llvm::LoopBase< N, M > Class Template Reference

#include <LoopInfo.h>

Inheritance diagram for llvm::LoopBase< N, M >:

Public Types
typedef std::vector< LoopT * > ::const_iterator	iterator
typedef std::vector< LoopT * > ::const_reverse_iterator	reverse_iterator
typedef std::vector< BlockT * > ::const_iterator	block_iterator
typedef std::pair< const BlockT *, const BlockT * >	Edge
	Edge type. More...

Public Member Functions
	LoopBase ()
	Loop ctor - This creates an empty loop. More...
	~LoopBase ()
unsigned	getLoopDepth () const
BlockT *	getHeader () const
LoopT *	getParentLoop () const
void	setParentLoop (LoopT *L)
	setParentLoop is a raw interface for bypassing addChildLoop. More...
bool	contains (const LoopT *L) const
bool	contains (const BlockT *BB) const
template<class InstT >
bool	contains (const InstT *Inst) const
const std::vector< LoopT * > &	getSubLoops () const
std::vector< LoopT * > &	getSubLoopsVector ()
iterator	begin () const
iterator	end () const
reverse_iterator	rbegin () const
reverse_iterator	rend () const
bool	empty () const
const std::vector< BlockT * > &	getBlocks () const
block_iterator	block_begin () const
block_iterator	block_end () const
unsigned	getNumBlocks () const
	getNumBlocks - Get the number of blocks in this loop in constant time. More...
bool	isLoopExiting (const BlockT *BB) const
unsigned	getNumBackEdges () const
void	getExitingBlocks (SmallVectorImpl< BlockT * > &ExitingBlocks) const
BlockT *	getExitingBlock () const
void	getExitBlocks (SmallVectorImpl< BlockT * > &ExitBlocks) const
BlockT *	getExitBlock () const
void	getExitEdges (SmallVectorImpl< Edge > &ExitEdges) const
	getExitEdges - Return all pairs of (inside_block,outside_block). More...
BlockT *	getLoopPreheader () const
BlockT *	getLoopPredecessor () const
BlockT *	getLoopLatch () const
void	addBasicBlockToLoop (BlockT *NewBB, LoopInfoBase< BlockT, LoopT > &LI)
void	replaceChildLoopWith (LoopT *OldChild, LoopT *NewChild)
void	addChildLoop (LoopT *NewChild)
LoopT *	removeChildLoop (iterator I)
void	addBlockEntry (BlockT *BB)
void	reverseBlock (unsigned from)
	reverseBlocks - interface to reverse Blocks[from, end of loop] in this loop More...
void	reserveBlocks (unsigned size)
	reserveBlocks- interface to do reserve() for Blocks More...
void	moveToHeader (BlockT *BB)
void	removeBlockFromLoop (BlockT *BB)
void	verifyLoop () const
	verifyLoop - Verify loop structure More...
void	verifyLoopNest (DenseSet< const LoopT * > *Loops) const
	verifyLoop - Verify loop structure of this loop and all nested loops. More...
void	print (raw_ostream &OS, unsigned Depth=0) const

Protected Member Functions
	LoopBase (BlockT *BB)

Friends
class	LoopInfoBase< BlockT, LoopT >

Detailed Description

template<class N, class M>
class llvm::LoopBase< N, M >

LoopBase class - Instances of this class are used to represent loops that are detected in the flow graph

Definition at line 57 of file LoopInfo.h.

Member Typedef Documentation

template<class N, class M>

typedef std::vector<BlockT*>::const_iterator llvm::LoopBase< N, M >::block_iterator

Definition at line 139 of file LoopInfo.h.

template<class N, class M>

typedef std::pair<const BlockT*, const BlockT*> llvm::LoopBase< N, M >::Edge

Edge type.

Definition at line 206 of file LoopInfo.h.

template<class N, class M>

typedef std::vector<LoopT *>::const_iterator llvm::LoopBase< N, M >::iterator

Definition at line 127 of file LoopInfo.h.

template<class N, class M>

typedef std::vector<LoopT *>::const_reverse_iterator llvm::LoopBase< N, M >::reverse_iterator

Definition at line 129 of file LoopInfo.h.

Constructor & Destructor Documentation

template<class N, class M>

llvm::LoopBase< N, M >::LoopBase ( )

inline

Loop ctor - This creates an empty loop.

Definition at line 79 of file LoopInfo.h.

template<class N, class M>

llvm::LoopBase< N, M >::~LoopBase ( )

inline

Definition at line 80 of file LoopInfo.h.

template<class N, class M>

llvm::LoopBase< N, M >::LoopBase ( BlockT *  BB )

inlineexplicitprotected

Definition at line 321 of file LoopInfo.h.

