#include <SelectionDAGISel.h>

Inheritance diagram for llvm::SelectionDAGISel:

Collaboration diagram for llvm::SelectionDAGISel:

Public Types
enum	BuiltinOpcodes { OPC_Scope, OPC_RecordNode, OPC_RecordChild0, OPC_RecordChild1, OPC_RecordChild2, OPC_RecordChild3, OPC_RecordChild4, OPC_RecordChild5, OPC_RecordChild6, OPC_RecordChild7, OPC_RecordMemRef, OPC_CaptureGlueInput, OPC_MoveChild, OPC_MoveParent, OPC_CheckSame, OPC_CheckChild0Same, OPC_CheckChild1Same, OPC_CheckChild2Same, OPC_CheckChild3Same, OPC_CheckPatternPredicate, OPC_CheckPredicate, OPC_CheckOpcode, OPC_SwitchOpcode, OPC_CheckType, OPC_SwitchType, OPC_CheckChild0Type, OPC_CheckChild1Type, OPC_CheckChild2Type, OPC_CheckChild3Type, OPC_CheckChild4Type, OPC_CheckChild5Type, OPC_CheckChild6Type, OPC_CheckChild7Type, OPC_CheckInteger, OPC_CheckCondCode, OPC_CheckValueType, OPC_CheckComplexPat, OPC_CheckAndImm, OPC_CheckOrImm, OPC_CheckFoldableChainNode, OPC_EmitInteger, OPC_EmitRegister, OPC_EmitRegister2, OPC_EmitConvertToTarget, OPC_EmitMergeInputChains, OPC_EmitMergeInputChains1_0, OPC_EmitMergeInputChains1_1, OPC_EmitCopyToReg, OPC_EmitNodeXForm, OPC_EmitNode, OPC_MorphNodeTo, OPC_MarkGlueResults, OPC_CompleteMatch }

enum	{ OPFL_None = 0, OPFL_Chain = 1, OPFL_GlueInput = 2, OPFL_GlueOutput = 4, OPFL_MemRefs = 8, OPFL_Variadic0 = 1<<4, OPFL_Variadic1 = 2<<4, OPFL_Variadic2 = 3<<4, OPFL_Variadic3 = 4<<4, OPFL_Variadic4 = 5<<4, OPFL_Variadic5 = 6<<4, OPFL_Variadic6 = 7<<4, OPFL_VariadicInfo = OPFL_Variadic6 }

Public Member Functions
	SelectionDAGISel (TargetMachine &tm, CodeGenOpt::Level OL=CodeGenOpt::Default)

virtual	~SelectionDAGISel ()

const TargetLowering *	getTargetLowering () const

virtual void	getAnalysisUsage (AnalysisUsage &AU) const

virtual bool	runOnMachineFunction (MachineFunction &MF)

virtual void	EmitFunctionEntryCode ()

virtual void	PreprocessISelDAG ()

virtual void	PostprocessISelDAG ()

virtual SDNode *	Select (SDNode *N)=0
	Select - Main hook targets implement to select a node. More...

virtual bool	SelectInlineAsmMemoryOperand (const SDValue &Op, char ConstraintCode, std::vector< SDValue > &OutOps)

virtual bool	IsProfitableToFold (SDValue N, SDNode U, SDNode Root) const

bool	CheckAndMask (SDValue LHS, ConstantSDNode *RHS, int64_t DesiredMaskS) const

bool	CheckOrMask (SDValue LHS, ConstantSDNode *RHS, int64_t DesiredMaskS) const

virtual bool	CheckPatternPredicate (unsigned PredNo) const

virtual bool	CheckNodePredicate (SDNode *N, unsigned PredNo) const

virtual bool	CheckComplexPattern (SDNode Root, SDNode Parent, SDValue N, unsigned PatternNo, SmallVectorImpl< std::pair< SDValue, SDNode * > > &Result)

virtual SDValue	RunSDNodeXForm (SDValue V, unsigned XFormNo)

SDNode *	SelectCodeCommon (SDNode NodeToMatch, const unsigned char MatcherTable, unsigned TableSize)

Public Member Functions inherited from llvm::FunctionPass
	FunctionPass (char &pid)

Pass *	createPrinterPass (raw_ostream &O, const std::string &Banner) const
	createPrinterPass - Get a function printer pass. More...

virtual void	assignPassManager (PMStack &PMS, PassManagerType T)

virtual PassManagerType	getPotentialPassManagerType () const
	Return what kind of Pass Manager can manage this pass. More...

