNodeLabel (const SUnit *SU) const
	Return a label for a DAG node that points to an instruction. More...

virtual std::string	getDAGName () const
	Return a label for the region of code covered by the DAG. More...

Public Member Functions inherited from llvm::ScheduleDAG
	ScheduleDAG (MachineFunction &mf)

virtual	~ScheduleDAG ()

void	clearDAG ()
	clearDAG - clear the DAG state (between regions). More...

const MCInstrDesc *	getInstrDesc (const SUnit *SU) const

virtual void	addCustomGraphFeatures (GraphWriter< ScheduleDAG * > &) const

unsigned	VerifyScheduledDAG (bool isBottomUp)

Additional Inherited Members
Public Attributes inherited from llvm::ScheduleDAG
const TargetMachine &	TM

const TargetInstrInfo *	TII

const TargetRegisterInfo *	TRI

MachineFunction &	MF

MachineRegisterInfo &	MRI

std::vector< SUnit >	SUnits

SUnit	EntrySU

SUnit	ExitSU

bool	StressSched

Protected Types inherited from llvm::ScheduleDAGInstrs
typedef std::vector< std::pair < MachineInstr , MachineInstr > >	DbgValueVector

Protected Member Functions inherited from llvm::ScheduleDAGMI
void	buildDAGWithRegPressure ()
	Build the DAG and setup three register pressure trackers. More...

void	postprocessDAG ()
	Apply each ScheduleDAGMutation step in order. More...

void	initQueues (ArrayRef< SUnit * > TopRoots, ArrayRef< SUnit * > BotRoots)
	Release ExitSU predecessors and setup scheduler queues. More...

void	scheduleMI (SUnit *SU, bool IsTopNode)
	Move an instruction and update register pressure. More...

void	updateQueues (SUnit *SU, bool IsTopNode)
	Update scheduler DAG and queues after scheduling an instruction. More...

void	placeDebugValues ()
	Reinsert debug_values recorded in ScheduleDAGInstrs::DbgValues. More...

void	dumpSchedule () const
	dump the scheduled Sequence. More...

void	initRegPressure ()

void	updatePressureDiffs (ArrayRef< unsigned > LiveUses)

void	updateScheduledPressure (const SUnit *SU, const std::vector< unsigned > &NewMaxPressure)

bool	checkSchedLimit ()

void	findRootsAndBiasEdges (SmallVectorImpl< SUnit * > &TopRoots, SmallVectorImpl< SUnit * > &BotRoots)

void	releaseSucc (SUnit SU, SDep SuccEdge)

void	releaseSuccessors (SUnit *SU)
	releaseSuccessors - Call releaseSucc on each of SU's successors. More...

void	releasePred (SUnit SU, SDep PredEdge)

void	releasePredecessors (SUnit *SU)
	releasePredecessors - Call releasePred on each of SU's predecessors. More...

Protected Member Functions inherited from llvm::ScheduleDAGInstrs
void	initSUnits ()

void	addPhysRegDataDeps (SUnit *SU, unsigned OperIdx)

void	addPhysRegDeps (SUnit *SU, unsigned OperIdx)

void	addVRegDefDeps (SUnit *SU, unsigned OperIdx)

void	addVRegUseDeps (SUnit *SU, unsigned OperIdx)

Protected Attributes inherited from llvm::ScheduleDAGMI
AliasAnalysis *	AA

RegisterClassInfo *	RegClassInfo

MachineSchedStrategy *	SchedImpl

SchedDFSResult *	DFSResult

BitVector	ScheduledTrees

ScheduleDAGTopologicalSort	Topo

std::vector < ScheduleDAGMutation * >	Mutations
	Ordered list of DAG postprocessing steps. More...

MachineBasicBlock::iterator	LiveRegionEnd

PressureDiffs	SUPressureDiffs

bool	ShouldTrackPressure
	Register pressure in this region computed by initRegPressure. More...

IntervalPressure	RegPressure

RegPressureTracker	RPTracker

std::vector< PressureChange >	RegionCriticalPSets

MachineBasicBlock::iterator	CurrentTop
	The top of the unscheduled zone. More...