Member Function Documentation

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::addBasicBlockToLoop	(	BlockT *	NewBB,
		LoopInfoBase< BlockT, LoopT > &	LIB
	)

addBasicBlockToLoop - This method is used by other analyses to update loop information. NewBB is set to be a new member of the current loop. Because of this, it is added as a member of all parent loops, and is added to the specified LoopInfo object as being in the current basic block. It is not valid to replace the loop header with this method.

Definition at line 185 of file LoopInfoImpl.h.

Referenced by CloneLoop(), llvm::UnrollLoop(), and UpdateAnalysisInformation().

template<class N, class M>

void llvm::LoopBase< N, M >::addBlockEntry ( BlockT *  BB )

inline

addBlockEntry - This adds a basic block directly to the basic block list. This should only be used by transformations that create new loops. Other transformations should use addBasicBlockToLoop.

Definition at line 273 of file LoopInfo.h.

template<class N, class M>

void llvm::LoopBase< N, M >::addChildLoop ( LoopT *  NewChild )

inline

addChildLoop - Add the specified loop to be a child of this loop. This updates the loop depth of the new child.

Definition at line 252 of file LoopInfo.h.

Referenced by llvm::LPPassManager::insertLoop().

template<class N, class M>

iterator llvm::LoopBase< N, M >::begin ( ) const

inline

Definition at line 130 of file LoopInfo.h.

Referenced by llvm::GraphTraits< const MachineLoop * >::child_begin(), llvm::GraphTraits< MachineLoop * >::child_begin(), llvm::GraphTraits< const Loop * >::child_begin(), llvm::GraphTraits< Loop * >::child_begin(), CloneLoop(), llvm::ScalarEvolution::forgetLoop(), llvm::ScalarEvolution::print(), PrintChildLoopComment(), PrintLoopInfo(), llvm::LoopBase< BasicBlock, Loop >::removeChildLoop(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

block_iterator llvm::LoopBase< N, M >::block_begin ( ) const

inline

Definition at line 140 of file LoopInfo.h.

Referenced by ApproximateLoopSize(), CloneLoop(), llvm::Loop::getLoopID(), llvm::Loop::getUniqueExitBlocks(), llvm::Loop::isAnnotatedParallel(), llvm::Loop::isLCSSAForm(), llvm::Loop::isSafeToClone(), mayLoopAccessLocation(), llvm::Loop::setLoopID(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

block_iterator llvm::LoopBase< N, M >::block_end ( ) const

inline

Definition at line 141 of file LoopInfo.h.

Referenced by ApproximateLoopSize(), CloneLoop(), llvm::Loop::getLoopID(), llvm::Loop::getUniqueExitBlocks(), llvm::Loop::isAnnotatedParallel(), llvm::Loop::isLCSSAForm(), llvm::Loop::isSafeToClone(), mayLoopAccessLocation(), llvm::Loop::setLoopID(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

bool llvm::LoopBase< N, M >::contains ( const LoopT *  L ) const

inline

contains - Return true if the specified loop is contained within in this loop.

Definition at line 104 of file LoopInfo.h.

Referenced by canConstantEvolve(), CloneLoopBlocks(), ConnectProlog(), llvm::LoopBase< BasicBlock, Loop >::contains(), FindPHIToPartitionLoops(), llvm::ScalarEvolution::getAddRecExpr(), llvm::Loop::getCanonicalInductionVariable(), llvm::LoopBase< BasicBlock, Loop >::getNumBackEdges(), llvm::Loop::getUniqueExitBlocks(), llvm::Loop::hasDedicatedExits(), hasOutsideLoopUser(), hasUsesOutsideLoop(), llvm::InsertPreheaderForLoop(), isExitingLoop(), isInteresting(), llvm::Loop::isLCSSAForm(), llvm::LoopBase< BasicBlock, Loop >::isLoopExiting(), isTrivialLoopExitBlockHelper(), IVUseShouldUsePostIncValue(), PickMostRelevantLoop(), PlaceSplitBlockCarefully(), llvm::LoopInfo::replacementPreservesLCSSAForm(), llvm::UnrollLoop(), and llvm::LoopBlocksTraversal::visitPreorder().

template<class N, class M>

bool llvm::LoopBase< N, M >::contains ( const BlockT *  BB ) const

inline

contains - Return true if the specified basic block is in this loop.

Definition at line 112 of file LoopInfo.h.

template<class N, class M>

template<class InstT >

bool llvm::LoopBase< N, M >::contains ( const InstT *  Inst ) const

inline

contains - Return true if the specified instruction is in this loop.

Definition at line 119 of file LoopInfo.h.

template<class N, class M>

bool llvm::LoopBase< N, M >::empty ( ) const

inline

Definition at line 134 of file LoopInfo.h.

Referenced by emitBasicBlockLoopComments(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

iterator llvm::LoopBase< N, M >::end ( ) const

inline

Definition at line 131 of file LoopInfo.h.

Referenced by llvm::GraphTraits< const MachineLoop * >::child_end(), llvm::GraphTraits< MachineLoop * >::child_end(), llvm::GraphTraits< const Loop * >::child_end(), llvm::GraphTraits< Loop * >::child_end(), CloneLoop(), llvm::ScalarEvolution::forgetLoop(), llvm::ScalarEvolution::print(), PrintChildLoopComment(), PrintLoopInfo(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

const std::vector<BlockT*>& llvm::LoopBase< N, M >::getBlocks ( ) const

inline

getBlocks - Get a list of the basic blocks which make up this loop.

Definition at line 138 of file LoopInfo.h.

Referenced by llvm::UnrollLoop().

template<class BlockT , class LoopT >

BlockT * llvm::LoopBase< BlockT, LoopT >::getExitBlock

(

)

const

getExitBlock - If getExitBlocks would return exactly one block, return that block. Otherwise return null.

Definition at line 76 of file LoopInfoImpl.h.

References llvm::SmallVectorTemplateCommon< T >::size().

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::getExitBlocks

(

SmallVectorImpl< BlockT * > &

ExitBlocks

)

const

getExitBlocks - Return all of the successor blocks of this loop. These are the blocks outside of the current loop which are branched to.

Definition at line 62 of file LoopInfoImpl.h.

References I, and llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back().

Referenced by llvm::Loop::hasDedicatedExits(), and PrintLoopInfo().

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::getExitEdges

(

SmallVectorImpl< Edge > &

ExitEdges

)

const

getExitEdges - Return all pairs of (inside_block,outside_block).

Definition at line 87 of file LoopInfoImpl.h.

References I, and llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back().

template<class BlockT , class LoopT >

BlockT * llvm::LoopBase< BlockT, LoopT >::getExitingBlock

(

)

const

getExitingBlock - If getExitingBlocks would return exactly one block, return that block. Otherwise return null.

Definition at line 49 of file LoopInfoImpl.h.

References llvm::SmallVectorTemplateCommon< T >::size().

Referenced by canExpandBackedgeTakenCount(), FindLoopCounter(), genLoopLimit(), getLoopTest(), and llvm::UnrollRuntimeLoopProlog().

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::getExitingBlocks

(

SmallVectorImpl< BlockT * > &

ExitingBlocks

)

const

getExitingBlocks - Return all blocks inside the loop that have successors outside of the loop. These are the blocks inside of the current loop which branch out. The returned list is always unique.

Definition at line 33 of file LoopInfoImpl.h.

References I, and llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back().

Referenced by llvm::Region::contains().

template<class N, class M>

BlockT* llvm::LoopBase< N, M >::getHeader ( ) const

inline

Definition at line 95 of file LoopInfo.h.

Referenced by llvm::LoopBlocksTraversal::begin(), canConstantEvolve(), CloneLoopBlocks(), llvm::Region::contains(), DoInitialMatch(), emitBasicBlockLoopComments(), llvm::LoopBlocksTraversal::end(), FindLoopCounter(), FindPHIToPartitionLoops(), llvm::ScalarEvolution::getAddRecExpr(), llvm::Loop::getCanonicalInductionVariable(), llvm::Loop::getLoopID(), getLoopPhiForCounter(), llvm::LoopBase< BasicBlock, Loop >::getNumBackEdges(), llvm::SCEVExpander::getOrInsertCanonicalInductionVariable(), llvm::InsertPreheaderForLoop(), isExistingPhi(), llvm::ScalarEvolution::isLoopBackedgeGuardedByCond(), llvm::ScalarEvolution::isLoopEntryGuardedByCond(), isLoopInvariant(), isSimplifiedLoopNest(), isTrivialLoopExitBlock(), PickMostRelevantLoop(), llvm::SCEV::print(), llvm::IVUsers::print(), PrintLoopInfo(), PrintParentLoopComment(), PushLoopPHIs(), llvm::SCEVExpander::replaceCongruentIVs(), llvm::LPPassManager::runOnFunction(), llvm::Loop::setLoopID(), llvm::ScalarEvolution::SimplifyICmpOperands(), llvm::simplifyLoopIVs(), llvm::UnrollLoop(), and llvm::UnrollRuntimeLoopProlog().

template<class N, class M>

unsigned llvm::LoopBase< N, M >::getLoopDepth ( ) const

inline

getLoopDepth - Return the nesting level of this loop. An outer-most loop has depth 1, for consistency with loop depth values used for basic blocks, where depth 0 is used for blocks not inside any loops.

Definition at line 88 of file LoopInfo.h.

Referenced by emitBasicBlockLoopComments(), llvm::ScalarEvolution::getAddRecExpr(), PrintParentLoopComment(), and UpdateAnalysisInformation().

template<class BlockT , class LoopT >

BlockT * llvm::LoopBase< BlockT, LoopT >::getLoopLatch

(

)

const

getLoopLatch - If there is a single latch block for this loop, return it. A latch block is a block that contains a branch back to the header.

Definition at line 154 of file LoopInfoImpl.h.

References N.

Referenced by CloneLoopBlocks(), ConnectProlog(), FindLoopCounter(), llvm::Loop::getLoopID(), getLoopTest(), llvm::ScalarEvolution::isLoopBackedgeGuardedByCond(), llvm::Loop::isLoopSimplifyForm(), IVUseShouldUsePostIncValue(), needsLFTR(), llvm::SCEVExpander::replaceCongruentIVs(), llvm::Loop::setLoopID(), llvm::UnrollLoop(), and llvm::UnrollRuntimeLoopProlog().

template<class BlockT , class LoopT >

BlockT * llvm::LoopBase< BlockT, LoopT >::getLoopPredecessor

(

)

const

getLoopPredecessor - If the given loop's header has exactly one unique predecessor outside the loop, return it. Otherwise return null. This is less strict that the loop "preheader" concept, which requires the predecessor to have exactly one successor.

Definition at line 128 of file LoopInfoImpl.h.

References N.

Referenced by llvm::ScalarEvolution::isLoopEntryGuardedByCond().

template<class BlockT , class LoopT >

BlockT * llvm::LoopBase< BlockT, LoopT >::getLoopPreheader

(

)

const

getLoopPreheader - If there is a preheader for this loop, return it. A loop has a preheader if there is only one edge to the header of the loop from outside of the loop. If this is the case, the block branching to the header of the loop is the preheader node.

This method returns null if there is no preheader for the loop.

Definition at line 106 of file LoopInfoImpl.h.

Referenced by CloneLoopBlocks(), genLoopLimit(), llvm::Loop::isLoopSimplifyForm(), llvm::Loop::makeLoopInvariant(), llvm::UnrollLoop(), and llvm::UnrollRuntimeLoopProlog().

template<class N, class M>

unsigned llvm::LoopBase< N, M >::getNumBackEdges ( ) const

inline

getNumBackEdges - Calculate the number of back edges to the loop header

Definition at line 164 of file LoopInfo.h.

template<class N, class M>

unsigned llvm::LoopBase< N, M >::getNumBlocks ( ) const

inline

getNumBlocks - Get the number of blocks in this loop in constant time.

Definition at line 144 of file LoopInfo.h.

Referenced by llvm::LoopBlocksTraversal::begin(), llvm::LoopBlocksDFS::isComplete(), and llvm::LoopBlocksDFS::LoopBlocksDFS().

template<class N, class M>

LoopT* llvm::LoopBase< N, M >::getParentLoop ( ) const

inline

Definition at line 96 of file LoopInfo.h.

Referenced by CloneLoopBlocks(), emitBasicBlockLoopComments(), getOutermostLoop(), llvm::LPPassManager::insertLoopIntoQueue(), LoopIsOuterMostWithPredecessor(), llvm::Region::outermostLoopInRegion(), llvm::ScalarEvolution::print(), PrintParentLoopComment(), llvm::UnrollRuntimeLoopProlog(), and llvm::LoopInfo::updateUnloop().

template<class N, class M>

const std::vector<LoopT *>& llvm::LoopBase< N, M >::getSubLoops ( ) const

inline

iterator/begin/end - Return the loops contained entirely within this loop.

Definition at line 125 of file LoopInfo.h.

template<class N, class M>

std::vector<LoopT *>& llvm::LoopBase< N, M >::getSubLoopsVector ( )

inline

Definition at line 126 of file LoopInfo.h.

template<class N, class M>

bool llvm::LoopBase< N, M >::isLoopExiting ( const BlockT *  BB ) const

inline

isLoopExiting - True if terminator in the block can branch to another block that is outside of the current loop.

Definition at line 151 of file LoopInfo.h.

Referenced by llvm::VirtRegAuxInfo::calculateSpillWeightAndHint().

template<class N, class M>

void llvm::LoopBase< N, M >::moveToHeader ( BlockT *  BB )

inline

moveToHeader - This method is used to move BB (which must be part of this loop) to be the loop header of the loop (the block that dominates all others).

Definition at line 291 of file LoopInfo.h.

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::print	(	raw_ostream &	OS,
		unsigned	Depth = 0
	)		const

Definition at line 318 of file LoopInfoImpl.h.

References llvm::sys::path::begin(), llvm::sys::path::end(), I, llvm::raw_ostream::indent(), and llvm::WriteAsOperand().

Referenced by llvm::Loop::dump(), and llvm::operator<<().

template<class N, class M>

reverse_iterator llvm::LoopBase< N, M >::rbegin ( ) const

inline

Definition at line 132 of file LoopInfo.h.

Referenced by addLoopIntoQueue(), getLoopBackedgeTakenCounts(), and llvm::ScalarEvolution::verifyAnalysis().

template<class N, class M>

void llvm::LoopBase< N, M >::removeBlockFromLoop ( BlockT *  BB )

inline

removeBlockFromLoop - This removes the specified basic block from the current loop, updating the Blocks as appropriate. This does not update the mapping in the LoopInfo class.

Definition at line 306 of file LoopInfo.h.

template<class N, class M>

LoopT* llvm::LoopBase< N, M >::removeChildLoop ( iterator  I )

inline

removeChildLoop - This removes the specified child from being a subloop of this loop. The loop is not deleted, as it will presumably be inserted into another loop.

Definition at line 261 of file LoopInfo.h.

Referenced by llvm::LoopInfo::updateUnloop().

template<class N, class M>

reverse_iterator llvm::LoopBase< N, M >::rend ( ) const

inline

Definition at line 133 of file LoopInfo.h.

Referenced by addLoopIntoQueue(), getLoopBackedgeTakenCounts(), and llvm::ScalarEvolution::verifyAnalysis().

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::replaceChildLoopWith	(	LoopT *	OldChild,
		LoopT *	NewChild
	)

replaceChildLoopWith - This is used when splitting loops up. It replaces the OldChild entry in our children list with NewChild, and updates the parent pointer of OldChild to be null and the NewChild to be this loop. This updates the loop depth of the new child.

Definition at line 209 of file LoopInfoImpl.h.

References I.

template<class N, class M>

void llvm::LoopBase< N, M >::reserveBlocks ( unsigned  size )

inline

reserveBlocks- interface to do reserve() for Blocks

Definition at line 284 of file LoopInfo.h.

template<class N, class M>

void llvm::LoopBase< N, M >::reverseBlock ( unsigned  from )

inline

reverseBlocks - interface to reverse Blocks[from, end of loop] in this loop

Definition at line 279 of file LoopInfo.h.

template<class N, class M>

void llvm::LoopBase< N, M >::setParentLoop ( LoopT *  L )

inline

setParentLoop is a raw interface for bypassing addChildLoop.

Definition at line 99 of file LoopInfo.h.

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::verifyLoop

(

)

const

verifyLoop - Verify loop structure

Definition at line 222 of file LoopInfoImpl.h.

References llvm::sys::path::begin(), llvm::df_begin(), llvm::df_end(), llvm::df_ext_begin(), llvm::df_ext_end(), llvm::SmallVectorBase::empty(), llvm::sys::path::end(), getParent(), I, llvm::SmallPtrSet< PtrType, SmallSize >::insert(), N, llvm::A64CC::NE, llvm::SmallVectorTemplateBase< T, isPodLike< T >::value >::push_back(), and llvm::SmallVectorTemplateCommon< T >::size().

Referenced by llvm::LPPassManager::runOnFunction().

template<class BlockT , class LoopT >

void llvm::LoopBase< BlockT, LoopT >::verifyLoopNest

(

DenseSet< const LoopT * > *

Loops

)

const

verifyLoop - Verify loop structure of this loop and all nested loops.

Definition at line 307 of file LoopInfoImpl.h.

References llvm::sys::path::begin(), llvm::sys::path::end(), I, and llvm::DenseSet< ValueT, ValueInfoT >::insert().

Friends And Related Function Documentation

template<class N, class M>

friend class LoopInfoBase< BlockT, LoopT >

friend

Definition at line 320 of file LoopInfo.h.

---

The documentation for this class was generated from the following files:

• LoopInfo.h
• LoopInfoImpl.h