Public Member Functions inherited from llvm::Pass
	Pass (PassKind K, char &pid)

virtual	~Pass ()

PassKind	getPassKind () const

virtual const char *	getPassName () const

AnalysisID	getPassID () const
	getPassID - Return the PassID number that corresponds to this pass. More...

virtual bool	doInitialization (Module &)

virtual bool	doFinalization (Module &)

virtual void	print (raw_ostream &O, const Module *M) const

void	dump () const

virtual void	preparePassManager (PMStack &)
	Check if available pass managers are suitable for this pass or not. More...

void	setResolver (AnalysisResolver *AR)

AnalysisResolver *	getResolver () const

virtual void	releaseMemory ()

virtual void *	getAdjustedAnalysisPointer (AnalysisID ID)

virtual ImmutablePass *	getAsImmutablePass ()

virtual PMDataManager *	getAsPMDataManager ()

virtual void	verifyAnalysis () const

virtual void	dumpPassStructure (unsigned Offset=0)

template<typename AnalysisType >
AnalysisType *	getAnalysisIfAvailable () const

bool	mustPreserveAnalysisID (char &AID) const

template<typename AnalysisType >
AnalysisType &	getAnalysis () const

template<typename AnalysisType >
AnalysisType &	getAnalysis (Function &F)

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI) const

template<typename AnalysisType >
AnalysisType &	getAnalysisID (AnalysisID PI, Function &F)

Static Public Member Functions
static bool	IsLegalToFold (SDValue N, SDNode U, SDNode Root, CodeGenOpt::Level OptLevel, bool IgnoreChains=false)

static int	getNumFixedFromVariadicInfo (unsigned Flags)

Static Public Member Functions inherited from llvm::Pass
static const PassInfo *	lookupPassInfo (const void *TI)

static const PassInfo *	lookupPassInfo (StringRef Arg)

static Pass *	createPass (AnalysisID ID)

Public Attributes
TargetMachine &	TM

const TargetLibraryInfo *	LibInfo

const TargetTransformInfo *	TTI

FunctionLoweringInfo *	FuncInfo

MachineFunction *	MF

MachineRegisterInfo *	RegInfo

SelectionDAG *	CurDAG

SelectionDAGBuilder *	SDB

AliasAnalysis *	AA

GCFunctionInfo *	GFI

CodeGenOpt::Level	OptLevel

Static Public Attributes
static char	ID = 0

Protected Member Functions
void	ReplaceUses (SDValue F, SDValue T)

void	ReplaceUses (const SDValue F, const SDValue T, unsigned Num)

void	ReplaceUses (SDNode F, SDNode T)

void	SelectInlineAsmMemoryOperands (std::vector< SDValue > &Ops)

Protected Member Functions inherited from llvm::MachineFunctionPass
	MachineFunctionPass (char &ID)

Protected Attributes
unsigned	DAGSize

Detailed Description

SelectionDAGISel - This is the common base class used for SelectionDAG-based pattern-matching instruction selectors.

Definition at line 42 of file SelectionDAGISel.h.

Member Enumeration Documentation

anonymous enum

Enumerator
OPFL_None
OPFL_Chain
OPFL_GlueInput
OPFL_GlueOutput
OPFL_MemRefs
OPFL_Variadic0
OPFL_Variadic1
OPFL_Variadic2
OPFL_Variadic3
OPFL_Variadic4
OPFL_Variadic5
OPFL_Variadic6
OPFL_VariadicInfo

Definition at line 149 of file SelectionDAGISel.h.

enum llvm::SelectionDAGISel::BuiltinOpcodes

Enumerator
OPC_Scope
OPC_RecordNode
OPC_RecordChild0
OPC_RecordChild1
OPC_RecordChild2
OPC_RecordChild3
OPC_RecordChild4
OPC_RecordChild5
OPC_RecordChild6
OPC_RecordChild7
OPC_RecordMemRef
OPC_CaptureGlueInput
OPC_MoveChild
OPC_MoveParent
OPC_CheckSame
OPC_CheckChild0Same
OPC_CheckChild1Same
OPC_CheckChild2Same
OPC_CheckChild3Same
OPC_CheckPatternPredicate
OPC_CheckPredicate
OPC_CheckOpcode
OPC_SwitchOpcode
OPC_CheckType
OPC_SwitchType
OPC_CheckChild0Type
OPC_CheckChild1Type
OPC_CheckChild2Type
OPC_CheckChild3Type
OPC_CheckChild4Type
OPC_CheckChild5Type
OPC_CheckChild6Type
OPC_CheckChild7Type
OPC_CheckInteger
OPC_CheckCondCode
OPC_CheckValueType
OPC_CheckComplexPat
OPC_CheckAndImm
OPC_CheckOrImm
OPC_CheckFoldableChainNode
OPC_EmitInteger
OPC_EmitRegister
OPC_EmitRegister2
OPC_EmitConvertToTarget
OPC_EmitMergeInputChains
OPC_EmitMergeInputChains1_0
OPC_EmitMergeInputChains1_1
OPC_EmitCopyToReg
OPC_EmitNodeXForm
OPC_EmitNode
OPC_MorphNodeTo
OPC_MarkGlueResults
OPC_CompleteMatch

Definition at line 106 of file SelectionDAGISel.h.

Constructor & Destructor Documentation

SelectionDAGISel::SelectionDAGISel	(	TargetMachine &	tm,
		CodeGenOpt::Level	OL = `CodeGenOpt::Default`
	)

explicit

Definition at line 317 of file SelectionDAGISel.cpp.

References llvm::PassRegistry::getPassRegistry(), llvm::initializeAliasAnalysisAnalysisGroup(), llvm::initializeBranchProbabilityInfoPass(), llvm::initializeGCModuleInfoPass(), and llvm::initializeTargetLibraryInfoPass().

SelectionDAGISel::~SelectionDAGISel ( )

virtual

Definition at line 332 of file SelectionDAGISel.cpp.

References CurDAG, FuncInfo, and SDB.

Member Function Documentation

bool SelectionDAGISel::CheckAndMask	(	SDValue	LHS,
		ConstantSDNode *	RHS,
		int64_t	DesiredMaskS
	)		const

CheckAndMask - The isel is trying to match something like (and X, 255). If the dag combiner simplified the 255, we still want to match. RHS is the actual value in the DAG on the RHS of an AND, and DesiredMaskS is the value specified in the .td file (e.g. 255).

Definition at line 1559 of file SelectionDAGISel.cpp.

References CurDAG, llvm::ConstantSDNode::getAPIntValue(), llvm::SDValue::getValueSizeInBits(), llvm::APInt::intersects(), and llvm::SelectionDAG::MaskedValueIsZero().

Referenced by CheckAndImm().

virtual bool llvm::SelectionDAGISel::CheckComplexPattern	(	SDNode *	Root,
		SDNode *	Parent,
		SDValue	N,
		unsigned	PatternNo,
		SmallVectorImpl< std::pair< SDValue, SDNode * > > &	Result
	)

inlinevirtual

Definition at line 227 of file SelectionDAGISel.h.

References llvm_unreachable.

Referenced by SelectCodeCommon().

virtual bool llvm::SelectionDAGISel::CheckNodePredicate	(	SDNode *	N,
		unsigned	PredNo
	)		const

inlinevirtual

CheckNodePredicate - This function is generated by tblgen in the target. It runs node predicate number PredNo and returns true if it succeeds or false if it fails. The number is a private implementation detail to the code tblgen produces.

Definition at line 223 of file SelectionDAGISel.h.

References llvm_unreachable.

Referenced by CheckNodePredicate(), and SelectCodeCommon().

bool SelectionDAGISel::CheckOrMask	(	SDValue	LHS,
		ConstantSDNode *	RHS,
		int64_t	DesiredMaskS
	)		const

CheckOrMask - The isel is trying to match something like (or X, 255). If the dag combiner simplified the 255, we still want to match. RHS is the actual value in the DAG on the RHS of an OR, and DesiredMaskS is the value specified in the .td file (e.g. 255).

Definition at line 1588 of file SelectionDAGISel.cpp.

References llvm::SelectionDAG::ComputeMaskedBits(), CurDAG, llvm::ConstantSDNode::getAPIntValue(), llvm::SDValue::getValueSizeInBits(), and llvm::APInt::intersects().

Referenced by CheckOrImm().

virtual bool llvm::SelectionDAGISel::CheckPatternPredicate ( unsigned PredNo ) const

inlinevirtual

CheckPatternPredicate - This function is generated by tblgen in the target. It runs the specified pattern predicate and returns true if it succeeds or false if it fails. The number is a private implementation detail to the code tblgen produces.

Definition at line 215 of file SelectionDAGISel.h.

References llvm_unreachable.

Referenced by CheckPatternPredicate(), and SelectCodeCommon().

virtual void llvm::SelectionDAGISel::EmitFunctionEntryCode ( )

inlinevirtual

Definition at line 69 of file SelectionDAGISel.h.

void SelectionDAGISel::getAnalysisUsage ( AnalysisUsage & AU ) const

virtual

getAnalysisUsage - Subclasses that override getAnalysisUsage must call this.

For MachineFunctionPasses, calling AU.preservesCFG() indicates that the pass does not modify the MachineBasicBlock CFG.

Reimplemented from llvm::MachineFunctionPass.

Definition at line 338 of file SelectionDAGISel.cpp.

References llvm::AnalysisUsage::addPreserved(), llvm::AnalysisUsage::addRequired(), llvm::MachineFunctionPass::getAnalysisUsage(), llvm::CodeGenOpt::None, OptLevel, and UseMBPI.

static int llvm::SelectionDAGISel::getNumFixedFromVariadicInfo ( unsigned Flags )

inlinestatic

getNumFixedFromVariadicInfo - Transform an EmitNode flags word into the number of fixed arity values that should be skipped when copying from the root.

Definition at line 169 of file SelectionDAGISel.h.

References OPFL_VariadicInfo.

Referenced by SelectCodeCommon().

const TargetLowering* llvm::SelectionDAGISel::getTargetLowering ( ) const

inline

Definition at line 61 of file SelectionDAGISel.h.

References llvm::TargetMachine::getTargetLowering(), and TM.

Referenced by llvm::createDefaultScheduler(), llvm::createHybridListDAGScheduler(), llvm::createILPListDAGScheduler(), llvm::MipsDAGToDAGISel::getGlobalBaseReg(), IsPredicateKnownToFail(), llvm::ResourcePriorityQueue::ResourcePriorityQueue(), and SelectCodeCommon().

bool SelectionDAGISel::IsLegalToFold	(	SDValue	N,
		SDNode *	U,
		SDNode *	Root,
		CodeGenOpt::Level	OptLevel,
		bool	IgnoreChains = `false`
	)

static

IsLegalToFold - Returns true if the specific operand node N of U can be folded during instruction selection that starts at Root. FIXME: This is a static member function because the MSP430/X86 targets, which uses it during isel. This could become a proper member.

IsLegalToFold - Returns true if the specific operand node N of U can be folded during instruction selection that starts at Root.

Definition at line 1730 of file SelectionDAGISel.cpp.

References findGlueUse(), findNonImmUse(), llvm::SDValue::getNode(), llvm::SDNode::getNumValues(), llvm::SDNode::getValueType(), llvm::MVT::Glue, and llvm::CodeGenOpt::None.

Referenced by SelectCodeCommon().

bool SelectionDAGISel::IsProfitableToFold	(	SDValue	N,
		SDNode *	U,
		SDNode *	Root
	)		const

virtual

IsProfitableToFold - Returns true if it's profitable to fold the specific operand node N of U during instruction selection that starts at Root.

Definition at line 1722 of file SelectionDAGISel.cpp.

References llvm::SDValue::hasOneUse(), llvm::CodeGenOpt::None, and OptLevel.

Referenced by SelectCodeCommon().

virtual void llvm::SelectionDAGISel::PostprocessISelDAG ( )

inlinevirtual

PostprocessISelDAG() - This hook allows the target to hack on the graph right after selection.

Definition at line 77 of file SelectionDAGISel.h.

virtual void llvm::SelectionDAGISel::PreprocessISelDAG ( )

inlinevirtual

PreprocessISelDAG - This hook allows targets to hack on the graph before instruction selection starts.

Definition at line 73 of file SelectionDAGISel.h.

void llvm::SelectionDAGISel::ReplaceUses	(	SDValue	F,
		SDValue	T
	)

inlineprotected

ReplaceUses - replace all uses of the old node F with the use of the new node T.

Definition at line 181 of file SelectionDAGISel.h.

References CurDAG, and llvm::SelectionDAG::ReplaceAllUsesOfValueWith().

void llvm::SelectionDAGISel::ReplaceUses	(	const SDValue *	F,
		const SDValue *	T,
		unsigned	Num
	)

inlineprotected

ReplaceUses - replace all uses of the old nodes F with the use of the new nodes T.

Definition at line 187 of file SelectionDAGISel.h.

References CurDAG, and llvm::SelectionDAG::ReplaceAllUsesOfValuesWith().

void llvm::SelectionDAGISel::ReplaceUses	(	SDNode *	F,
		SDNode *	T
	)

inlineprotected

ReplaceUses - replace all uses of the old node F with the use of the new node T.

Definition at line 193 of file SelectionDAGISel.h.

References CurDAG, and llvm::SelectionDAG::ReplaceAllUsesWith().

bool SelectionDAGISel::runOnMachineFunction ( MachineFunction & MF )

virtual

runOnMachineFunction - This method must be overloaded to perform the desired machine code transformation or analysis.

Implements llvm::MachineFunctionPass.

Reimplemented in llvm::MipsDAGToDAGISel.

Definition at line 387 of file SelectionDAGISel.cpp.

References AA, llvm::FunctionLoweringInfo::ArgDbgValues, llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::begin(), llvm::MachineBasicBlock::begin(), llvm::MachineFunction::begin(), llvm::FunctionLoweringInfo::BPI, llvm::BuildMI(), llvm::Function::callsFunctionThatReturnsTwice(), llvm::FunctionLoweringInfo::clear(), llvm::MachineRegisterInfo::constrainRegClass(), CurDAG, llvm::TargetOpcode::DBG_VALUE, llvm::dbgs(), DEBUG, llvm::tgtok::Def, llvm::MachineRegisterInfo::EmitLiveInCopies(), llvm::TargetOptions::EnableFastISel, EnableFastISelAbort, EnableFastISelVerbose, llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::end(), llvm::MachineBasicBlock::end(), llvm::MachineFunction::end(), llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::find(), llvm::MachineRegisterInfo::freezeReservedRegs(), FuncInfo, llvm::MCInstrInfo::get(), llvm::MachineInstr::getDebugLoc(), llvm::MachineFunction::getFrameInfo(), llvm::TargetRegisterInfo::getFrameRegister(), llvm::MachineFunction::getFunction(), llvm::MachineOperand::getImm(), llvm::TargetMachine::getInstrInfo(), llvm::Value::getName(), llvm::MachineInstr::getNumOperands(), llvm::MachineInstr::getOperand(), llvm::MachineInstr::getParent(), llvm::MachineOperand::getReg(), llvm::MachineRegisterInfo::getRegClass(), llvm::MachineFunction::getRegInfo(), llvm::TargetMachine::getRegisterInfo(), llvm::TargetMachine::getSubtarget(), llvm::TargetMachine::getTargetLowering(), llvm::MachineRegisterInfo::getVRegDef(), GFI, llvm::MachineFrameInfo::hasCalls(), llvm::Function::hasFnAttribute(), llvm::Function::hasGC(), llvm::MachineFunction::hasMSInlineAsm(), I, llvm::ARM_PROC::IE, llvm::SelectionDAG::init(), llvm::SelectionDAGBuilder::init(), llvm::DenseMapBase< DerivedT, KeyT, ValueT, KeyInfoT >::insert(), llvm::MachineBasicBlock::insert(), llvm::MachineBasicBlock::insertAfter(), llvm::MCInstrDesc::isCall(), llvm::MachineInstr::isCopy(), llvm::MachineInstr::isDebugValue(), llvm::MachineOperand::isFI(), llvm::MachineInstr::isIndirectDebugValue(), llvm::TargetRegisterInfo::isPhysicalRegister(), llvm::MCInstrDesc::isReturn(), llvm::TargetRegisterInfo::isVirtualRegister(), LI, LibInfo, llvm::MachineRegisterInfo::livein_begin(), llvm::MachineRegisterInfo::livein_end(), MF, llvm::A64CC::MI, MRI, llvm::next(), llvm::CodeGenOpt::None, llvm::Attribute::OptimizeNone, llvm::TargetMachine::Options, OptLevel, llvm::FunctionLoweringInfo::RegFixups, RegInfo, llvm::MachineRegisterInfo::replaceRegWith(), llvm::TargetSubtargetInfo::resetSubtargetFeatures(), llvm::TargetMachine::resetTargetOptions(), SDB, llvm::FunctionLoweringInfo::set(), llvm::MachineFunction::setExposesReturnsTwice(), llvm::MachineFrameInfo::setHasCalls(), llvm::MachineFunction::setHasMSInlineAsm(), SplitCriticalSideEffectEdges(), llvm::A64DB::ST, TII, TM, TTI, llvm::MachineRegisterInfo::use_begin(), UseMBPI, and llvm::TargetRegisterInfo::virtReg2Index().

Referenced by llvm::MipsDAGToDAGISel::runOnMachineFunction().

virtual SDValue llvm::SelectionDAGISel::RunSDNodeXForm	(	SDValue	V,
		unsigned	XFormNo
	)

inlinevirtual

Definition at line 233 of file SelectionDAGISel.h.

References llvm_unreachable.

Referenced by SelectCodeCommon().

virtual SDNode* llvm::SelectionDAGISel::Select ( SDNode * N )

pure virtual

Select - Main hook targets implement to select a node.

SDNode * SelectionDAGISel::SelectCodeCommon	(	SDNode *	NodeToMatch,
		const unsigned char *	MatcherTable,
		unsigned	TableSize
	)

Definition at line 2350 of file SelectionDAGISel.cpp.

virtual bool llvm::SelectionDAGISel::SelectInlineAsmMemoryOperand	(	const SDValue &	Op,
		char	ConstraintCode,
		std::vector< SDValue > &	OutOps
	)

inlinevirtual

SelectInlineAsmMemoryOperand - Select the specified address as a target addressing mode, according to the specified constraint code. If this does not match or is not implemented, return true. The resultant operands (which will appear in the machine instruction) should be added to the OutOps vector.

Definition at line 87 of file SelectionDAGISel.h.

Referenced by SelectInlineAsmMemoryOperands().

void SelectionDAGISel::SelectInlineAsmMemoryOperands ( std::vector< SDValue > & Ops )

protected

SelectInlineAsmMemoryOperands - Calls to this are automatically generated by tblgen. Others should not call it.

Definition at line 1622 of file SelectionDAGISel.cpp.

References CurDAG, llvm::InlineAsm::getFlagWord(), llvm::InlineAsm::getNumOperandRegisters(), llvm::SelectionDAG::getTargetConstant(), llvm::MVT::Glue, llvm::MVT::i32, llvm::InlineAsm::isMemKind(), llvm::report_fatal_error(), SelectInlineAsmMemoryOperand(), and std::swap().