IntervalPressure	TopPressure

RegPressureTracker	TopRPTracker

MachineBasicBlock::iterator	CurrentBottom
	The bottom of the unscheduled zone. More...

IntervalPressure	BotPressure

RegPressureTracker	BotRPTracker

const SUnit *	NextClusterPred
	Record the next node in a scheduled cluster. More...

const SUnit *	NextClusterSucc

unsigned	NumInstrsScheduled

Protected Attributes inherited from llvm::ScheduleDAGInstrs
const MachineLoopInfo &	MLI

const MachineDominatorTree &	MDT

const MachineFrameInfo *	MFI

LiveIntervals *	LIS
	Live Intervals provides reaching defs in preRA scheduling. More...

TargetSchedModel	SchedModel
	TargetSchedModel provides an interface to the machine model. More...

bool	IsPostRA
	isPostRA flag indicates vregs cannot be present. More...

bool	CanHandleTerminators

MachineBasicBlock *	BB
	The block in which to insert instructions. More...

MachineBasicBlock::iterator	RegionBegin
	The beginning of the range to be scheduled. More...

MachineBasicBlock::iterator	RegionEnd
	The end of the range to be scheduled. More...

unsigned	NumRegionInstrs
	Instructions in this region (distance(RegionBegin, RegionEnd)). More...

DenseMap< MachineInstr , SUnit >	MISUnitMap

VReg2UseMap	VRegUses

Reg2SUnitsMap	Defs

Reg2SUnitsMap	Uses

VReg2SUnitMap	VRegDefs
	Track the last instruction in this region defining each virtual register. More...

std::vector< SUnit * >	PendingLoads

DbgValueVector	DbgValues

MachineInstr *	FirstDbgValue

Detailed Description

Extend the standard ScheduleDAGMI to provide more context and override the top-level schedule() driver.

Definition at line 95 of file HexagonMachineScheduler.h.

Constructor & Destructor Documentation

llvm::VLIWMachineScheduler::VLIWMachineScheduler	(	MachineSchedContext *	C,
		MachineSchedStrategy *	S
	)

inline

Definition at line 97 of file HexagonMachineScheduler.h.

Member Function Documentation

void VLIWMachineScheduler::postprocessDAG ( )

Perform platform specific DAG postprocessing.

Platform specific modifications to DAG.

Definition at line 24 of file HexagonMachineScheduler.cpp.

References llvm::SDep::Barrier, and llvm::ScheduleDAG::SUnits.

Referenced by schedule().

void VLIWMachineScheduler::schedule ( )

virtual

Schedule - This is called back from ScheduleDAGInstrs::Run() when it's time to do some work.

schedule - Called back from MachineScheduler::runOnMachineFunction after setting up the current scheduling region. [RegionBegin, RegionEnd) only includes instructions that have DAG nodes, not scheduling boundaries.

Reimplemented from llvm::ScheduleDAGMI.

Definition at line 143 of file HexagonMachineScheduler.cpp.

References llvm::ScheduleDAGInstrs::BB, llvm::ScheduleDAGMI::buildDAGWithRegPressure(), llvm::ScheduleDAGMI::checkSchedLimit(), llvm::ScheduleDAGMI::CurrentBottom, llvm::ScheduleDAGMI::CurrentTop, llvm::dbgs(), DEBUG, llvm::ScheduleDAGMI::findRootsAndBiasEdges(), llvm::MachineFunction::getFunction(), llvm::MachineLoopInfo::getLoopDepth(), llvm::MachineBasicBlock::getName(), llvm::Value::getName(), llvm::MachineBasicBlock::getNumber(), llvm::MachineBasicBlock::getParent(), llvm::MachineSchedStrategy::initialize(), llvm::ScheduleDAGMI::initQueues(), llvm::ScheduleDAGInstrs::MLI, llvm::MachineSchedStrategy::pickNode(), llvm::ScheduleDAGMI::placeDebugValues(), postprocessDAG(), llvm::ScheduleDAGMI::SchedImpl, llvm::ScheduleDAGMI::scheduleMI(), llvm::ScheduleDAG::SUnits, and llvm::ScheduleDAGMI::updateQueues().

The documentation for this class was generated from the following files:
